Garmin Rino 110 Quick Start Manual

Marking a Waypoint
Marking a waypoint is simply capturing your current location and
storing it in the unit's memory. The unit must be turned on and
tracking satellites to mark a waypoint.
To mark a waypoint:
1. Press the Thumb Stick In and hold it until the Shortcuts
Menu is displayed.
2. Highlight Mark Waypoint and press the Thumb Stick In to
display the Mark Waypoint Page shown below.
Symbol Field
Name
Field
Mark Waypoint Page
3. Highlight the Name field and press the Thumb Stick In. Enter
a new name. When finished, highlight OK then press the
Thumb Stick In.
4. Highlight the Symbol field and press the Thumb Stick In.
Choose a symbol then press the Thumb Stick In to accept
the selection.
5. Highlight the OK button at the bottom of the page and press
the Thumb Stick In to save the waypoint.
Creating a Breadcrumb Trail
As you move, notice that a breadcrumb trail of your path is left on
the map. This trail is called a Track Log. You can use the track log to
retrace your steps back to a certain location.
To view your breadcrumb trail (track log):
1. Use the Page button to display the Map Page.
2. Walk away from your original location for at least
three minutes.
3. The default zoom level is 80 miles. Press the Zoom button to
zoom in to view the breadcrumb trail (track log) in detail.
Navigating with Your Rino 110
You can navigate to a waypoint, city, exit, or a contact's location.
Using optional detailed maps, you can also navigate to points of
interest, addresses, and intersections.
To begin navigation using Find 'N Go:
1. Press the Thumb Stick In to display the Shortcuts Menu.
2. Highlight Find 'N Go and press the Thumb Stick In.
3. Highlight Waypoints and press the Thumb Stick In. Select
the desired option (by Nearest or by Name), and press the
Thumb Stick In.
4. Highlight the desired waypoint and press the Thumb Stick In.
5. With the Waypoint Page displayed, highlight the Goto button
at the bottom of the page and press the Thumb Stick In to
begin navigation. The Navigation Page automatically opens
to guide you to your destination. See below for more
information.
Navigation Page
The two main components of the Navigation
Page are the compass ring and the pointer. As
you move, the compass ring rotates showing
your current direction of travel at the top of
the display. The pointer points toward your
destination. When the pointer is aligned with
the vertical line at the top of the compass ring, Navigation Page
you are on a direct course toward your destina-
tion. The unit has to be moving to navigate. If you are standing still
or moving very slowly, the navigation data may not be accurate.
Using Contacts
The first time you receive a signal from another Rino user, the New
Contact page is displayed. From the New Contact page you can
show the user's location on your Map, Goto that position, select OK
to add them to your contact list, or press the
Page/Quit button to disregard the contact.
Every time you receive signals from
contacts, your map is updated showing their
new position. A Track Log of their move-
ment is created and shown on your map.
New Contact Page
Sending a Location
You can send any location that you have available in your Find 'N
Go menu. These may be waypoints, contacts, cities, exits, or any
other data that is loaded in the unit. Below are the steps to send a
waypoint.
To send a location (waypoint) using Find 'N Go:
1. Press the Thumb Stick In and hold it
until the Shortcuts Menu is displayed,
or press the Page button until the
Main Menu is displayed.
2. Highlight Find 'N Go and press the
Thumb Stick In. Highlight Way-
points and press the Thumb Stick
In. Select Nearest or By Name and
Send Location
press the Thumb Stick In.
3. Highlight the waypoint that you want to send and press the
Thumb Stick In to display the Waypoint Review page.
4. Highlight the Option Menu button and press the Thumb
Stick In.
5. Select Send Location and press the Thumb Stick In.
The location is sent to all Rinos on the same channel and squelch
code as you. They can then choose to Goto that location, view the
location on the map (Map), or save the location (OK).
Using Peer-to-Peer Positioning
The Rino's most unique feature is Peer-to-Peer positioning, send-
ing the location of one Rino unit to other Rino units. Peer-to-Peer
positioning allows you to track the movement of other Rino users
and even navigate to their location.
To send your location:
Press and release either the Call or Talk button. Your Rino
110 automatically sends out its location. Other Rino users
monitoring the same channel and squelch code receive this
information.
Using Find 'N Go
Using Find 'N Go, you can search for a waypoint and then create a
straight-line route to it from your current location.
To find and go to a waypoint:
1. Press and hold the Thumb Stick In to access the Shortcuts
Menu.
2. Highlight Find 'N Go and press In.
3. Highlight Waypoints and press the Thumb Stick In. Select
Nearest from the pop-up menu
4. Use the Thumb Stick to select the desired waypoint from the
list and then press In to display the Information Page for that
waypoint.
5. Highlight Goto and press In to create a straight-line route to
the waypoint from your current location.
Polling a Location
If you have not heard from a contact in a while and would like to
know that contact's current location, you may "poll" the contact's
location. This will update that contact's location in your Rino 110.
To poll a location:
1. Press the Thumb Stick In and
hold it until the Shortcuts Menu
is displayed, or press the Page
button until the Main Menu is
displayed.
2. Highlight Find 'N Go and press
the Thumb Stick In. Highlight
Polling a contact's location
Contacts and press the Thumb
Stick In.
3. Highlight the contact that you want to poll and press the
Thumb Stick In to display the Contact Review page.
4. Highlight the Option Menu button and press the Thumb
Stick In.
5. Select Poll Location and press the Thumb Stick In.
If you have further questions or just want to learn more about the
operation of Rino 110, refer to the Owner's Manual, which provides
detailed information about all of your Rino 110's features.
Rino 110
®

Quick Start Guide

Thumb Stick
Power button:
• Press In to enter
• Press and hold to turn the
highlighted options
unit On/Off
and to confirm
• Press to adjust contrast
messages
and backlighting
• Move Up, Down,
Right or Left to
Call button: move through lists,
highlight fields,
• Press to send out Call Tone
• Sends position when on-screen buttons,
icons, enter data,
released (if enabled)
or move the map
panning arrow
• Press In and hold
Talk button: to display Shortcuts
Menu.
• Press and hold to talk
• Sends position when
released (if enabled)
Zoom/Map (Z)
button:
Page/Quit button:
• From the Map Page,
• Press to cycle through
press to open Zoom
main pages
control window
• Used to quit or escape
• From any other
menu items
page, press to
display Map Page
Volume (V) button:
• Press to open volume
Microphone:
control window
• Hold unit 3–4 inches
Speaker
away when talking
Step-by-Step Instructions
to Get You Started
(Turn this page and begin with Step 1)
Part Number 190-00251-01 Rev. C
