DOREL ASIA
Model No:
QUEEN METAL BED
DA3285
UPC CODE:
0-65857-16539-5
NOTE:
THIS INSTRUCTION BOOKLET
IMPORTANT
CONTAINS
SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
___________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer
service department. We will replace the part FREE of
charge.
NEED HELP!
Tel #: 1-800-295-1980
CALL US FOR ASSISTANCE
E-Mail: das@dorel.com
1-800-295-1980
DO NOT RETURN PRODUC
E-MAIL:DAS@DOREL.COM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dorel Asia QUEEN METAL BED DA3285
Summary of Contents for Dorel Asia QUEEN METAL BED DA3285
- Page 1 DOREL ASIA Model No: QUEEN METAL BED DA3285 UPC CODE: 0-65857-16539-5 NOTE: THIS INSTRUCTION BOOKLET IMPORTANT CONTAINS SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) ___________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
-
Page 2: Care And Cleaning
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. -
Page 3: Parts List
QUEEN METAL BED DA3285 Parts List HEADBOARD TOP HEADBOARD BOTTOM FOOTBOARD 1 PC 1 PC 1 PC SLAT SIDE RAIL (WITH 1 BRACKET) SIDE RAIL (WITH 2 BRACKETS) 2 PCS 2 PCS 3 PCS SUPPORT LEG 6 PCS... -
Page 4: Hardware List
QUEEN METAL BED DA3285 Hardware List M8 x 19mm M8 x 25mm M8 x 51mm HEX SOCKET HEAD BOLT HEX SOCKET HEAD BOLT HEX SOCKET HEAD BOLT 10 PCS 8 PCS 12 PCS INSIDE DIAMETER: Φ8.5mm INSIDE DIAMETER: Φ8.5 Φ8.5mm OUTSIDE DIAMETER: Φ16mm OUTSIDE DIAMETER: Φ22mm SPRING WASHER... - Page 5 QUEEN METAL BED DA3285 STEP 1 Attach the headboard top (A) to ● headboard bottom (B) with hex socket head bolts (1), spring washers (4) and metal flat washers (5). Use Allen Key (8) to tighten bolts. STEP 2 Attach the side rail (D1) to side rail ●...
- Page 6 QUEEN METAL BED DA3285 D2 & D1 STEP 3 Attach the assembled side rails to the ● headboard bottom (B) and footboard (C) with hex socket head bolts (2), spring washers (4), metal flat washers (5) and rubber flat washers (6). Use Allen Key (8) to tighten bolts.
- Page 7 QUEEN METAL BED DA3285 STEP 5 Place the slats (E) on the metal brackets ● of the side rails (D1&D2). Secure using hex socket head bolts (3), spring washers (4), metal flat washers (5) and nuts (7). Use Allen Key (8) & Allen Wrench (9) to tighten bolts and nuts.
- Page 8 QUEEN METAL BED DA3285 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Dust this item regularly with a soft, lint-free cloth to prevent soil build up.
-
Page 9: Customer Service
MODEL #: DA3285 Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name: Shipping Address:...
