VERSION # 20- 10-17
1 / 9
MODEL #
CM7383EK/CK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
3 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7383EK
Summary of Contents for Furniture of America CM7383EK
- Page 1 MODEL # CM7383EK/CK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 3 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 9...
- Page 5 CM7383EK/CK #1 1pc #2 2pcs #3 1pcs #4 2pcs Headboard Panel Headboard Post L/R Footboard Side Rail #5 3 pcs #6 6 pcs Ø1/4" Support Leg Slat 177 x 32 x 32mm #A 2pcs #B 6pcs #C 8pcs #D 8pcs Flat Washer Ø5/16''...
- Page 6 CM7383 EK/CK is packed in 3 cases Carton Disignation Part Hardware CM7383EK/CK-HB Headboard Panel #A x 2pcs CM7383EK/CK-HB #B x 6pcs #C x 8pcs Headboard Post L/R #D x 8pcs #E x 2Pcs Footboard CM7383EK/CK-FB #F x 1pc Slat #G x 6 pcs...
- Page 7 ASSEMBLY INSTRUCTIONS Align HB posts (#2R/L) to the headboard (#1), then secure by using bolts (#A) with washers Part #1 x1pc Part (#C,D). #2 x2pcs Hardware #A x2pcs Hardware #C x2pcs Hardware #D x2pcs Hardware #E x2pcs Hardware #B x6pcs Hardware #C x6pcs Hardware...
- Page 8 ASSEMBLY INSTRUCTIONS Align and hook side rails (#4) to the headboard (#1) and footboard (#3). Part #3 x1pc Part #4 x2pcs Part #5 x1pc Part #6 x2pcs Attach support legs (#6) to the slats (#5). Leveler 8 / 9...
- Page 9 ASSEMBLY INSTRUCTIONS Align slats (#5) to the side rails, then secure by using screws (#G). Hardware #G x6pcs 9 / 9...
