INSTALLATION INSTRUCTIONS
NCR OPTIC 5 for Wayne Vista
Release 1.0
497-0513342
Issue B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Retrofit G6+InvencoLink and is the answer not in the manual?

Questions and answers

Related Manuals for Invenco Retrofit G6+InvencoLink

Summary of Contents for Invenco Retrofit G6+InvencoLink

  • Page 1 INSTALLATION INSTRUCTIONS NCR OPTIC 5 for Wayne Vista Release 1.0 497-0513342 Issue B...
  • Page 2 DCV-00203 Document Number Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Kit Part Number: 6001-0007-8801...

  • Page 3: Release History

    All rights reserved No part of this document may be copied or reproduced in any form without prior written consent from Invenco. Invenco has taken great effort to verify the accuracy of this document but assumes no responsibility for any technical...

  • Page 4: Table Of Contents

    DCV-00203 Document Number Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Contents Release History ........................2 Introduction ........................4 Tools Required ....................... 4 Installation Kit Contents ..................5 Safety & Compliance Information ................... 6 Preliminary Precautions ..................

  • Page 5: Introduction

    Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide 1 Introduction The documentation provides some basic guidelines for installing the Optic 5 / G6 Outdoor Payment Terminal (OPT). This Retro-Fit Kit can be installed into either Side A or Side B of a Wayne Vista dispenser;...

  • Page 6: Installation Kit Contents

    Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Installation Kit Contents Unpack the Retro-Fit Kit and check that all of the parts listed below are present. G6 OPT (IP0065), Mounted on RFK Door...

  • Page 7: Safety & Compliance Information

    Read, understand and follow this manual and any other labels or related materials supplied with the equipment. If you do not understand a procedure, call an Invenco Authorized Service Centre or Invenco Service Officer. It is imperative to your safety and the safety of others to understand the procedures...

  • Page 8: Follow The Regulations

    Replacement Parts Use only genuine Invenco replacement parts and retrofit kits on your installation. Using parts other than genuine Invenco replacement parts could create a safety hazard and violate local regulations.

  • Page 9: No Open Flames

    Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide 3.1.1 No Open Flames Open flames from matches, lighters, welding torches or other sources can ignite fuels and their vapors. 3.1.2 No Sparks - No Smoking Sparks from starting vehicles, starting or using power tools, burning cigarettes, cigars or pipes can also ignite fuels and their vapour.

  • Page 10: Approvals

    Invenco develops and maintains its hardware and software products using industry-standard quality processes, and is audited by various bodies. The Invenco G6 OPT has a UL File Reference of MH61528 and carries a label similar to this: 3.1.8 Laser Warning Some models of the G6 OPT incorporate a barcode reader.

  • Page 11: Installation Guide

    Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide 4 Installation Guide 1. Please ensure all safety procedures are followed per requirement by the customer before installing the retrofit kit. 2. Remove power to Pump and follow the OSHA Lock-out/Tag-out procedures.
  • Page 12 Document Number Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Security Bolts Fig. 2.1 – Wide Frame (top) - Side A of Electronics Bezel - Narrow Frame (bottom) Lower the electronics head bezel by pulling the top forward until it fully rests on the suspension cables.
  • Page 13 DCV-00203 Document Number Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Graphics Display Assembly Single Line Display Assembly Fig. 2.2 – Electronics Bezel in fully lowered position For the Graphic Display Assembly: Unplug the 8-pin display cable and the two-wire ribbon cable that are connected to the Graphic Display Assembly (Fig 2.3a):...
  • Page 14 DCV-00203 Document Number Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Two-Wire Ribbon Cable 8-pin Display Cable Fig. 2.3a – Location of both Graphics Display cables that will need unplugged For the Single Line Display: Unplug the 40-pin display cable and the two-wire grey cable that are connected to the Single Line Display Assembly (Fig 2.3b):...
  • Page 15 Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide For the Graphic Display Assembly: Locate and remove the (3) ¼” head mounting screws located along the bottom of the Graphic Display Assembly. (Fig 2.4a)
  • Page 16 DCV-00203 Document Number Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Variant rain catcher This screw may remain in place Remove this screw Fig. 2.4b – Location of the screw that needs removal Remove the ¼”...
  • Page 17 Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Remove and retain this screw Fig. 2.5.1 – Remove Totalizer Window Screw (Narrow Frame only) Fig. 2.6 – Grab the card reader and remove the assembly Remove the Printer Assembly 1) Slide the printer forward until it stops.
  • Page 18 Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Fig. 2.7 – Printer in the fully pulled-out position 2) Unplug both cables from the back of the printer. (Fig. 2.8) Printer Cables Fig. 2.8 – Remove both printer cables 3) Lift up on the release tab inside the printer assembly and firmly pull the printer forward to remove it.
  • Page 19 Document Number Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Printer Release Lever Fig. 2.9a – Location of Printer Release Tab Fig 2.9b – Printer Slide after Printer has been removed 4) Set the printer aside to be discarded.
  • Page 20 Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Loosen the two Philips retaining screws under the water catch tray (if installed): Water catch tray screws Fig. 2.10 – Loosen water catch tray screws then remove the water catch tray by lifting it up and out of the electronics cabinet.
  • Page 21 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide A Printer Bracket Screws B Fig 2.12 – Side A & Side B Printer Bracket Screws (Wide Frame) 2) Cut or unfasten any cord restraints or zip ties that may be fasten to the printer’s bracket. You may have to check for cable ties from both sides of the dispenser.
  • Page 22 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Remove the Printer Bracket in a Narrow Frame Pump. 1) Remove the two Philips head screws from each side of the Printer Bracket using the pictures as a guide.
  • Page 23 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Cut Zip-ties Fig 2.15 – Remove any zip-ties or cable restraints 3) Lift and remove the printer bracket from the electronics cabinet. Set it aside to be discarded.
  • Page 24 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide 1) Unplug all wiring that is attached to the Q-CAT board. The Purple/Brown cable is used for communications. It must be marked and retained for later use.
  • Page 25 Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide 3) Remove the Q-Cat Board and set it aside to be discarded. 4) Remove the data cables to the printer and Graphics Display Assembly. Cut any zip-ties and remove any cable restraints that may be present.
  • Page 26 DCV-00203 Document Number Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Graphics Printer Bracket Display Assembly Assembly Water Catch Tray Printer Assembly All removed components can be discarded (Narrow Frame set above)

