Preferred™ Series
551J 04-06 Single Package Rooftop
Cooling Only/Electric Heat Unit
with Puron
(R-410A) Refrigerant
®
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . 1
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Rated Indoor Airflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Jobsite Survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Step 1 - Plan for Unit Location . . . . . . . . . . . . . . . . . . . . 9
Step 3 - Inspect Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Step 4 - Provide Unit Support . . . . . . . . . . . . . . . . . . . . . 9
• ALTERNATE UNIT SUPPORT (IN LIEU OF CURB OR
Step 5 - Field Fabricate Ductwork . . . . . . . . . . . . . . . . 11
Step 6 - Rig and Place Unit . . . . . . . . . . . . . . . . . . . . . . 11
(When Required) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Step 8 - Install Outside Air Hood . . . . . . . . . . . . . . . . . 13
Step 9 - Units with Hinged Panels Only . . . . . . . . . . . . 14
Step 11 - Make Electrical Connections . . . . . . . . . . . . 14
• THERMOSTAT
Economi$er® X (Factory Option) . . . . . . . . . . . . . . . . . . 28
• ENVIRONMENTAL
• INTERFACE OVERVIEW
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53551016-01
Installation Instructions
Printed in U.S.A.
Form II551J-4-6-02
Smoke Detectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Step 13 - Install Accessories . . . . . . . . . . . . . . . . . . . . . . 41
Step 14 - Check Belt Tension . . . . . . . . . . . . . . . . . . . . . 41
Pre-Start and Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . . . . .CL-1

SAFETY CONSIDERATIONS

Installation and servicing of air-conditioning equipment can be
hazardous due to system pressure and electrical components.
Only trained and qualified service personnel should install, re-
pair, or service air-conditioning equipment.
Untrained personnel can perform basic maintenance functions
of cleaning coils and filters and replacing filters. All other op-
erations should be performed by trained service personnel.
When working on air-conditioning equipment, observe precau-
tions in the literature, tags and labels attached to the unit, and
other safety precautions that may apply.
Follow all safety codes, including ANSI (American National
Standards Institute) Z223.1. Wear safety glasses and work
gloves. Use quenching cloth for unbrazing operations. Have
fire extinguisher available for all brazing operations.
It is important to recognize safety information. This is the safe-
ty-alert symbol
. When you see this symbol on the unit and
in instructions or manuals, be alert to the potential for personal
injury.
Understand the signal words DANGER, WARNING, CAU-
TION, and NOTE. These words are used with the safety-alert
symbol. DANGER identifies the most serious hazards which
will result in severe personal injury or death. WARNING signi-
fies hazards which could result in personal injury or death.
CAUTION is used to identify unsafe practices, which may re-
sult in minor personal injury or product and property damage.
NOTE is used to highlight suggestions which will result in en-
hanced installation, reliability, or operation.
WARNING
Electrical shock can cause personal injury and death. Shut
off all power to this equipment during installation. There
may be more than one disconnect switch. Tag all disconnect
locations to alert others not to restore power until work is
completed.
Pg 1
1-2020
Replaces: II551J-4-6-01
