SUSPENZ 11-7800 Quick Start Manual

Ceiling Rack
Tools Needed : Tape Measure, Stud Finder, Electric Drill, ¹/₄" Drill Bit,
¹/₁₆" drill bit, Adjustable Wrench, and a Bar of Soap
Note: When determining Ceiling Rack placement, the base of the
Ceiling Post
must run parallel to the center of the ceiling joist;
Arms
however, the may be positioned in any direction.

Important Safety Note:

It is critical that the 4 lag screws securing each Ceiling Post to the
ceiling are screwed into the center of a wooden joist. Screwing
Ceiling Posts into just dry wall or the edge of a joist is not suffi-
cient and could result in injury to self and damage to watercraft
or vehicle.
The length of your craft will determine the
spacing.
(boat/board length X 0.4 = spacing).
1. Use a Stud Finder to determine which way the ceiling joists
run in your ceiling.
2. Hold horizontal part of
mark a hole location at one end.
