1 INTRODUCTION

1.1

ABOUT THIS MANUAL

This integration manual explains how to integrate ELATEC RFID reader module TWN4 MultiTech 3 M BLE into a host device and is
mainly intended for integrators and host manufacturers.
The content of this integration manual is subject to changes without prior notice and printed versions might be obsolete. Integrators
and host manufacturers are required to use the latest version of this integration manual.
For the sake of better understanding and readability, this manual might contain exemplary pictures, drawings and other illustrations.
Depending on your product configuration, these pictures might differ from the actual design of your product.
1.2

ABOUT TWN4 MULTITECH 3 M BLE

TWN4 MultiTech 3 M BLE integrates RFID (125 kHz and 13.56 MHz), NFC and Bluetooth Low Energy capabilities into a compact but
powerful reader. Its reduced size combined with optimized read/write performance makes it the perfect reader for all applications where
small size and full performance matters, e.g. print solutions, driver identification, POS integration and many more. Furthermore,
TWN4 MultiTech 3 M BLE provides access to most common host interfaces such as USB, serial (TTL) or I²C which are readily
accessible through an on-board connector.
1.3

ELATEC SUPPORT

In case of any technical questions, refer to the ELATEC website (www.elatec.com) or contact ELATEC technical support at:
support-rfid@elatec.com
1.4

REVISION HISTORY

VERSION
First edition
01 (replaces Transponder Reader TWN4 MultiTech 3 Quick Start Guide, Rev. 5.0, dated
11/2018)

2 SAFETY INFORMATION

•
ELATEC TWN4 MultiTech 3 M BLE is an electronic component and should be installed exclusively by a trained and qualified
personnel.
•
ELATEC recommends the integrators to follow general ESD protective measures during the installation of
TWN4 MultiTech 3 M BLE into a host device, e.g. the use of an antistatic wristband or special gloves.
•
The integrator should not touch the antennas (if not shielded), printed circuit boards, connectors or other sensitive components on
TWN4 MultiTech 3 M BLE.
•
Before installing TWN4 MultiTech 3 M BLE into a host device, the integrator should also make sure that he/she has read and
understood the ELATEC technical documentation related to TWN4 MultiTech 3 M BLE, as well as the technical documentation
related to the host device. In particular, the instructions and safety information given in the user manual of
TWN4 MultiTech 3 M BLE should be read carefully and listed in the technical documentation of the host manufacturer as well, as
soon as these instructions and safety information are required for a safe and proper use of the host device containing
TWN4 MultiTech 3 M BLE.
