Chute With Deflector - Kubota B2781B Operator And Parts Manual

C D
HUTE WITH EFLECTOR
R . D
EF ESCRIPTION
1 Chute assembly w/ english decals
2 Knob 5/16"NC
3 Flat washer nylon 11/32" dia. PTD
4 Carriage bolt 5/16"NC x 1" GR. 5, PTD
5 Flat washer nylon 7/16" dia.
6 Hand guard
7 Bolt hex. 1/4"NC x 3/4" GR. 5, PTD
8 Flat washer 1/4" (5/16"hole) PTD
9 Lockwasher 1/4" PTD
10 Nut hex. 1/4"NC PTD
11 Rotation bushing
12 Spacer
13 Retaining plate – 3 holes
14 Retaining plate – 2 holes
15 Bolt hex. 5/16" NC x 1 1/2", PTD
16 Spacer PTD
17 Hex nut 5/16" NC, PTD
18 Lockwasher 5/16" PTD
OM 0377SB-A
PARTS
Q
TY
1
2
2
2
2
1
2
2
2
2
1
4
2
1
8
4
8
8
28
P # C
ART
77700-02292 669681
70060-01419 657309
70060-03052 658467
70001-00793 0300003
70060-03053 658468
70060-01358 657308
75599-01115 0100003
75599-32011 1400002
75599-33011 1200002
75599-31011 0900001
70060-03226 659151
70060-00697 665957
77700-03043 669496
77700-03044 669497
75599-01230 0100021
70060-00600 666191
75599-31012 0900002
75599-33012 1200003
ODE
