User Manual
Pace 350/500 Electric Bicycle
(Throttle on Demand)
Thank you for purchasing the Aventon Pace350/500 Ebike.
We take pride in bringing you a quality product that will o˜er years of
enjoyment. Please read and understand this manual fully before
assembling and riding your bike. If you have questions after reading this
manual, please refer to the Aventon support or contact us by email or
give us a call.
We are here to help!
Aventon Support Center: https://www.aventon.com/pages/support
Email: info@aventon.com
Phone: 1-866-300-3311

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pace 350/500 and is the answer not in the manual?

Questions and answers

Related Manuals for aventon Pace 350/500

Summary of Contents for aventon Pace 350/500

  • Page 1 Please read and understand this manual fully before assembling and riding your bike. If you have questions after reading this manual, please refer to the Aventon support or contact us by email or give us a call. We are here to help! Aventon Support Center: https://www.aventon.com/pages/support...

  • Page 2: Table Of Contents

    USING THIS MANUAL GENERAL INFORMATION WARNINGS AND SAFETY SPECIFICATIONS ASSEMBLY INSTRUCTION BATTERY CHARGING (LOCK & REMOVAL) OPERATION MAINTENANCE TROUBLESHOOTING LIMITED WARRANTY LINK TO ASSEMBLY VIDEO AND ONLINE RESOURCES...

  • Page 3: Using This Manual

    Aventon recommends having a certified, reputable bike mechanic to check your work. NOTICE: If you do not have the experience, skill, and tools to complete assembly and fit, Aventon highly recommends having a certified, reputable bike mechanic complete these procedures as well as any future adjustments or tuning.
  • Page 4 Aventon. Do not attempt to true wheels or tighten spokes unless you have adequate knowledge, tools, and experience. Ensure the tires and inner tubes are in good working condition without any visual damage and have the correct amount of air pressure.

  • Page 5: Warnings And Safety

    ˛ Be careful at intersections and when preparing to pass other vehicles or cyclists. ˛ Familiarize yourself with all the features and operations of the bik e by Aventon Bikes. Practice and become proficient at shifting gears, applying the brakes, using the pedal assist system, and using the throttle in a controlled setting before riding in riskier conditions.
  • Page 6 ˛ Do not use this product with standard bik e trailers, stands, vehicle racks, or accessories that Aventon has not tested for safety and compatibility and have verified as safe and compatible with the bike.
  • Page 7 Helmets When riding a bike, always wear a properly fitted helmet that covers the forehead. Many locations require specific safety devices. It is your responsibility to familiarize yourself with the local laws, rules, and regulations where you ride and to comply with all applicable laws, including equipping yourself and your bike as the law requires.

  • Page 8: Specifications

    SPECIFICATIONS Model Name Aventon Pace 350 Max. Load Capacity 250lbs. / 113 kg Max.Speed 20MPH Motor 36V 350W Brushless Hub Battery 36V 417.6Wh Range Average Per Charge 35 Mile Average Wheel Size 27.5 x 2.20" Front / Rear Inflate to 30-50 PSI...
  • Page 9 SPECIFICATIONS Model Name Aventon Pace 350/500 Max. Load Capacity 250lbs. / 113 kg Max.Speed Configurable to 28MPH Motor 48V 500W Brushless Hub Battery 48V 556.8Wh Li-ion Range Average Per Charge 40 Miles Average Wheel Size 27.5 x 2.20" Front / Rear Tire pressure Inflate to 30-50 PSI...

