SJE Rhombus Installer Friendly Series Installation Instructions And Operation/Troubleshooting Manual

SJE-Rhombus
Installation Instructions and Operation/Troubleshooting Manual
Warranty void if panel is modifi ed.
Call factory with servicing questions:
1-800-RHOMBUS
(1-800-746-6287)
Manufactured by:
22650 County Highway 6  P.O. Box 1708
Detroit Lakes, Minnesota 56502 USA
1-888-DIAL-SJE (1-888-342-5753)
Phone: 218-847-1317  Fax: 218-847-4617
E--mail: customer.service@sjerhombus.com
Website: www.sjerhombus.com
©SJE-Rhombus
Printed in USA
1036677 • Rev B 12/14
Installer Friendly Series
Type IFS w/C-Level
®
This control panel must be installed and serviced by a
licensed electrician in accordance with the National Electric Code
NFPA-70, state and local electrical codes. All conduit running from
the sump or tank to the control panel must be sealed with conduit
sealant to prevent moisture or gases from entering the panel. NEMA
4X enclosures are for indoor or outdoor use, primarily to provide
a degree of protection against corrosion, windblown dust and rain,
splashing water and hose-directed water. Cable connectors must
be liquid-tight in NEMA 4X enclosures.
The C-Level sensor is suitable for use in sewage applications.
Do NOT use in potable water.
Installation
Installer Friendly Series
pump(s). The controller records number of pump cycles, elapsed run
time, alarm counts, and signal error counts.
Mounting the Control Panel
Note: The control panel should not be mounted in a location that may
be subject to submersion.
1. Determine mounting location for panel. If distance exceeds the
length of either the sensor or fl oat cables or the pump power
cables, splicing will be required. Note: For splicing C-Level cord,
use only shielded cable. Splice conductors as well as shielding.
Maximum total cable length is 300 feet. For outdoor or wet instal-
lation, we recommend the use of an SJE-Rhombus
junction box with liquid-tight connectors to make required connec-
tions. You must use conduit sealant to prevent moisture or
gases from entering the panel.
2. Mount control panel with mounting devices furnished.
3. Determine conduit entrance locations on control panel. Check
local codes and schematic for the number of power circuits re-
quired. (Sensor cable requires separate conduit from power
and pump cables.)
Note: Be sure the proper power supply voltage, amperage, and phase
meet the requirements of the pump motor(s) being installed. If in
doubt, see the pump identifi cation plate for voltage/phase require-
ments.
4. Drill proper size holes for type of connectors being used.
Note: If using conduit, be sure that it is of adequate size to pull the
pump cable(s) through.
5. Attach cable connectors and/or conduit connectors to control
panel.
FOR INSTALLATION REQUIRING A SPLICE, FOLLOW STEPS 6-10;
FOR INSTALLATION WITHOUT A SPLICE, GO TO STEP 11.
®
™
®
(IFS) control panels are designed to control
Sensor
® liquid-tight
