In the field "Num Bytes" it is possible to select define the dimension of the SNMP data;
In the field "Conversion" it is possible to select the conversion to apply to the data read/written from/to the SNMP Agent;
If the field "Cancel" is checked, if the answer to the SNMP request is missing, the data on EtherCAT side are set to '0';
If SNMP version is set to '3', the following fields must be set:
In the field "User" the user for the SNMP authentication is defined;
o
In the field "Auth
o
In the field "Priv
o
In the field "Security
o
In the field "Auth
o
In the field "Priv
o
In the field "Mnemonic" a description of the data inserted in the row is defined.
Note:
If the field "On change" and "On Timer" is checked and the "Poll Time" is different from 0, the converter sends the SNMP writing
request cyclically and also when the data is changed.
Note:
If the "Trap" mode is used, the fields "On Change" and "On Timer" must be disabled.
ADFweb.com S.r.l.
Pass" the password for the SNMP aithentication is defined;
Pass" the password for Privacy authentication is defined;
Level" the type of security used is defined;
Mode" the mode used for the authentication is defined;
Mode" the mode used for Privacy is defined;
