Double Trouble
Cart
Tools Needed: Phillips head screwdriver and adjustable wrench
Step 1: Assemble Stand
Parts Needed: 2
Base Frames
Washers
Lock Nuts
8
and 4
For Technical assistance or Replacement parts: call 866.787.7369
Rev. 11/17
Suspenz®, Inc.
8725 Roswell Road #0-220
Atlanta GA 30350
and 2
Base Frame Cross Bars
Stand
, 4
Bolts,
Model # 22-9935
Parts List
Qty
Name
2
Base Frame
2
Base Frame Cross Bar
1
Wheel Base with Axel
2
Loop Frame
1
Top Frame
4
Bolts
8
Washer
4
Lock Nut
4
Locking Pin
2
10" Airless Wheel
2
Quick Release Pin
1
Strap
Holds up to 125 LBS
Scan* to see
Video Instructions
for Assembly & Use
or
Visit Suspenz.com
"Video & Manual" page
*QR code reader app required
Customer Service:770-518-0045
Fax: 770-518-8507
Website: www.suspenz.com
Advertisement
Related Manuals for SUSPENZ Double Trouble 22-9935
Summary of Contents for SUSPENZ Double Trouble 22-9935
- Page 1 Bolts, Washers Lock Nuts and 4 Scan* to see Video Instructions for Assembly & Use Visit Suspenz.com “Video & Manual” page *QR code reader app required For Technical assistance or Replacement parts: call 866.787.7369 Rev. 11/17 Suspenz®, Inc. Customer Service:770-518-0045...
- Page 2 4 Locking Pins, 2 Loop Frames Parts Needed: Top Frame Parts Needed: 1 and 1 Wheel Base Loop Frame. Repeat for 2nd For Technical assistance or Replacement parts: call 866.787.7369 Suspenz®, Inc. Customer Service:770-518-0045 8725 Roswell Road #0-220 Fax: 770-518-8507 Atlanta GA 30350 Website: www.suspenz.com...
- Page 3 Step 3: Assemble Wheel to Wheel Base Wheels Quick Release Pins Parts Needed: 2 For Technical assistance or Replacement parts: call 866.787.7369 Suspenz®, Inc. Customer Service:770-518-0045 8725 Roswell Road #0-220 Fax: 770-518-8507 Atlanta GA 30350 Website: www.suspenz.com...
- Page 4 OUR PLEDGE TO YOU ® Suspenz products are warrantied for life against defects in material or workmanship to the original owner. Product must be used for its intended purpose under normal conditions. Please visit www.Suspenz.com for complete warranty information. Suspenz®, Inc. Customer Service:770-518-0045...
