ACCESS PROCEDURES

ACCESS PROCEDURES
LOAD MONITORING SYSTEM (LMI)
LOAD MONITORING SYSTEM (LMI)
This systems has been conceived and developed to offer two different levels of functionality
of access to internal data, according to the actions to be done.
The basic access level (Operator) does not need any password; this one, in fact, is
required for possible assistances, only by Technical Service Personnel (failure detecting
and repairing).
1° LEVEL:
OPERATOR:
Without needing PASSWORD (also see OPERATOR MANUAL) all working information of
the machine are available through several monitoring given by the display panel; starting
from basic working data: lifted load, max admitted load, outreach, working conditions, tilting
percentage;
Just pressing the GREEN button key, it is possible to show machine working data in a
graphic way.
The aim to give to the Operator the possibility of entering these readings, allowing to
communicate them to the Technical Assistance Department, giving relevant data, possibly
avoiding a direct Service on site.
The Operator can also find some information to solve easy troubles in his OPERATOR
MANUAL
2° LEVEL: (PASSWORD) SENSORS REPLACEMENTS :
TECHNICAL ASSISTANCE DEPT. AND AUTHORIZED DEALERS
The second level corresponds to the information contained in this TROUBLE SHOOTING
MANUAL, where all details referred to system components are included (Main Unit,
Transducers, Display Panel), troubleshooting codes introduction, and the useful information
to remove the problems without specific tools (except a voltmeter).
As far as Pressure Transducers are concerned, please note that they do not need any
calibration, as they are totally interchangeable.
FINE CALIBRATION.
This means the complete machine calibration, that is done at the first start-up of the
machine.
To this aim a PASSWORD is given, allowing to enter into the functions of the program, as
the fine calibration of geometrical data and lifted load, and to perform their on-site
calibration. These calibrations need the use of a PC.
