Sauder 413044 Instruction Booklet

Entertainment wall system
Hide thumbs

Advertisement

Quick Links

Download this manual
413044
Entertainment
Wall System
PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English .................... Page 1-18
Français ...............Pages 19-21
Made in the USA
Espanol .............Páginas 22-24
Archbold, OH
Lot #: 367569
Date Purchased: ____________________
12 / 09 / 14

Advertisement

loading

Related Manuals for Sauder 413044

Summary of Contents for Sauder 413044

  • Page 1 413044 Entertainment Wall System NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE CONTACT US PLEASE READ AND KEEP FOR FUTURE REFERENCE. BEFORE RETURNING English ....Page 1-18 YOUR UNIT TO THE STORE Français ....Pages 19-21 Made in the USA 1-800-523-3987 Espanol .....Páginas 22-24...
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 50 pounds. Never use with a TV that weighs more.

  • Page 3: Part Identification

    SMALL RIGHT END UPRIGHT LOWER BACK LARGE LEFT END BOTTOM ADJUSTABLE SHELF SMALL LEFT END UPPER SHELF LARGE SKIRT LARGE RIGHT UPRIGHT TV SHELF BRACE SMALL RIGHT UPRIGHT LOWER SHELF SMALL SKIRT LARGE LEFT UPRIGHT SMALL SHELF 413044 www.sauder.com/services Page 3...

  • Page 4: Hardware Identification

    (Refer to the last step for proper location and application) BLACK 1-7/8" FLAT HEAD SCREW - 56 BROWN 7/16" LARGE HEAD SCREW - 27 Screws are shown actual size. You may receive extra hardware with your unit. Page 4 www.sauder.com/services 413044...
  • Page 5 Then, insert the metal end of a CAM DOWEL (V2) into each HIDDEN CAM. Push sixteen HIDDEN CAMS (U2) into the LARGE ENDS (A and C), LARGE UPRIGHTS (E2 and G2), SMALL ENDS (B and D), and SMALL UPRIGHTS (F2 and H2) as shown in the lower diagram. 413044 www.sauder.com/services Page 5...
  • Page 6 Finished edge Finished edge Finished edge BLACK 1-7/8" FLAT HEAD SCREW (4 used in this step) Fasten the LARGE UPRIGHTS (E2 and G2) to the UPPER SHELF (K). Use four BLACK 1-7/8" FLAT HEAD SCREWS (FF). Page 6 www.sauder.com/services 413044...
  • Page 7 Finished edge Finished edge BLACK 1-7/8" FLAT HEAD SCREW (8 used in this step) Fasten four SMALL SHELVES (N) to the LARGE UPRIGHTS (E2 and G2). Use eight BLACK 1-7/8" FLAT HEAD SCREWS (FF). 413044 www.sauder.com/services Page 7...
  • Page 8 Tighten Arrow Risk of damage or injury. Hidden Cams must be completely Arrow Maximum tightened. Hidden 210 degrees Cams that are not completely tightened Minimum may loosen, and parts 190 degrees may separate. To completely tighten: Page 8 www.sauder.com/services 413044...
  • Page 9 Fasten the UPPER BACK (O) to the UPPER SHELF (K) and LARGE UPRIGHTS (E2 and G2). Use five BLACK 1-7/8" FLAT HEAD SCREWS (FF). Fasten the LARGE ENDS (A and C) to the SMALL SHELVES (N). Use eight BLACK 1-7/8" FLAT HEAD SCREWS (FF). 413044 www.sauder.com/services Page 9...
  • Page 10 BLACK 1-7/8" FLAT HEAD SCREW (8 used in this step) Fasten the SMALL ENDS (B and D) and SMALL UPRIGHTS (F2 and H2) to the remaining SMALL SHELVES (N). Use eight BLACK 1-7/8" FLAT HEAD SCREWS (FF). Page 10 www.sauder.com/services 413044...
  • Page 11 Position SMALL ENDS (B and D) and SMALL UPRIGHTS (F2 and H2) as shown in the lower diagrams. Fasten the SMALL SKIRTS (T) to the SMALL ENDS (B and D) and SMALL UPRIGHTS (F2 and H2). Use eight BROWN 7/16" LARGE HEAD SCREWS (GG) through the ANGLE BRACKETS (Y). 413044 www.sauder.com/services Page 11...
  • Page 12 H I D Finished edge Unfi nished edge Maximum Arrow 210 degrees Minimum 190 degrees Position SMALL UPRIGHTS (F2 and H2) as shown. Fasten the BOTTOM (J) to the SMALL UPRIGHTS (F2 and H2). Tighten four HIDDEN CAMS. Page 12 www.sauder.com/services 413044...
  • Page 13 Position SMALL ENDS (B and D) and SMALL UPRIGHTS (F2 and H2) as shown in the lower diagrams. Fasten the LARGE SKIRT (R) to the BOTTOM (J) and SMALL UPRIGHTS (F2 and H2). Use five BROWN 7/16" LARGE HEAD SCREWS (GG) through the ANGLE BRACKETS (Y). 413044 www.sauder.com/services Page 13...
  • Page 14 Fasten the LOWER SHELF (M) to the SMALL UPRIGHTS (F2 and H2). Use four BLACK 1-7/8" FLAT HEAD SCREWS (FF). NOTE: Be sure the METAL PINS (Z) in the UPRIGHT (I) insert into the holes in the LOWER SHELF (M). Page 14 www.sauder.com/services 413044...
  • Page 15 Finished edge Carefully turn the lower portion of your unit onto its finished edges as shown. Fasten the LOWER BACK (P) to the BOTTOM (J) and LOWER SHELF (M). Use four BLACK 1-7/8" FLAT HEAD SCREWS (FF). 413044 www.sauder.com/services Page 15...
  • Page 16 NOTE: Be sure the METAL PINS (Z) in the UPRIGHT (I) insert into the holes in the LOWER SHELF (M). Be sure the CAM DOWELS (V) in the LOWER BACK (P) insert into the holes in the TV SHELF (L). These HIDDEN CAMS will be tightened in the next step. Page 16 www.sauder.com/services 413044...
  • Page 17 LARGE ENDS (A and C) and LARGE UPRIGHTS (E2 and G2). Set the ADJUSTABLE SHELVES (Q) onto the METAL PINS. Center a SCREW COVER (CC) over the head of each SCREW and press firmly. Push a CAM COVER (X) onto each visible HIDDEN CAM. 413044 www.sauder.com/services Page 17...
  • Page 18 To help prevent the TV from sliding, place the ANTI-SKID PAD (DD) under the front support of the TV or divide among the front supports if more than one. NOTE: Please read the back pages of the instruction booklet for important safety information. This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. Page 18 www.sauder.com/services 413044...

