- Page 1 INSTRUCTION MANUAL DISHWASHER...
-
Page 2: Table Of Contents
Contents Safety and operating instructions __________________________ 34 Installation and hook-up _________________________________ 37 Description of the controls _______________________________ 39 Operating instructions __________________________________ 46 Cleaning and maintenance_______________________________ 57 Troubleshooting _______________________________________ 61 Thank you for choosing this product. We advise you to carefully read all the instructions contained in this manual, in order to understand how to operate your dishwasher safely and correctly. -
Page 3: Safety And Operating Instructions
Safety instructions 1. Safety and operating instructions THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE: IT MUST ALWAYS BE KEPT INTACT TOGETHER WITH THE DISHWASHER. BEFORE USING THE APPLIANCE, CAREFULLY READ ALL THE INSTRUCTIONS CONTAINED IN THIS MANUAL. INSTALLATION MUST BE PERFORMED BY A QUALIFIED TECHNICIAN, IN COMPLIANCE WITH THE REGULATIONS IN FORCE. -
Page 4: Safety Instructions
Safety instructions • AFTER INSTALLATION, THE PLUG MUST REMAIN ACCESSIBLE. • IN THE EVENT OF DAMAGE TO THE POWER CORD, HAVE IT REPLACED BY A QUALIFIED TECHNICIAN. • AFTER CHANGING THE POWER CORD, MAKE SURE THAT THE BRACKET WHICH SECURES THE CORD IS FIXED SECURELY IN PLACE. - Page 5 Safety instructions LEANING OR SITTING ON THE DISHWASHER DOOR WHEN OPEN MAY CAUSE THE APPLIANCE TO OVERTURN, PUTING PEOPLE AT RISK. DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE THE DISHES OR DISHWASHER AT THE END OF THE WASHING PROGRAM AND BEFORE THE DRYING CYCLE.
-
Page 6: Installation And Hook-Up
Installation instructions 2. Installation and hook-up Remove the polystyrene basket retainers. Position the appliance in the desired place of installation. The back or sides of the dishwasher may be placed up against walls or other furniture units. If the dishwasher is installed near a heat source, fit the special insulating panel to prevent overheating and malfunction of the appliance. -
Page 7: Installation Instructions
Installation instructions CONNECTING TO THE WATER SUPPLY Connect the intake hose to a cold water supply with ¾” gas thread, inserting the filter A supplied with the dishwasher. Take care to screw the hose firmly into place with your hands and then complete tightening about ¼... -
Page 8: Description Of The Controls
User instructions 3. Description of the controls 3.1 Front panel All the dishwasher controls are grouped on the front panel. ON/OFF BUTTON SELECTION PROGRAM BUTTONS (P1…P5) ECO DRYING CYCLE BUTTON DELAY PROGRAM BUTTON START/STOP BUTTON POWER ON LIGHT PROGRAM PHASE INDICATOR LIGHTS INFORMATION DISPLAY RECESSED DOOR HANDLE 3.2 Information display... - Page 9 DRYING PROGRAM SEL ECTION TYPE AND GRADE DIRT (OPTIONAL) PANS AND DISHES IN WAITING SOAK OF COMPLETING THE LOAD DISHES NOT MUCH DIRTY QUICK AND WITH "FRESH DIRT" WITHOUT RESIDU AL DRY PANS AND DISHES NOT VERY DIRTY BUT WITH DR Y RESIDUALS PANS AND DISHES DAIL Y WITH NOR MAL DIRT,...
-
Page 10: User Instructions
User instructions PROGRAMMING In this dishwasher model all the programming operations are possible only with closed door. With open door, on the DISPLAY (8) will appear the symbols -- and the PILOT LIGHT PROGRAMS (7) remains out. SELECTION PROGRAM By pressing the relative button of desired program (see table) it will lid up the relative pilot light to confirm that the operation did occurred on the DISPLAY (8) will appear a program duration forecasting (“h.mm”). - Page 11 User instructions INTERRUPTION OF A PROGRAM In order to interrupt a running program it is necessary: • to press the START/STOP (5) for some seconds until when the writting “Time to end” remains lit on the display (confirmation beep). At this point,it is possible to start the cycle again, otherwise: TO CHANGE A PROGRAM To change the running program it is necessary: •...
- Page 12 User instructions TABLE FOR CERTIFICATION BODIES Reference standard Reference program Load Type of detergent Amount of detergent Rinse aid setting The upper basket must be set in the low position. 3.3 Washing programs The dishwasher is equipped with a control panel and an INFORMATION DISPLAY (8) from which it is possible to carry out all the power switch- on, switch-off and programming operations.
- Page 13 User instructions DELAYING THE PROGRAM The PROGRAM DELAY button (4) can be pressed to delay the start of the program by up to 12 hours .. This means that the dishwasher can be operated at the time of day of your choice. The first time the PROGRAM DELAY button (4), is pressed the display will show 12 hours, the maximum delay time before the program will start.
- Page 14 User instructions TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT • Always try to run the dishwasher fully loaded. • Do not wash the dishes in running water. • Use the washing program that is most appropriate for each type of load.
- Page 15 User instructions To access the programming environment, the appliance must be turned on with the door open. Then proceed as follows: • press the ECO DRY (3) button until the H symbol appears on the display, followed by the number 3, > H3; •...
