  • Page 2 The rear width of the S12-2D can be changed through rear hubs and rear CVD modularity. The SWORKz S12-2D is equipped with a front sway bar and a completely new developed rear sway bar holder system.

  • Page 3: Specification

    Contact your local hobby shop or SWORKz distributor for all claims and questions. Claims must be well documented. All Claims are subject to expert examination approval by SWORKz.

  • Page 4: Required Equipment For Operation

    IN D E X INSTRUCTION Warranty INDEX Required Equipment for Operation Operation Guide Assembly Steps 7-26 Blank Set-up Sheet Set-up Sheet S12-2D Key No.List S12-2D Spare Part List S12-2D Option Part List Explosion view with spare parts number 32-35 End cover This radio controlled racing car is not a toy! This high-performance R/C model is recommended for ages 14 and older.
  • Page 5 R eq ui red Equ ip me nt fo r O p erat i o n Radio Gear Stick Type Receiver ESC system Steering servo Wheel & Trigger Type Breshless Motor Charger and LiPo Battery Tools Recommended Long nose pliers Side cutter 1.5mm Paint...

  • Page 6: Thread Locking Compound

    The S12-2D Pro Kit is not intended for children under the age of 14 without adult supervision. SWORKz shall not be held liable for any loss or damages, whether direct, indirect, act of nature, arising from abuse or misuse of this product or any other product required.
  • Page 7 Ball Diff. Paste 332021 (16pc) 116015 Ball Bearing 5x8x2.5mm 332022 116015 116013R Ball Bearing 10x15x4mm (Red Rubber Case) 330520 103004 M2.5mm Nut Lock 116013R 103004 332024 332025 Ball Diff. Paste 200490 116013R 115089 332023 332022 116015 2502403-01 Front Ball Diff. Setting Plate PRO TIP 2.0 mm Use a 2.0mm HEX tool to tighten the ball diff.
  • Page 8 220048 330283 332006 Pin M2x10mm 108006 108006 M3x8mm FH/ST HEX Screw 610013B08 332005A S12-2 Slipper Clutch Adjust Screw 2.4x60mm 108006 610013B08 332033 220031-81 332005A 332032 330283 106015 220042(#4) 116010R 354003-26 106015 M3x5mm Hex Socket OH/TP Screw 116010R 116010R Ball Bearing 5x10x4mm (Red Rubber Case) 116010R 332002 116010R...
  • Page 9 106002 115188 SWORKz 1/10 Slipper Clutch Spring (D1.4x12mm) 115189 SWORKz 1/10 Slipper Clutch Spring (D1.6x12mm) 332034 S12-2 Steel Slipper Clutch Spring Holder Washer 220048 220040 103001 106001 M3 Nut Lock 332034 106003 115188 115189 106001 220040 M3x8mm Hex Socket OH/TP Screw...
  • Page 10 BrushLess 540 Motor is not included is not included 104004 M3x3mm Set Screw 104004 101026 Washer M3x6xT1.5mm 330410 330410 SWORKz 1/10 Motor Pinion Gear 21T 106001 M3x8mm Hex Socket OH/TP Screw 101026 106001 101026 Paper for gear mesh. Paper for gear mesh.
  • Page 11 M3x4mm FH/ST HEX Screw 220042 106020 M2.5x5mm Hex Socket OH/TP Screw 330643 Steering Linkage Ball Stud 5mm 220042 101026 104004 SWORKz Aluminum Washer 3X6X1.5mm 104004 108006 108014 M3x3mm Set Screw 115172 330156A OPTION: SW-332028 S12-2 Aluminum Front Upper Arm Holder...
  • Page 12 116015 330331 220040 106002 M3x10mm Hex Socket OH/TP Screw 220040 330331 Steering Linkage Ball Stud 5mm 116015 116015 Ball Bearing 5x8x2.5mm 117003 332013 220040 101007 Flange Ball Bearing 3x6x2.5mm 101007 330331 Washer 3x8x0.5mm OPTION: 117003 SW-332045 S12-2 Aluminum Servo Savor Arms (2PC) 117003 SW-332046 S12-2 Aluminum Servo Savor Steering Plate...
  • Page 13 STEP 1. Please make sure that your steering servo is centered before mounting the servo saver horn. 2502401BK STEP 2. Only SWORKz original plastic servo horn (SW-2502401-BK) or aluminum servo horn (SW-330690/330692) can STEP 3. fit the steering system. Mount the servo saver horn in a 90 degree 108006 position onto the servo.
