Smeg Universale LVS533PXIN User Instructions

Hide thumbs Also See for Universale LVS533PXIN:

Advertisement

Quick Links

Download this manual
Table of Contents

1.
Description of the controls ________________________________ 2

2.
Operating instructions __________________________________ 12

3.
Cleaning and maintenance ______________________________ 20

4.
Troubleshooting _______________________________________ 36
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need to use your dishwasher safely, correctly and in the
most satisfactory manner.
Following the cleaning instructions provided here will keep your
dishwasher's performance at peak levels in the long term.
USER INSTRUCTIONS: these consist of recommendations for using the
appliance, a description of its controls and of the correct cleaning and
maintenance procedures.




1

Advertisement

loading

Related Manuals for Smeg Universale LVS533PXIN

Summary of Contents for Smeg Universale LVS533PXIN

  • Page 1 Table of Contents     Description of the controls ________________________________ 2     Operating instructions __________________________________ 12     Cleaning and maintenance ______________________________ 20     Troubleshooting _______________________________________ 36 Thank you for choosing one of our products. You are advised to read this manual carefully; it contains all the information you need to use your dishwasher safely, correctly and in the most satisfactory manner.

  • Page 2: Description Of The Controls

    User instructions 1. Description of the controls Upper panel All the dishwasher controls are grouped on the upper panel. Switching on, programming, switching off etc. are only possible when the door is open. ON/OFF BUTTON OPTION BUTTONS/LIGHTS SELECTED PROGRAM BUTTONS/LIGHTS START/PAUSE BUTTON TOP DISPLAY (3 FIGURES) SALT WARNING LIGHT...
  • Page 3 User instructions Information shown on top display Example of screen and information provided 01.05 Estimated wash cycle duration and time remaining 1 h  Delayed start information CHECK E01  Error message h.3  Softener setting P0  Program cancellation Information shown on front display End of cycle message Estimated wash cycle duration and 01: 55...
  • Page 4 With the door closed, if the dishwasher is programmed but the start is not confirmed (cycle not confirmed, program interrupted, start not confirmed…) the name smeg appears on the display after about 10 seconds. WASH PROGRAM SELECTION AND SWITCHING-ON For selection of the most suitable program for the dishes to be washed, refer to the table below, which specifies the recommended type of wash, also considering the type of dishes and the degree of soiling.
  • Page 5 User instructions PROGRAMS TABLE DURATION CONSUMPTION PROGRAMME LOAD CROCKERY AND PROGRAM NUMBER CUTLERY PROGRESS MINUTES & SYMBOL WATER POWER LITRES KWh (1) 1 SOAK Recommended for rinsing 0,02 dishes while waiting for Cold prewash another wash cycle. 2 AUTO Wash cycle for normally When the "...
  • Page 6 User instructions EXPRESS TIME PROGRAMS (see relevant section for explanation of functioning modes) DURATION CONSUMPTION PROGRAMME LOAD CROCKERY AND PROGRAM NUMBER E CUTLERY PROGRESS MINUTES SYMBOL WATER POWER LITRES KWh (1) EXPRESS Quick wash cycle for 27’ lightly soiled dishes, Wash at 38°C 0,70 washed immediately after...
  • Page 7 User instructions NOTES AND REFERENCES Only run the soak program with half loads. Options cannot be used with the soak program. Dry assist is activated automatically if the selected program is compatible with the option. Standard programme under EN 50242. The Dry assist option must be enabled. See information sheet provided IEC/DIN reference programme.
  • Page 8 User instructions Wash programs Before starting a wash program, check that:  The water supply tap is open.  The softener container contains regenerating salt.  The correct amount of detergent has been added to the dispenser.  The baskets have been correctly loaded. ...
  • Page 9 User instructions As the program runs, the front display, which shows the program phases, will indicate the status of the cycle in progress. Prewash Wash Rinse Drying Warning: during the initial phase of the wash program the spray arms cannot be heard in operation because they start turning about 5 minutes after the start.
  • Page 10 User instructions DELAYING THE PROGRAM Allows you to program the dishwasher cycle to start during the required time period (e.g. night). Press the DELAY button to activate the option. A delay of 1 hour is shown on the display. Pressing the button repeatedly will allow you to select the required delay of up to 24 hours.
  • Page 11 User instructions TO SAVE ENERGY AND PROTECT THE ENVIRONMENT  Always try to use the dishwasher with a full load.  Do not wash the dishes in running water.  Use the wash program that is most appropriate for each type of load. ...

