'1:*9449-:8'8) 22( 51&>*7
• Xtreme Tuner • USB / SD Memory Card Ports
• Deckless • Front Panel Aux-In • Mini Chassis
SPECIFICATIONS
GENERAL
- Flip Down Detachable Face Panel
- LCD Display
- Illuminated Controls (Blue)
- ISO DIN Mounting
- ISO Wiring harness
- Mini DIN Chassis: 178W x 50H x 90Dmm
- 12 Volt DC (11-15V) Negative Ground
AUDIO CONTROL
- Rotary Encoder
- Electronic Volume / Balance / Bass / Treble
- Loud / Mute
- Front panel AUX-IN
- 4 Ch RCA Line Out - 4 Volt
- 4-Band DSP Settings
- Speaker Impedance 4-8 Ohm
- Max Power 40 Watts x 4 Ch
BLUETOOTH
- Bluetooth in Phone Mode
- External Microphone
- Phone Contacts / History
- Audio Streaming
+2&2 9:3*7
TUNER
- PLL Synthesized AM/FM Stereo
- Xtreme Long Range Tuner
- FM 87.5~108 MHz; AM 522~1710 KHz
- Interference Absorption Circuit
- 30 Station Presets - 18FM/12AM Memory
- Station Seek / Preset Scan / Auto Store
- Local / Distant Control
- Automatic or Manual Tuning
- Mono / Stereo
- Digital Clock
MULTIMEDIA
- USB Input: Front Panel
- SD / MMC Card Port: Behind Front Panel
- AUX-IN Socket: Front Panel
- iPod / MP3 Playback Through USB
- MP3 / WMA Player
- Intro / Repeat / Random Play
- Select Folder / Track, File or Character Search
- Compatible with audio output of most
iPod and MP3 players
DESIGNED FOR AUSTRALASIAN CONDITIONS
&= '9
Advertisement
Table of Contents
Related Manuals for Axis AX 1102BT
Summary of Contents for Axis AX 1102BT
- Page 1 '1:*9449-:8'8) 22( 51&>*7 +2&2 9:3*7 • Xtreme Tuner • USB / SD Memory Card Ports • Deckless • Front Panel Aux-In • Mini Chassis SPECIFICATIONS TUNER GENERAL - PLL Synthesized AM/FM Stereo - Flip Down Detachable Face Panel - Xtreme Long Range Tuner - LCD Display - FM 87.5~108 MHz;...
-
Page 2: Safety Precautions
Safety Precautions Please VZLWFK off this unit LPPHGLDWHO\ and VHHN Thank you for purchasing this product. SURIHVVLRQDO DVVLVWDQFH LI RQH RI WKH IROORZLQJ P l e a s e r e a d t h r o u g h t h e s e LQVWUXFWLRQV V\PSWRPV LV IRXQG so you will know how to operate \RXU PRGHO RTQRGTN[ .eep this manual in a safe place for... -
Page 3: Table Of Contents
Contents Features Safety Precautions WMA and MP3 Compatibility Features 7Q RNC[ DCEM 9/# CPF /2 NGU Panel Controls About WMA General Operation Tuner Operation The unit can play back WMA data. Windows Media and the Windows logo are USB/SD/MMC/MP3 Playback trade marks or registered trademarks of Playing MP3/WMA Files ... -
Page 4: Panel Controls
Panel Controls Power ON: Press to turn on the unit. ST/LOU Press VQ KR FQYP VJG RCPGN 1. - Power on #7: HTQPV CWFKQ KPRWV 'ZVGTPCN RGTKRJGTCN - Mute devices can be connected with the unit.) - Power off (press KROG) $6 /75+% 2. -
Page 5: General Operation
General Operation Power On/Off Button Display Selector (DISP) This unit can display the clock time, radio Press the button to SRZHU the unit frequenc\ or PTY type. Ordinarily, the radio when the vehicle ignition is on. Press frequency or MP3/WMA track indication is and hold the button to turn the unit off. -
Page 6: Tuner Operation
Tuner Operation USB/SD/MMC/MP3 Playback 1. Load SD/MMC Card Band Press DWVVQP VQ KR FQYP VJG RCPGN ,PUGTV During radio play, press the BAND button to the SD/MMC card into the slot, with the front choose between three FM and two $0 bands. side WR WKH right &lose the panel. -