  • Page 14 M3 Nut Lock caster angles -5/-2.5/0/2.5/5. The less angle, the faster the 116010R response. 330643 Steering Linkage Ball Stud 5mm 342003 220047(#0) 116010R 116010R 332014 334020 Ball Bearing 5x10x4mm (Red Rubber Case) 220038 106017 101026 101026 SWORKz Aluminum Washer 3X6X1.5mm...
  • Page 15 220035 106014 M2.0x6mm Hex Socket OH/TP Screw 212001 338011 S12-2 Rear CVD Drive Shaft Set 62mm SWORKz Pinion Gear Stopper (5x7x5.1mm) 330283 Pin M2x10mm PRO TIP: Right The part 220046 has 3 Rear Hub Inserts that come in different types which offers several different rear hub angles.
  • Page 16 220047 106020 Right M2.5x5mm Hex Socket OH/TP Screw 104002 220036 101026 SWORKz Aluminum Washer 3X6X1.5mm 101026 220047 106020 220036 334022A 220036 Left 332007 108006 M3x8mm FH/ST HEX Screw OPTION: SW-362001 S12-2 15g Brass Rear Lower Arm Holder (RF) 108006 330525...
  • Page 17 104005 330156A M3x10mm Hex Socket OH/TP Screw 220042 106010 M3x6mm FH/ST HEX Screw 220040 101026 SWORKz Aluminum Washer 3X6X1.5mm OPTION: SSW-332029 S12-2 Aluminum Rear Upper Linkage Mount OPTION: SW-332044 S12-2 Aluminum Gear Box Support Mount 108003 M3x10mm FH/ST HEX Screw...
  • Page 18 (Upper Arm Linkage) (Upper Arm Linkage) 330300 Rear Upper Sus. Arm Turnbuckles (Steering Linkage) (Steering Linkage) OPTION: SWC-332049 SWORKz 1/10 Series Pro Titanium Linkage Turnbuckle M3X36mm(2PC) 18.0 mm 18.0 mm 2502401BK(#4) 2502401BK(#5) 330300 330643 Steering Linkage Ball Stud 5mm 330643 330300 Rear Upper Sus.
  • Page 19 Shock Washer 2.6x6x0.5mm Front 332037-DS Rear 332037-DL 220049-5 Shock Washer 3.0X6.3X0.9mm Front 332047-DS Rear 332047-DL 410049 400025 SWORKz 1/10 Series Pro Shock System Seal O-ring 410049 Shock Seal Cap O-ring 8x10x1mm 220049-5 220049-5 220049-1 400025 SWORKz 1/10 Precision Plastic Shock Piston(1.6X2Holes) 220049-5...
  • Page 20 Front Rear 108029 M2.0x4.6mm FH/ST HEX Screw (1.5mm HexHead) 220050-1 410047 410047 SWORKz Shock Cap O-Ring (SP) 108029 Slowly push the shock shaft to the end of shock cap. Then tight screw M2x4mm Front Front Rear 220023-1 Rear 115186 220023-1...
  • Page 21 105021 105021 M3x6mm Taper head screw 334002 108001 M3x12mm FH/ST HEX Screw 106005 M3x15mm Hex Socket OH/TP Screw 101020A 101020A 3mm Countersunk Washers (GM) 108001 334002 Aluminum Shock Cap Stud 106005 108001 105021 M3x6mm Taper head screw 101020A 108001 M3x12mm FH/ST HEX Screw 334002 106008 M3x12mm Hex Socket OH/TP Screw...
  • Page 22 104004 200193 ESC is not included ESC is not included 104004 M3x3mm Set Screw Receiver is not included Receiver is not included 108028 M2.6x4mm Flat Head Screw - Hex Socket 220042 PRO TIP: Forward Dirt Position 108028 106008 106008 220043 M3x12mm Hex Socket OH/TP Screw 106008 220043...
  • Page 23 106009 106002 106009 220043 220043 Li-po Shorty Peak is not included Li-po Shorty Peak is not included 106002 M3x10mm Hex Socket OH/TP Screw 106009 610024 M3x25mm Hex Socket OH/TP Screw 610024 103002 Flange M4 Nut Lock Tires and Wheels Tires and Wheels are Not included are Not included 103002...
  • Page 24 108007 101020A 108007 101020A M3x6mm FH/ST HEX Screw 252002-65 101020A 3mm Countersunk Washers (RD) 108003 M3x10mm FH/ST HEX Screw 250042 PRO TIP: 220024(#0) Part 220024 Rear Wing Mount Spacer can be adjusted to 3 different rear wing angles. (-3/0/3 degrees)
  • Page 25 Body shell painting preparation 252001 Use body scissors to cut along the body lines. Use water/washing solution to clean body. Apply window masks as shown. 252001 Paint body.
  • Page 26 Cut and put 0.8x5cm loop decal strap in same position as side Guard fillister. 540004A 540004A Cut and put 0.8x5cm hook decal strap in this side Guard fillister. Cut and put 0.8x3cm hook decal strap in this 540004B side Guard fillister. 540004B Cut and put 0.8x5cm hook decal strap...

