5 Using the EXSIDE
5.4

Operating the liftable upper rail (option)

5.4.1
Manual pump
Step Operation
Remove the handle from the holder (1).
1
Insert the handle into the pump (2).
Place the pump lever in the desired position.
2
Start pumping.
Build up pressure (pump ±15 times).
3
Lift upper rail (pump ±15 times).
Stop at the desired or highest position.
5.4.2
Pneumatic pump
During operation, run the motor of the truck for the air supply.
Step Operation
Place the pump lever in the desired position.
1
Push the control lever to the right to lift or lower the
upper rail.
Build up pressure (±15 secs.).
2
Stop at the desired or highest position
(the pump will automatically stop).
12
Lift upper rail.
Lower upper rail.
Lift upper rail.
Lower upper rail.
2
1