-
Page 16: Operating Instructions
User instructions 4. Operating instructions Once the dishwasher has been correctly installed, prepare for use as follows: • Adjust the water softening system; • Add the regenerating salt; • Add the rinse aid and detergent. 4.1 Using the water softening system The amount of scale contained in the water (water hardness index) can cause whitish staining on the dry dishes, which... - Page 17 User instructions • Do not use table salt as it contains insoluble substances which, over time, may damage the water softening system. • When necessary, refill the regenerating salt container before starting the washing program. In this way, the excess saline solution will be immediately removed by the water;...
- Page 18 User instructions WATER HARDNESS TABLE WATER HARDNESS German Degrees (°dH) 0 - 4 5 - 9 10 - 17 18 - 26 27 - 35 36 - 47 Contact your local water board for information on the hardness of your water supply.
- Page 19 User instructions ADDING THE RINSE AID The rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining; it is automatically added to the water during the final rinse cycle, from the container situated on the inner side of the door. To add rinse aid: •...
- Page 20 User instructions ADDING THE DETERGENT To open the detergent dispenser cap, lightly press the button P. Add the detergent and close the cap carefully. During the washing cycle, the dispenser will be opened automatically. • When a INTENSIVE program is selected, in addition to the normal dose of detergent, it is necessary to add an additional amount inside compartment G or H.
- Page 21 User instructions • The market offers liquid and powder detergents with differing chemical compositions, which may contain phosphates, or be phosphate-free but contain natural enzymes. - Detergents containing phosphates are more effective against grease and starch at temperatures above 60°C. - Enzyme detergents, on the other hand, are also effective at lower temperatures (from 40 to 55°C) and are biodegradable.
- Page 22 User instructions 4.3 General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading. There are generally no constraints on the washing of domestic dishes, but in certain cases it is necessary to take their characteristics into account.
- Page 23 User instructions Items which are not dishwasher-safe: • Wooden dishes, pots or pans: these may be damaged by the high washing temperatures. • Handcrafted items: these are rarely suitable for washing in a dishwasher. The relatively high water temperatures and the detergents used may damage them.
- Page 24 User instructions 4.4 Using the baskets The dishwasher has a capacity of 10 place-settings, including serving dishes. LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest” items with a heavier degree of soiling.
- Page 25 User instructions CUTLERY BASKET The cutlery should be arranged in an orderly manner inside the basket, with the handles pointing downwards. Take care during loading to avoid injury from the knife blades. The basket is suitable for all types of cutlery, except those long enough to interfere with the upper spray arm.
- Page 26 User instructions LOADING THE UPPER BASKET Load plates facing forward; cups, bowls etc. must always be facing downwards. The left-hand side of the basket can be loaded with two layers of cups and glasses. On the right plates and saucers can be slotted verticalli into the forks.
-
Page 27: Cleaning And Maintenance
User instructions 5. Cleaning and maintenance Before carrying out any work, always disconnect the appliance from the electrical power supply. 5.1 General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened with water or with a normal detergent suitable for painted surfaces. - Page 28 User instructions CLEANING THE SPRAY ARM, TRAVELLING VERSION To remove the TRAVELLING spray arm, take hold of it and raise it to release both the spray arm and the pipe from the tank, then detach the spray arm from the pipe. Wash both the pipe and the spray arm in running water, re-attach the spray arm to the pipe and return the assembly to the seat provided in the tank.
- Page 29 User instructions GENERAL WARNINGS AND RECOMMENDATIONS FOR CORRECT MAINTENANCE: • The filters should be cleaned under running water using a stiff brush. • It is essential to thoroughly clean the filters according to the above instructions: the dishwasher cannot function if the filters are clogged.
-
Page 30: Troubleshooting
User instructions If the dishes are not being cleaned properly, check that: • the correct amount of detergent has been added; • there is regenerating salt inside the special container; • the dishes are being loaded correctly; • the selected program is suitable for the dish types and their degree of soiling;... -
Page 31: Troubleshooting
User instructions 6. Troubleshooting The dishwasher is equipped with a self-diagnostics system that is capable of detecting and signalling a number of possible faults. TABLE OF FAULTS DETECTED BY THE SELF-DIAGNOSTICS SYSTEM FAULT The anti-flooding system (where present) has been tripped. E2 - E9 The water level limitation system has tripped. - Page 32 User instructions TECHNICAL DATA Width Depth measured flush with the outer edge of the control panel Height Capacity Water supply pressure Electrical characteristics 447 ÷ 449 mm Free standing: 600 mm Semi-integrated: 590 mm Free standing from 850 mm to 870 mm Semi-integrated from 820 mm to 870 mm 10 Standard place settings min.
- Page 33 820- 820- 1/2” S N SF 3/4” 0,3-10 bar 0,3-10 bar 1,14 m 1,14 m 1,23 m 1,23 m 1,78 m 1,78 m 0,3-10 bar 0,3-10 bar 1,25 m 1,25 m 1,50 m 1,50 m 1,66 m 1,66 m 3x16 820- 820-...
- Page 34 Superficie interna Superficie interna Surface interne Surface interne Inner surface Inner surface Innenfläche Innenfläche Lato superiore Lato superiore Bord supérieure Bord supérieure Upper edge Upper edge Oberkante Oberkante...