  • Page 10: Assembly Instruction

    ASSEMBLY INSTRUCTION HANDLE BAR FRONT BRAKE THROTTLE SEAT DISPLAY REAR BRAKE SEATPOST CLAMP REAR WHEEL HUB MOTOR PEDAL FRONT WHEEL WHAT’ S IN THE BOX 1*Charger 1*Charger cable 2*Front/Rear Reflector 1*Spare Derailleur Hanger 1*Grease 1*Hex key 1*Wrench 1*Owner's manual 2*Reflector holder 1*Left pedal 1*Right pedal 1*Owners' manual...
  • Page 11 Assembly Instruction NOTICE: The following steps are only a general guide to assist in the assembly of your ebike and are not a complete or comprehensive manual of all aspects of assembly, maintenance, and repair. Consult a certified, reputable bike mechanic to assist with assembly, repair, and maintenance of your ebike. Step 1.
  • Page 12 B.Place the handlebar stem onto the stem with the display facing upwards, replace the top cap and use a 5mm hex key to secure the handlebar stem. Reinsert the rubber cover back into the top cap. Rubber Cover Step 4. Make sure the handle bars stay on the left side so after the handle bars are installed the cables come out of the frame to the left side of the bike.
  • Page 13 Step 6: Place the handlebar on the stem correctly. Center the handlebar and screw in the four stem faceplate bolts evenly, however do not tighten all the way down for further adjustment.（ For Pace 500 ） Step 7: Install the front wheel. A.Remove the plastic insert from the fork dropout.
  • Page 14 WARNING: an improperly secured front wheel and/or handlebar stem can cause loss of control, accidents, serious injury, or death. Check that the front wheel and handlebar stem are properly secured to the bike during assembly and before each ride. D.Use a 15mm open wrench to tight the wheel axle bolt to recommended torque value at 25-30 Nm. Step 8: Put the kickstand down to hold the bike up.
  • Page 15 C. Sit on the saddle, adjust display and handlebar to the desired position and tighten the screws which secure it to the handlebar. Step 9: Adjusting the display and handlebar ( For Pace 350) A.Stand in front of the bike and clamp front wheel with both legs, verify the handle bars are straight and in line with the front wheel.
  • Page 16 Step 10: Use 3mm hex key to tighten the display clamp to desired angle . Step 11: Pedal Installation. Use a pedal wrench to install the pedals. Locate the pedal with a smooth pedal axle exterior and an “R” stamped into the end of the pedal axle (1, below), which indicate it is the right pedal.
  • Page 17 Step 12: Remove motor protector and put on the motor protection guard on both sides of back wheel. Note: Part of plastic motor protector will likely break and be left in between the frame and the gears, use a pair of pliers to carefully remove it.
  • Page 18 Step 15: Adjusting the seat position and angle To change the angle and horizontal position of the seat: A.Use a 5mm Allen wrench to loosen the seat adjustment bolt on the clamp positioned directly underneath the seat, above the rear wheel. Do not completely remove the bolts. B.Move the seat backward or forward and tilt to adjust the angle.

  • Page 19: Battery Charging (Lock & Removal)

    Always charge your battery in temperatures between 50 °F – 77 °F (10 °C – 25 °C) and ensure the battery and charger are not damaged before initiating charge. If you notice anything unusual while charging, please discontinue charging and using the bike and contact Aventon Bikes Product Support for help.
  • Page 20 BATTERY CHARGING BEST PRACTICES AND INFORMATION ˛ Check the charger , charger cables, and battery for damage before beginning each charge. ˛ Be sure to charge in an area where it is clear and safe from any potential damage or tripping situations can occur while it is charging.
  • Page 23 You should wear an approved bicycle helmet every time you ride a bicycle, regardless of the legal requirement to do so. You should comply with local law when riding your Pace 350/500 E-Bike. BATTERY LEVEL INDICATOR (Current / Max / Average)

  • Page 24: Operation

    Aventon Bikes until you have adequate knowledge of its control and operation. Damage caused by failing to follow instructions is not covered under warranty and could result in serious injury or death. Contact Aventon Bikes if you have any questions about assembly or operation.

  • Page 25: Maintenance

    ˛ Do not park, store , or transport your bike from Aventon Bikes on a vehicle rack not designed for the bike s size and weight.
  • Page 26 Replace Weekly, - Check hardware for proper torque: See - Clean frame by wiping frame - Replace any components confirmed by Aventon Bikes 160-321 Recommended Torque Values chart. down with damp cloth. km (100- - Check drivetrain for proper alignment and - Use barrel adjuster(s) to tension Product Support or a cer�fied,...
  • Page 27 Safety Check Basic Steps 1. Brakes Ensure front and rear brakes work properly. Check brake pads for wear and ensure they are not overworn. Ensure brake pads are correctly posi�oned in rela�on to the rims. Ensure brake cables are lubricated, correctly adjusted, and display no obvious wear. Ensure brake levers are lubricated and �ghtly secured to the handlebar.
  • Page 28 Tire Information PACE 350/500 uses 27.5’’ x 2.2’’ rubber tires with inner tubes. The tires are designed for durability and safety for regular cycling activities and to be checked before each use for proper inflation and condition. Proper inflation, care, and timely replacement will help to ensure that your bike’ s operational characteristics will be maintained, and unsafe conditions avoided.

  • Page 29: Troubleshooting

    Reconnect or replace motor. Error Detection Your bike from Aventon Bikes is equipped with an error detection system integrated into the display and controller. In the case of an electronic control system fault an error code should display. The following error codes are the most common and can aid in troubleshooting.

  • Page 30: Limited Warranty

    LIMITED W ARRANTY...
  • Page 31 In order to exercise your right to receive a replacement for a Covered Component under this Limited Warranty, you must: ˛ Contact the A venton Product Support team by email at info@aventon.com or by phone at(866) 300-3311. The Product Support team will initially work with you on the problem with your ebike to identify potential simple fixes.

  • Page 32: Link To Assembly Video And Online Resources

    Please visit the “Support” section of the Aventon Bikes website ( https://www.aventon.com/pages/support) to view the o˝cial LEVEL Assembly Video . Online Resources For more information on best practices, please visit the Aventon Bikes website (www.aventon.com), Support ( https://www.aventon.com/pages/support), or contact Aventon Bikes Product Support with any questions.
