CyberPower HT200W User Manual

2-Outlet Surge Protector 2-Outlet Surge Protector
HT200W HT200W
1
USER'S MANUAL
Copyright © 2017 Cyber Power Systems, Inc. All rights reserved.
CONGRATULATIONS ON YOUR PURCHASE
Thank you for selecting CyberPower HT200W Surge
Protector. The information contained in this brochure
explains the features and operation of the HT200W.
Please take a few moments to read this manual.
FEATURES
1. Surge Protected Indicator
Illuminated when the surge protection feature is working properly.
2. Two Side-Facing Standard Outlets
SPECIFICATIONS
• Model Number: HT200W
• Outlets:
2 Standard Outlets
• Surge Protection: 1,500 Joules
• Electrical Rating: 125V/15A/1875W
• UL Clamping Voltage: UL 1449 3rd/400V (L-N, L-G, N-G)
• Maximum Peak Current: 75,000A
• 3 AC Lines Protected: H-N:
N-G: 15,000A (The maximum surge possible on household
wiring is 6,000 volts)
• Response Time: Less than 1 nanosecond
2
• Attenuation: Up to 32dB
• EMI/RFI Filtration: 150 kHz to 100 MHz
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK - Use only
in dry locations and only indoors. DO NOT plug into
another relocatable power tap. DO NOT "daisy chain"
surge protectors. DO NOT use with any aquarium
equipment. DO NOT use if properly grounded outlets are
not available. DO NOT install this device if there is not at
least 10 meters (30 feet) or more of wire between the
electrical outlet and electrical service panel. This device
features an internal protection that will disconnect the
surge protective component at the end of its useful life,
but will maintain power to the load – now unprotected. If
this situation is undesirable for the application, follow the
manufacturer's instructions for replacing the device. The
conductors used to connect the SPD to the line or bus
and to ground shall not be any longer than necessary
and shall avoid unnecessary bends.
TROUBLESHOOTING
If the Protected indicator does not light, the surge
protector's AC lines is no longer protected from surge.
L-N: 45,000A, L-G: 15,000A,
Replace the surge protector. The surge protector may
have received a power surge or spike beyond its
specified limits that overloaded the protection circuitry
and rendered it inactive. The surge protector has
protected your connected equipment, but it will not
protect against future surges and spikes.
TECHNICAL SUPPORT
Please contact our Tech Support department with
installation, troubleshooting, or general product questions.
• Phone: 1-877-297-6937
• Email: tech@cpsww.com
• Hours of Operation:
1
Monday – Friday 7:00am – 6:00pm CST