  • Page 19: Liste De Pièces

    GG VIS MARRON TÊTE LARGE ARRIÈRE INFÉRIEUR .....1 et conserver le livret 11 mm ..........27 TABLETTE RÉGLABLE ....4 pour future référence. Pour contacter Sauder GRANDE PLINTHE ......1 en ce qui concerne cet ENTRETOISE ........2 élément, faire référence PETITE PLINTHE ......2 au numéro de lot et...
  • Page 20 MONTANTS (E2 et G2). Serrer quatre EXCENTRIQUES l'assemblage ! ESCAMOTABLES. • Cette unité Sauder est conçue pour les téléviseurs Fixer les deux ENTRETOISES (S) aux GRANDS pesant moins de 22,6 kg. Ne jamais utiliser avec des MONTANTS (E2 et G2), à la TABLETTE téléviseurs plus lourds.
  • Page 21 fi gurant sur les pages arrière du manuel GRANDES EXTRÉMITÉS (A et C) et les GRANDS d’instructions. MONTANTS (E2 et G2). Ceci complète l'assemblage. Nettoyer à l’aide d’une encaustique pour meubles ou d’un chiffon humide. Essuyer. 413044 www.sauder.com/services Page 21...

  • Page 22: Lista De Partes

    CABEZA GRANDE de 11 mm ..27 ESTANTE AJUSTABLE ....4 Si necesita ponerse en contacto con FALDÓN GRANDE ......1 Sauder en cuanto a RIOSTRA .........2 esta unidad, refi érase al número de lote y FALDÓN PEQUEÑO ......2 al número de modelo cuando llame a nuestro número gratis.
  • Page 23 GRANDES (E2 y G2). Apriete cuatro EXCÉNTRICOS diagrama abajo - antes de comenzar el ensamblaje! ESCONDIDOS. • Esta unidad Sauder está diseñada para ser usada con Fije dos RIOSTRAS (S) a los PARALES GRANDES (E2 televisores cuyo peso sea inferior a 22,6 Kg. Nunca la y G2), al ESTANTE SUPERIOR (K) y ESTANTE DEL use para un televisor de mayor peso.
  • Page 24 NOTA: Por favor, lea las páginas de atrás del folleto de GRANDES (E2 y G2). instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 24 www.sauder.com/services 413044...
  • Page 25 équipé. • Blessure physique. Le mobilier peut être mobilier. très lourd. • Ne pas pousser le mobilier, surtout sur la moquette. Se faire aider par une autre personne pour soulever l’élément et le mettre en place. 413044 www.sauder.com/services Page 25...
  • Page 26 • Lesión física. El mobiliario puede ser • No empuje la unidad, especialmente muy pesado. sobre un piso alfombrado. Pide la ayuda de otra persona en levantar la unidad y colocarla en lugar. Page 26 www.sauder.com/services 413044...

  • Page 27: Year Limited Warranty

    4. La présente garantie ne s’applique qu’aux défauts garantis qui se produisent des composantes de mobilier Sauder. Le mot « défaut », tel qu’il est utilisé sous pour la première fois et qui sont signalés à Sauder dans les limites de ouverture les termes de la présente garantie, comprend les imperfections des pièces qui...
  • Page 28 Archbold, Ohio, where it all began. Certifi cate of Conformity The Sauder name on the box ensures that 1. This certifi cate applies to the Sauder Woodworking Product indentifi ed by this Instruction Book. the item you have purchased is made with 2.
