ONFIGURATION

Detmining On Battery Runtime

The battery pack charges when connected to an uninterruptible power supply. Refer to the battery runtime tables for corresponding
recharge times. Do not expect full battery run capability during the initial charge period.

Battery Runtime Tables

Note: The recharge time is the approximate time it takes to get to 90% capacity from a complete discharge at a 50% load.
5000XHV model:
Load (W) Internal
50 6:49
100 4:50
200 3:00
300 2:09
400 1:39
500 1:20
600 1:07
700 0:57
800 0:50
900 0:44
1000 0:39
1200 0:32
1400 0:26
1600 0:22
1800 0:19
2000 0:17
2500 0:12
3000 0:09
3400 0:08
4000 0:06
4500 0:05
Recharge
3
Hours
Number of Battery Packs
+1 +2
18:03 31:32
12:51 22:29
8:03 14:06
5:47 10:10
4:30 7:54
3:39 6:26
3:04 5:24
2:38 4:39
2:18 4:04
2:02 3:37
1:50 3:15
1:30 2:41
1:16 2:17
1:06 1:59
0:58 1:45
0:52 1:33
0:40 1:13
0:32 1:00
0:25 0:50
0:23 0:43
0:20 0:38
9 15
14
+4
59:56
42:46
26:50
19:22
15:04
12:17
10:20
8:54
7:48
6:56
6:14
5:11
4:25
3:50
3:23
3:01
2:22
1:57
1:40
1:25
1:15
