SJE Rhombus 123 Installation And Operation Manual

Single phase duplex capacitor start/run

Advertisement

Quick Links

Parts Included
For information regarding operation,
?
available options, or servicing
questions, please call SJE Rhombus
Technical Support.
Manufactured by: SJE Rhombus
x4
This control panel must be installed and serviced by a licensed electrician in
accordance with the National Electric Code NFPA-70, state and local electrical codes.
UL Type 4X enclosures are for indoor or outdoor use.
For complete terms and conditions, please visit www.sjerhombus.com.
Products returned must be cleaned, sanitized, or decontaminated as necessary
prior to shipment to ensure that employees will not be exposed to health
hazards in handling said material. All applicable laws and regulations shall apply.
Technical support: +1 800-746-6287
techsupport@sjerhombus.com
www.sjerhombus.com
Technical Support Hours: Monday-Friday, 7 A.M. to 6 P.M. Central Time
Single Phase Duplex
Capacitor Start/Run
Installation and Operation Manual
Warranty void if panel is modified.
SJE Rhombus offers a five-year limited warranty.
Model 123
x3
or
x4
Control panel may be
ordered with or
without these items.
PN 1009560F 06/20
©2019 SJE, Inc. All Rights Reserved.
SJE RHOMBUS is a trademark of SJE, Inc
1