  • Page 12: Operating Instructions

    User instructions 2. Operating instructions Once the dishwasher has been correctly installed, prepare it for use as follows:  Adjust the water softening system  Add salt  Add rinse aid and detergent Using the water softening system The quantity of lime in the water (which indicates its hardness) causes whitish marks on dry dishes, which also tend to lose their shine over time.
  • Page 13 User instructions  Do not use table salt, as it contains insoluble substances which, over time, may damage the water softening system.  The salt container should be refilled when necessary before starting the wash program. This way, the excess saline solution will be immediately removed by the water;...
  • Page 14 User instructions WATER HARDNESS TABLE WATER HARDNESS SETTING German degrees (°dH) French degrees (°dF) 0 - 6 0 - 11 h.-0 NO SALT 7 - 10 12 - 18 h.-1 11 - 15 19 - 27 h.-2 16 - 21 28 - 37 h.-3 22 - 28...
  • Page 15 User instructions ADDING THE RINSE AID The rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining; it is automatically added to the water during the final rinse cycle, from the container situated on the inner side of the door. To add rinse aid: ...
  • Page 16 User instructions ADJUSTING THE RINSE AID DISPENSER MODE To access the programming environment it is necessary that the dishwasher is switched on and the door is open, at this point you must:  press the PROGRAM DELAY button until the b symbol appears on the display, followed by the number currently set (e.g.
  • Page 17 User instructions ADDING THE DETERGENT To open the detergent dispenser cover, lightly press button P. Add the detergent or tablet and close the cover by sliding it until it stops, indicated by a click. The dispenser will open automatically during the wash cycle. Only add the detergent (also in tablet form) if the dispenser is dry ...
  • Page 18 User instructions The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading.
  • Page 19 User instructions WARNING!  Make sure that the dishes are securely in place so that they cannot tip over or obstruct the rotation of the spray arms during the washing cycle.  Do not place very small objects in the baskets as these could fall and obstruct the spray arms or the wash pump.
  • Page 20 User instructions Using the baskets The dishwasher has a capacity of 13 place-settings, including serving dishes. LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest” items with a heavier degree of soiling. All types and combinations of loads are permitted, provided that the dishes, pots and pans are arranged with all the soiled surfaces...
  • Page 21 User instructions LOADING THE LOWER BASKET Carefully load flat plates, soup plates, dessert and serving dishes, positioning them vertically. Pots, pans and their covers must be loaded upside down. When loading soup plates and dessert bowls, be sure to leave a gap between them. Loading examples: UPPER BASKET The upper basket should be loaded with small or medium-sized items...
  • Page 22 User instructions CUTLERY BASKET The basket is suitable for all types of cutlery, except long items that may interfere with the upper spray arm. The cutlery should be arranged in the spaces in the upper racks to allow the water to pass effectively between the items.
  • Page 23 User instructions FLEXI DUO TOP RACK (on some models only) This comprises two independent sliding, pull-out tray racks for easier loading/unloading of cutlery. Various loading systems and configurations are possible. For example, tea cups can be loaded with the right-hand rack set in the low position, while the left-hand rack or both can be removed to allow large dishes to be put in the top basket.
  • Page 24 User instructions EXAMPLES OF LOADING FOR INTENSIVE DIRT 13 Standard place setting If the bottom basket inserts are of the fold-down type, they should be laid flat for easier loading. 13 Standard place setting FLEXI DUO TOP RACK (on some models only) If the bottom basket inserts are of the fold-down type, they should be laid flat for easier loading.
  • Page 25 User instructions UPPER BASKET EQUIPMENT (depending on the model) Cutlery tray For knives, spoons (tea and dessert) and long objects. The ends are designed to hold long stemmed glasses. - It can be removed by pressing and pushing the release levers (B) at the same time.
  • Page 26 User instructions Fold-down shelves For mugs, cups and long objects. The ends are designed to hold long stemmed glasses When not used they can be moved to a vertical position (until a click is heard). Shelves with expandable wings For small objects, mugs and cups. They can be used either closed or open (pull the upper, sliding part).
  • Page 27 User instructions Fold-down tines These can be secured in a vertical position, resting on the bottom of the basket if unused, or placed in an intermediate position, as required. The single tine on the right is ideal for supporting long stemmed glasses.
  • Page 28 User instructions ADJUSTING THE UPPER BASKET The height of the top basket can be adjusted to allow large dishes or pans to be placed in the bottom basket. The adjustment procedure may be type A or B, depending on the dishwasher model purchased.

  • Page 29: Cleaning And Maintenance

    User instructions 3. Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply or turn off the dual-pole dedicated switch. General warnings and recommendations Do not use acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft, damp cloth or with a normal detergent suitable for painted surfaces.
  • Page 30 User instructions  To remove the lower spray arm, simply lift it up, pulling by the central part.  To remove the orbital spray arm assembly, take hold of the longer arm and pull the orbital unit upward. Wash the arms under a jet of running water and return them carefully to their seat.
  • Page 31 User instructions CLEANING THE FILTER UNIT (models with planetarium sprayer)  It is advisable to periodically inspect the centre filter and, if necessary, to clean it.  remove the planetarium sprayer follow the instructions provided.  push the centre filter D from the underside to remove it from the micro- filter: ...
  • Page 32 User instructions BEFORE STARTING THE DISHWASHER AFTER PROLONGED DISUSE:  Check that there are no deposits of sludge or rust inside the water pipe: if there are, allow the water to run from the water supply tap for a few minutes. ...
  • Page 33 User instructions If the dishes fail to dry or remain dull, check that:  The rinse aid container is not empty  The rinse aid dispenser setting is correct  The detergent used is of good quality and has not lost its effectiveness (for example, through incorrect storage, with the box left open) If the dishes show signs of streaking, staining etc., check that:...
  • Page 34 User instructions Only for models with this type of lock. If the door does not close: 1 - Check the position of the door lock catch (D) 2 - If necessary, raise it by adjusting the plastic screw (V) next to the catch.
  • Page 35 User instructions If the problem persists after following the troubleshooting instructions above, call the nearest Authorised Service Centre. WARNING: any operations performed on the appliance by unauthorised technicians are not covered by the warranty and shall be paid for by the user.

  • Page 36: Troubleshooting

    User instructions 4. Troubleshooting The dishwasher has an autodiagnosis system capable of detecting and indicating a preset series of possible malfunctions. TABLE OF MALFUNCTIONS DETECTED BY THE AUTODIAGNOSIS SYSTEM FAULT DESCRIPTION Error 01 Anti-flooding system tripped (where installed). Error 02 The system that limits the water level in the dishwasher has been tripped.
