Summary of Contents for ALIGATOR A431
- Page 1 Quick Guide A431...
-
Page 2: Table Of Contents
Contents Safety instructions........3 Putting into operation........5 Insert SIM, memory card and battery..5 Battery charging........6 Switch On / Off..........7 Mobile controls..........8 Making calls..........14 Contact list..........15 SOS call and SMS........16 SOS Locator ..........17 SMS messages........21 FM Radio..........21 Other functions........22 Mobile phone setting.......24 Security...........25 Safety and ecology........28 Used electric device........28... -
Page 3: Safety Instructions
Safety instructions Thank you for your purchase of the ALIGATOR mobile phone. Please read this instruction manual before use. Do not switch on nor use the mobile phone in the prohibited areas Do not use the mobile phone while driving... - Page 4 Turn off the mobile phone always near explosives Use always original batteries supplied by the producer (danger of damage or explosion of the mobile phone). Do not throw the battery in the fire nor expose it to the temperatures over +60°C. Danger of explosion or fire ! SAR –...
-
Page 5: Putting Into Operation
Keep it out of reach of children. It contains small parts that could be swollowed or may hurt Sometimes, the top of the external display, including battery and signal icons, may not appear. In this case, turn the phone off and on to display it correctly. -
Page 6: Battery Charging
Insert the battery. The three metal contacts must point toward the bottom part of the phone. Make sure that the battery clicks smoothly into the slot at the mobile phone. Put the battery cover back. ATTENTION! Turn off the phone and disconnect the charger when handling the battery, card or SIM card. -
Page 7: Switch On / Off
Mobile phone will warn you by an acoustic signal and by message on the screen when the battery is almost discharged. In this case charge the battery as soon as possible. Switch On / Switch Off to SWITCH ON the phone - press and hold the red button, till the phone turns on. -
Page 8: Mobile Controls
Mobile Controls... - Page 9 Button Function starts contacts in standby mode return from menu or Right exit current function functional other functions button depending on context (current function is shown on display above the key) displays Message in standby mode confirms selection in menu or activates Left selected function (OK) functional...
- Page 10 press Up in standby mode to display phone Navigation menu , press Down to button Up / display photo contacts Down -move in menu and in phone directrory long press to Switch On / Off -stop or reject a call Red button -return from the menu or exit current function...
- Page 11 inserts # when writing numbers in text writing mode toggles method of Button # character imput ong press to turn on/off silent mode „Meeting“ inserts *,+, p, w when writing numbers - in text writing mode Buttton enables to insert special characters Used for Earphone...
- Page 12 Powerful LED flashlight is placed Flashlight on the upper side of the phone Earphone For call listening -move up to turn on Flashlight the lantern switch -move down to turn off the lantern Stand For charging at the contacts charging stand...
- Page 13 Icons on the screen Battery charge level Signal strength Alarm clock activated Unread SMS message Ringing off - vibration Missed call...
-
Page 14: Making Calls
Making calls Dialing Insert required phone number on the mobile keypad and press the green button (5). Mobile will start to dial required number. In case 2 SIM cards are inserted in the phone, you will be asked before dialing the number which SIM card should be used for calling. -
Page 15: Contact List
Press the right button On/Off (1) while talking to activate the Handsfree function Contact list You can save phone numbers and assign names to your number. Contacts can be stored either on the SIM card or in the phone memory. Dialing from the contact list Press the right button (1). -
Page 16: Sos Call And Sms
SOS call and SMS Starting the emergecy call and SMS Press and hold the SOS button. An audible alarm sounds and a countdown begins, during which the emergency call can be interrupted. The phone will automatically dial the preset numbers from the list until they can reach one. -
Page 17: Sos Locator
SOS button, press the right button Off (1) and then turn the phone off and on again (restart). SOS function is only available if it is enabled in the settings of the phone and if the numbers are set up at the phone that the mobile should automatically call and send SMS message to. - Page 18 with an accuracy of tens to a few hundred meters, outside the buildings/cities but a focus accuracy usually decreases. This service is provided without any guarantee, at the own risk of an user and the accuracy of the results or the availability of services is not guaranteed by the supplier of telephone, operator or provider of maps.
- Page 19 Position of your mobile phone can be remotely detected by using of a special control SMS. It is sufficient to send just a command via SMS with a text SOSLOCATOR to your ALIGATOR mobile phone. Your ALIGATOR phone then responds by sending of the current position via SMS.
- Page 20 SOS Regime – allows to switch SOS functions. You can choose following options: Off – SOS functions, including SOS button, are off Normal - SOS calls and sending of emergency SMS are activated, but positioning is turned off ...
-
Page 21: Sms Messages
SMS messages Your phone can receive and send SMS text messages. The new message you receive will be notified by a symbol on the phone screen. A notification will appear on the screen if you have a new unread message. To view the message directly, just press the left button (2) and the message is displayed. -
Page 22: Other Functions
Press the volume buttons Up / Down (3) to adjust the volume You can change the frequency using the buttons 4 and 6 (automatic tunning) Press the button (5) repeatedly to turn the sound on / off. Press the Left button Options (2) to display the FM radio menu (manual and auto tuning, channel list etc.). - Page 23 Ringtone and sound settings The phone allows you to set different kinds of ringtones including vibration, different melodies, sounds and also the volume of these sounds. Select in menu : Settings Sound Mute the phone Hold # (7) to quickly activate the silent mode in which the phone vibrates instead of the ringer.
-
Page 24: Mobile Phone Setting
It is possible to transfer call sound or send files or receive files from another device. Select in menu: Organizer Bluetooth Multimedia – Music reply Allows you to replay music files, such as MP3, that you have placed on a memory card. Select in menu: Multimedia... -
Page 25: Security
Security Select in menu: Settings Security. Enables to set up the PIN code of the SIM card and phone password: 1. PIN – to set PIN of the SIM cards 2. Mobile Lock – enables to activate protection by a password 3. - Page 26 Selection of Network Select in menu to choose the network: Setting Network selection SIM1 /SIM2 You can now set up an automatic or manual selection of the operator (suitable for border areas, for example, to prevent unwanted roaming) Restore settings Select in menu: Settings...
- Page 27 PC connection The phone comes with a standard micro USB connector that can be used for both charging and connecting to a PC. ATTENTION! Requires the use of Windows 2000, XP, Vista, 7, 8, 10 and up! If you use other operating systems, you may need to use special drivers.
-
Page 28: Safety And Ecology
Mobile phone ALIGATOR A431 is intended to be used in the EU countries. Safety and ecology Used electric device Mobile phone is an electronic appliance. It means it must not be manipulated as a common residential waste. Never throw the used device... -
Page 29: Declaration Of Conformity
+60°C. Danger of explosion or fire. Declaration of conformity ADART COMPUTERS s.r.o. declares that the type of ALIGATOR A431 radio device is in compliance with Directive 2014/53 / EU. www.aligator.cz Copyright © 2018 ADART COMPUTERS s.r.o. , CZ-Prague...