  • Page 27: Set-Up Sheet

    Race time / Lap: Best lap: SET-UP SHEET Diff. Oil Diff. Type Track Conditions Name: Size: Open Med. Tight Rear: Date: Gear Diff Traction: High Med. Ball Diff Track: Surface: Smooth Med. Bumpy Tire Electric System Front Rear ESC Type: Motor Type: Type: Type:...
  • Page 28 Race time / Lap: Best lap: SET-UP SHEET Diff. Oil Diff. Type Track Conditions Name: Micha Widmaier Size: Open Med. Tight Rear: Date: Gear Diff 2021/7/18 Traction: High Med. Ball Diff Track: Med. Bumpy Surface: Smooth Tire Electric System Front Rear Maclan M32t Pro 160A ESC Type:...
  • Page 29 332037-DS SWORKz 1/10 Series Pro Shock System Shaft (DS-42.7mm) 2 SW-332037-DS 332037-DL SWORKz 1/10 Series Pro Shock System Shaft (DL-49.7mm) 2 SW-332037-DL 332047-DS SWORKz 1/10 Series Pro Shock Body for Longer Travel System(DS) 2 SW-332047-DS 332047-DL SWORKz 1/10 Series Pro Shock Body for Longer Travel System(DL) 2 SW-332047-DL 332042-25 S12-2C/D Full Edition Main Chassis 2.5mm 1 SW-332042-25...
  • Page 30 SWORKz 1/10 Series Pro Shock System Shaft (DS-42.7mm) SW-332037-DL SWORKz 1/10 Series Pro Shock System Shaft (DL-49.7mm) SW-332047-DS SWORKz 1/10 Series Pro Shock Body for Longer Travel System(DS) SW-332047-DL SWORKz 1/10 Series Pro Shock Body for Longer Travel System(DL) SW-332042-25 S12-2C/D Full Edition Main Chassis 2.5mm...
  • Page 31 S14-3 12mm Wheel Hex (6.7mm)(Option)(2PC) SW-334039 S14-3 12mm Wheel Hex (7.7mm)(Option)(2PC) SW-334047BK SWORKz T-7075 M4 Lightened Low Pro le Large-contact with Serrated Wheel Nuts (BK)(6pc) SW-334047GM SWORKz T-7075 M4 Lightened Low Pro le Large-contact with Serrated Wheel Nuts (GM)(6pc) SWC-115157 S14/S12 Black Competition Front Shock Spring (S4-Dot)(43X1.2X6.5)

  • Page 32: Shock Absorbers

    Pa r ts No. List E xpl o d ed Vi ew Shock Absorbers Front Rear 108029 108029 220050-1 220050-1 332047-DS 332047-DL 106014 106014 220049-1 220049-2 101011 101011 332037-DL 332037-DL 220049-5 400025 220049-5 400025 410049 330544 410049 330544 115186 115162 220023-1 2501807 330134...

  • Page 33: Front Suspension

    Front Suspension 108007 220044 108006 101020A 101012 101020A 106002 101026 252002-65 108006 101012 108006 106002 330331 101020A 106017 220039A 342004 108001 334002 105021 108003 106002 103002 220039A 105021 332014 106001 108003 116010R 2502401BK 330643 220038 101020A 104012 116010R 330300 2502401BK 2502401BK 2502401BK 116015...
  • Page 34 Pa r ts No. List E xpl o d ed Vi ew Chassis & Electronic Parts 250001 106002 106009 220043 106009 220043 106008 220042 106008 220043 220043 220193 610024 104004 220043 220037 220043 220037 332042-25 108006 108003 108006 108006 108003 108003 108028 108006...

  • Page 35: Rear Suspension

    Rear Suspension 103002 108003 220046 220024 106014 2502401BK 250042 330643 330300 338011 2502401BK 220036 116019R 116010R 334010 220038 220036 334022A 220036 220036 330283 2503210A 106020 212001 220024(#0) 220046 330525 220036 106008 106002 220044 2503210A 108001 101020A 104005 106010 220042 342005 330283 106010 106002...
  • Page 36 502001D Production No. 33D120209...

This manual is also suitable for:

S12-2
