5.7

Using the rotating upper beam with side doors (option)

When using the rotating upper beam only door 3 and/or
door 4 may be opened.
The other doors should always be closed when the
rotating upper beam is used.
Secure door 3 and/or 4 using the door retainer.
When using the rotating upper beam the first bar should
always remain in position.
The other bars may be opened.
The other steps to be followed are described in the Knapen Trailers Users Manual.
5.8

Using the bars

Note: When the pin is released the bar may lower (±20cm).
Ensure a stable and safe position when performing the steps below.
Operation
Remove the locking device from the bar.
1
The pin can now be completely removed.
After the bar has been released, place the pin and
2
locking device back into the crossmember support.
Turn the bar completely away and hook it into the
3
designated holder.
User Manual EXSIDE EN - v202101
