Manual Chute Rotation - Kubota B2781B Operator And Parts Manual

M C
ANUAL HUTE
R . D
EF ESCRIPTION
1 Rotation worm
2 Rotation bracket
3 Plastic bushing short 1 5/16"
4 Serrated flange nut 3/8" NC, PTD
5 Rotation yoke
6 Universal block
7 Spring pin 1/4" x 1 1/4"
8 Rotation tube
9 Coupling rod
10 Allen socket head cap screw 10-24 x 1"
11 Nylon insert locknut 10-24
12 Rotation tube
13 Snap button
14 Rotation handle including item 13
15 Plastic handle
16 Grommet
17 Handle support- All Tractors - except B2320, B2620 & B2920
18 Rotation handle support
19 Bolt hex. 1/4"NC x 1" gr.5 PTD
20 Nut hex. 1/4" NC PTD
21 Lockwasher 1/4" PTD
22 Bolt hex. 6mm x 1.00 x 20mm lg PTD
23 Flat washer 1/4" (5/16" hole) PTD
24 Handle support – B2320, B2620 & B2920 Tractors
25 Handle support bracket
26 Allen socket head cap screw 10mm x 1.25 x 80mm lg Gr. 8.8 PTD
27 Lockwasher Ø10 mm, PTD
28 Bolt hex. 3/8" NC x 1 1/4" lg, PTD
29 Flat washer 1/4" PTD
OM 0377SB-A
PARTS
R
OTATION
29
Q P #
TY ART
1 70060-00694
1 70060-00693
2 70060-01350
2 70060-00791
1 70060-03416
1 70060-03417
2 77700-02237
1 70060-03498
1 70060-03228
3 70060-02583
3 77700-00991
1 70060-02297
1 70001-00568
1 70060-02292
1 70060-01318
1 70060-01352
1 70060-02280
1 70060-00692
5 75599-01120
5 75599-31011
5 75599-33011
2 70060-02110
4 75599-32011
1 77700-00618
1 77700-00619
2 77700-07144
2 70060-00792
2 75599-01325
5 75599-32011
C
ODE
665953
665952
657335
0900035
659595
658193
1600015
659594
659597
0800009
1000002
667227
663600
664007
656797
657390
667223
665951
0100004
0900001
1200002
0200090
1400002
668385
668386
0800058
1200019
0100039
1400002
