GVision P12ES-L Specifications

1 2 . 1 " T F T L C D M o n i t o r 1 2 . 1 " T F T L C D M o n i t o r
POS Application
W h e r e W h e r e V e r s a t i l i t y V e r s a t i l i t y
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR 10)
Backlight
Lamp Life
Stand Base
Input Signals
Signal Connector Analog
Digital
Scan Frequency
Audio System
USB HUB
Touch Panel
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions ( W x H x D )
Carton Dimensions
Weight (Net)
Certification
* Specifications are subject to change without notice.
UNIT : mm
P12ES-J
GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w GVision Incorporated T E L : + 8 8 6 - 2 - 8 2 2 6 - 5 5 11 / FA X : + 8 8 6 - 2 - 8 2 2 6 - 5 5 3 3 / w w w. g v i s i o n . c o m . t w
M e e t s M e e t s F l e x i b i l i t y F l e x i b i l i t y
P12ES-LA
12.1" TFT active matrix panel
0.240(H) x 0.240 (V) mm
SVGA 800 x 600
150:1 (typical)
2
200 Cd/m (typical)
50 ms (typical)
262K
245.8(H) x 184.3(V)
90 (H) x40 (V)
CCFL x 1
10,000(hr)
o o
Tilt down: -5 , Tilt up: +60
Analogue VGA
D-sub 15 pin (VGA)
N/A
H. scan 31~54KHz,
V. scan 56 ~ 85Hz
1W/per channel driver (Option)
N/A
Resistive/Capacitive - RS232
or USB A type (option)
Power on/off with LED, Menu,
Select, Adjustment (+, - )
o o o o
5 C-35 C (41 F-95 F)
20%-80% (no condensation)
To 10,000 feet
o o o o
-20 C-60 C ( -4 F-140 F )
10%-90% ( no condensation )
Universal power adaptor
Input AC 100~240V, 50~60Hz;
Output DC 12V / 3A
25W
VESA DPMS standard
312 x 310 x 146 mm
390 x 410 x 240 mm
3.3 Kg
C-UL, FCC, CE
Mechanical drawing

Features :

* High contrast color TFT LCD display supports resolution
up to SVGA 800x600. Compatible with IBM VGA, VESA
standards.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* IP54 compliant front cover.
* Optional stable photo stand excellent for touch solution.
* Optional black & white housing.
* Optional touch solutions.
* Optional MSR holder.

Optional Accessories :

* 3M Resistive touch panel
* ELO Resistive touch panel
* Anti-Glare tempered glass.
* Customized touch solutions acceptable.
* MSR holder
* Photo stand

Ordering Information :

* P12ES-LA VGA only
* P12ES-JA VGA + photo stand
* P12PS-LA VGA + speakers
* P12PS-JA VGA + photo stand + speakers
I/O Ports
P12ES-L
P12BS-L
P12ES LA P12ES LA P12ES-LA
