5.5

Closing the liftable upper rail (option)

Before lowering the upper rail, check that the entire load is inside the trailer.
Step
Lower the upper rail by operating the pump. See
1
CH 5.4 "Operating the liftable upper rail".
Release the mid post and roll it to the centre of the
2
trailer.
Release the handle of the post and place it in the
claw at the bottom (1).
3 Make sure the centring arrows align at the top (2).
Push the handle upwards until it is far enough in
the post and secured (3).
Make sure the locking slide block is properly
4
engaged and secured.
Pump another ± 4 times/secs. to fully engage the
5 upper rail at the front and rear.
See CH 5.4 "Operating the liftable upper rail".
Open the locking point (1) and fold the door
6
handle (2) away from the locking point.
Push the set of doors fully open, hold down the
7 locking device (1) and pull the set of doors to the
centre.