  • Page 27: Pre-Installation Procedure

    Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Pre-Installation Procedure This Retro-Fit Kit does not include a communications method for the OPT. When this Retro-Fit Kit is being installed on Side A (i.e. the first side) of the dispenser, a communications method MUST first be installed.

  • Page 28: Installation Procedure

    Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Installation Procedure This section follows from the Disassembly procedure above, and assumes the pump is still open. References to “left-hand” and “right-hand” are as viewed into the pump on the Side you’re working on.
  • Page 29 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Fig. 3.2 – Side A – Patch Cable installation – Side B 3. Temporarily coil the loose ends of the four cables (Black low-voltage DC, Green/Yellow Earth, Red and Yellow patch) in the bottom of the pump cabinet.
  • Page 30 Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Fig. 3.3 – Bringing the frame through the opening 5. Turn the RFK door thru 90° and, while holding the OPT, gently manipulate the RFK frame into a flatter position over the opening, ensuring the three screw-holes are positioned at the ‘bottom’, i.e.,...
  • Page 31 Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Wiggle the RFK frame under the three lugs at the ‘top’, taking care moving it past the pump door retainer cable fastening (bolt on the left in the above photo). Note that the thickness of the sealing gasket will make the frame tend to sit quite high: Fig.
  • Page 32 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Fig. 3.7 – Close-up of the window frame 8. Then carefully work the rest of the RFK frame into the pump door opening: and press it down to seat it fully: Fig.
  • Page 33 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Note: DO NOT use the old screws from the pump door – they are too long. Fig. 3.9 – Frame screwed down 10. For Narrow Frame Dispensers; re-install the Totalizer Window screw that was removed in Step 10 of the Disassembly Procedure.
  • Page 34 Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Ground strap screw Fig. 3.10 – RFK earth cable attached 13. Remove the screws on the cable-retention bracket on the OPT (keep the screws):...
  • Page 35 Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide b. Connect the EK0129 RED and EK0131 YELLOW patch cables into the correct sockets on the OPT. The port numbers on the InvencoLink for each cable (e.g. LAN-1, RS232-1) must match the side you’re working on (e.g.
  • Page 36 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Use Cable Fig. 3.15 – Securing the cables 17. Further gather excess slack from the cables from Step 16 and secure them into a MF0046 self- adhesive cable clip.
  • Page 37 Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Fig. 3.18 – Sale Calculator opened down 20. Disconnect the mains input connector (4-Pin) on the left side of the Dispenser Electronics Module. 4-Pin Mains Fig.
  • Page 38 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Fig. 3.20 – First of two connections 22. Insert the other connector into the fixed connector on the Dispenser Electronics Module: Fig. 3.21 – Second of two connections 23.
  • Page 39 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Fig. 3.22 – Sale Calculator Power Supply Board and connections a. Unplug the connectors P5 & P6 from J5 & J6: Fig. 3.23 – P5 & P6 disconnected b.
  • Page 40 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Fig. 3.24 – Left (above) & right (top) screws to loosen Fig. 3.25 – Screw loosened c. Place the fish-paper insulator over the power supply board (under the cables terminated in P5 &...
  • Page 41 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Fig. 3.27 – Fully seat the insulator over the screws e. Tighten the four screws loosened in (b): Re-plug the connectors P5 & P6 into J5 & J6: Fig.
  • Page 42 Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide EK0126 Fig. 3.29 - Mains Cable connected to PSU Plate 27. Repeat Steps 1 and 3-26 for Side B. 28. For Side A only: a.

  • Page 43: Wiring Completion

    Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide EK0127 Fig. 3.31 – Two-Wire Cable connected to InvencoLink 29. Gather all loose wires (on both sides if necessary), neatly wrap them together with cable-ties and secure to the chassis.

  • Page 44: First Power-Up

    Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide 5 First Power-Up Once the installation is complete and the wiring is certified (if necessary), power may be applied. The G6 OPT takes a couple of minutes to complete its start-up phase, during which several information screens will be presented.
  • Page 45 DCV-00203 Document Number Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Step Description Photo reference Ensure the paper roll has a neat cut edge. Remove spindle from the paper holder position Insert roll in place – the paper tension flap is spring- loaded so you will need to apply some pressure.
  • Page 46 Sept. 2016 Date Released Revision Number/Security level R03 S2 Retrofit G6+InvencoLink Wayne Vista (US) Installation Guide Feed the paper through the terminal until it appears at the paper exit slot. Cut the paper using both feed buttons, and remove the cut length from the chute.

This manual is also suitable for:

G6 optIp0065