Page 7: Playing Mp3/Wma Files
Playing MP3/WMA Files character and move to the next position. Display Information 4. Repeat for up to eight characters. During playback, ID3 tag information displayV 5. Press and hold the knob for 2 seconds to scrolling on the screen: FOLDER, FILE, begin the search. -
Page 8: Bluetooth Operation
Bluetooth Operation To dial a number directly, select DIAL NUM. Note: 1. Rotate the VOL knob to select phone For your safety, PLQLPLVH phone conversations PWODGT RTGUU /'07 DWVVQP VQ EQP TO DV much as possible while driving. - Press |<< button to delete a digit HQWHUed. - Press button to reset entered number. -
Page 9: Menu Function
Bluetooth Operation Menu Function Press the knob IRU more than 2 seconds to enter General Notes for Bluetooth WKH menu 7hen each press changes the mode as follows: 1. For some types of mobile phones, HYHQ — — — — — — — — — — — — — — — — — — — — after the FRQQHFWLRQ VHHPV VXFFHVVIXO WKH DSP mode unit still appearV to be ZDLWLQJ WR EH SDLUHG... -
Page 10: Device Connections
Device Connections Wiring Diagram Microphone Black Antenna Fuse 15A EN - 9... -
Page 11: Installation Guide
Installation Guide Device Connections Notes of connection Preparation 6Q CXQKF UJQTV EKTEWKV RI VJG GNGEVTKECN 1. Disconnect battery system, GLVFRQQHFW the negative battery Before you begin, Gisconnect the cable before installation. battery negative terminal. 6Q RTGXGPV UJQTV EKTEWKV KP VJG YKTKPI CPF damagH to this unit, secure all FDEOHV ZLWK Note: LQVXODWHG WHUPLQDOV or adhesive tape. - Page 12 Installation Guide 4. Place the unit in front of the dashboard to the sub-dashboard according to the opening so the wiring can be brought instructions in the installation kit. through the mounting sleeve. Follow the 3. Replace the dashboard trim panel. wiring diagram carefully and make certain all connections are secure and insulated ISO Installation...
-
Page 13: Anti-Theft System
Installation Guide Anti-Theft System This unit is equipped with a detachable panel ZKLFK Reset can be UHPRYHG and taken with you, KHOSLQJ WR deter theft. Removing the Panel 1. Switch off the power of the unit. 2. Press DWVVQP VQ KR FQYP VJG RCPGN 3. -
Page 14: Troubleshooting
Troubleshooting If you suspect something is wrong, immediately switch RII WKH power and FRQWDFW WKH GHDOHU ZKHUH you PDGH WKH purchase. Problem Possible cause Solution General Car ignition is not on. Turn your car key in the ignition. The unit will not switch Cable is not properly Check cable connection. -
Page 15: 5Rgek Ecvkqpu
5RGEK ECVKQPU General Power supply: 12VDC (11V-16V), Test voltage 14.4V, negative ground Maximum power output: 45W x 4 channels Continuous power output: 20W x 4 channels (4 10% T.H.D.) Suitable speaker impedance: 4-8ohm Pre-Amp output voltage: 4.0V (Play mode: 1KHz, 0dB, 10K load) Fuse: Dimensions (WxHxD):... - Page 16 Please complete details below in the event of warranty service being required. Purchaser’s Name: Purchaser’s Address: AX 1102BT Serial Number: Model Number: Date of Purchase: Dealer Name:...
