Parts List - Realtree RTLS-520 Instruction & Safety Manual

MODEL: RTLS-520
18' Deluxe Two-man Ladderstand
• Always Wear a Safety Harness with this Product
• Weight Limit: 500 lbs. Two Person, 300 lbs. Single Person
• Practice Using at Ground Level
• Tree Size: 9"-18" diameter

PARTS LIST

A
1 Top Ladder Section.................
B 1 Middle Ladder Section............
C 1 Bottom Ladder Section........... Part # RBL-520
1 Seat Assembly.......................... Part # RSA-520
D
E
1 Foot Platform.......................... Part # RFP-520
F
2 Handle Rail..............................Part # RHR-520
G
2 Rear Brace............................ Part # RRB-520
H
1 Right Shooting Rail Arm..........Part # RRA-520
J
1 Left Shooting Rail Arm............. P art # RLA-520
K
1 Shooting Rail...........................Part # RSR-520
L
2 Platform Brace........................ Part # RPB-520
M
2 Yoke........................................Part # RY-520
N
1 Step.........................................Part # RS-520
O
1 Jaws...............................
P
1 Rail Cover............................... Part # RC-520
Q
1 Stabilizer Bar...........................Part # PXSB-555
2 Harness...................................
= NOT PICTURED IN THIS MANUAL
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
Top Ladder
A
Section (1)
Part # RTL-520
Part # RML-520
E
Foot Platform (1)
Part # RTJ-310
Part # 2020
H
Right Shooting Rail Arm (1)
K
Shooting Rail (1)
M
Yoke (2)
P
Rail Cover (1)
Middle Ladder
B C Bottom Ladder
Section (1)
Section (1)
F
Handle Rail (2)
J
L
N
Step (1)
Q
D
Seat Assembly (1)
G
Rear Brace (2)
Left Shooting Rail Arm (1)
Platform Brace (2)
O
Jaws (2)
Stabilizer Bar (1)
©2020 (rev. 1/20)
