Sauder 413123 Assembly

Dresser
Hide thumbs

Advertisement

Quick Links

Download this manual
413123
Dresser
PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English .................... Page 1-18
Français ...............Pages 19-21
Made in the USA
Espanol .............Páginas 22-24
Archbold, OH
Lot #: 357469
Date Purchased: ____________________
11 / 15 / 13

Advertisement

loading

Related Manuals for Sauder 413123

Summary of Contents for Sauder 413123

  • Page 1 413123 Dresser NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE CONTACT US PLEASE READ AND KEEP FOR FUTURE REFERENCE. BEFORE RETURNING English ....Page 1-18 YOUR UNIT TO THE STORE Français ....Pages 19-21 Made in the USA 1-800-523-3987 Espanol .....Páginas 22-24 Archbold, OH www.sauder.com...
  • Page 2 ASSEMBLY TOOLS REQUIRED Part Identifi cation .......3 No. 2 Phillips Screwdriver Hardware Identifi cation .....4 Tip Shown Actual Size Assembly Steps ....5-18 Français ......19-21 Hammer Espanol ....... 22-24 Safety ......... 25-26 Warranty ........27 Scissors Page 2 www.sauder.com/services 413123...

  • Page 3: Part Identification

    Use this PART IDENTIFICATION to help identify similar parts. RIGHT END SKIRT LEFT END LARGE DRAWER FRONT UPRIGHT LARGE DRAWER BACK LARGE DRAWER SIDE BOTTOM DRAWER BOTTOM BACK SMALL DRAWER FRONT DOOR SMALL DRAWER BACK ADJUSTABLE SHELF SMALL DRAWER SIDE 413123 www.sauder.com/services Page 3...

  • Page 4: Hardware Identification

    SILVER 7/8" MACHINE SCREW - 10 BLACK 9/16" LARGE HEAD SCREW - 21 BLACK 1/2" FLAT HEAD SCREW - 28 NAIL - 40 Screws are shown actual size. You may receive extra hardware with your unit. Page 4 www.sauder.com/services 413123...
  • Page 5 Assemble your unit on a carpeted fl oor or on the empty carton to avoid scratching your unit or the fl oor. Push six HIDDEN CAMS (R) into the ENDS (A and B) and UPRIGHT (C). Then, insert the metal end of a CAM DOWEL (S) into each HIDDEN CAM. 413123 www.sauder.com/services Page 5...
  • Page 6 NOTE: The SLIDES are marked "RIGHT" and "LEFT" for easy identification. The SLIDES marked "RIGHT" will fasten to the RIGHT END (A) and the SLIDES marked "LEFT" will fasten to the UPRIGHT (C). There are also arrows on the SLIDES for correct positioning on the ENDS. Page 6 www.sauder.com/services 413123...
  • Page 7 Tighten Risk of damage or Arrow Arrow injury. Hidden Cams Maximum must be completely 210 degrees tightened. Hidden Cams that are not Minimum completely tightened 190 degrees may loosen, and parts may separate. To completely tighten: 413123 www.sauder.com/services Page 7...
  • Page 8 (2 used in this step) Fasten the BOTTOM (E) to the UPRIGHT (C). Use two BLACK 1-7/8" FLAT HEAD SCREWS (BB). Fasten A METAL BRACKET (T) to the TOP (D). Use a BLACK 9/16" LARGE HEAD SCREW (FF). Page 8 www.sauder.com/services 413123...
  • Page 9 (4 used in this step) 190 degrees Fasten the ENDS (A and B) to the TOP (D). Tighten four HIDDEN CAMS. Fasten the ENDS (A and B) to the BOTTOM (E). Use four BLACK 1-7/8" FLAT HEAD SCREWS (BB). 413123 www.sauder.com/services Page 9...
  • Page 10 NOTE: Be sure the edges of the METAL BRACKETS are even with the edges of the BOTTOM and SKIRT. Fasten the SKIRT (I) to the ENDS (A and B) and BOTTOM (E). Use five BLACK 9/16" LARGE HEAD SCREWS (FF). Page 10 www.sauder.com/services 413123...
  • Page 11 Fasten the BACK (F) to your unit using the NAILS (HH). NOTE: Be sure to tap NAILS into the holes that line up over the UPRIGHT (C). NOTE: Perforations have been provided for access through the BACK. Carefully cut out the holes needed. 413123 www.sauder.com/services Page 11...
  • Page 12 NOTE: You may need to loosen the mounting screw to slide the HINGE slightly out of the slot. Retighten the screw before mounting the HINGE to the END. Fasten a PULL (V) to the DOOR (G). Use two SILVER 7/8" MACHINE SCREWS (DD). Repeat this step for the other DOOR (G). Page 12 www.sauder.com/services 413123...
  • Page 13 Tighten the screws after making adjustments. To adjust the DOORS in or out (depth), loosen the mounting screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. 413123 www.sauder.com/services Page 13...
  • Page 14 Slide the DRAWER BOTTOM (M) into the grooves in the LARGE DRAWER SIDES (L) and LARGE DRAWER BACK (K). Repeat this step for the other drawers. The small drawer will use the DRAWER SIDES (P) and DRAWER BACK (O). Page 14 www.sauder.com/services 413123...
  • Page 15 Fasten the PULL (V) to the LARGE DRAWER FRONT (J). Use two SILVER 7/8" MACHINE SCREWS (DD). Repeat this step for the other drawers using the SMALL DRAWER FRONT (N). The small drawer will only use two DRAWER FRONT BRACKETS (W). 413123 www.sauder.com/services Page 15...
  • Page 16 With a hammer, gently tap four SHELF SNAPS (Z) into the holes in the ADJUSTABLE SHELF (H). Page 16 www.sauder.com/services 413123...
  • Page 17 SHELF (H) onto the METAL PINS so the SHELF SNAPS are resting on the METAL PINS. Push on the ADJUSTABLE SHELF until each METAL PIN "snaps" into the SHELF SNAPS. NOTE: If you wish to change the location of the ADJUSTABLE SHELF, tap the SHELF up with the palm of your hand. 413123 www.sauder.com/services Page 17...
  • Page 18 Peel the APPLIQUES from the APPLIQUE CARD (X). Stick the APPLIQUES over the heads of each visible SCREW in the ENDS (A and B). NOTE: Please read the back pages of the instruction booklet for important safety information. This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. Page 18 www.sauder.com/services 413123...

  • Page 19: Liste De Pièces

    CÔTÉ DE PETIT TIROIR ....2 et conserver le livret CC VIS NOIRE TÊTE GOUTTE pour future référence. DE SUIF 38 mm ......12 Pour contacter Sauder DD VIS ARGENTÉE À en ce qui concerne cet MÉTAUX 22 mm ......10 élément, faire référence VIS ARGENTÉE TÊTE...
  • Page 20 Resserrer la vis avant de monter la CHARNIÈRE à l’EXTRÉMITÉ. Fixer une POIGNÉE (V) à la PORTE (G). Utiliser deux VIS ARGENTÉES À MÉTAUX 22 mm (DD). Répéter cette étape pour l'autre PORTE (G). Page 20 www.sauder.com/services 413123...
  • Page 21 CONSOLES DE DEVANT DE REMARQUE : Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’aide d’une encaustique pour meubles ou d’un chiffon humide. Essuyer. 413123 www.sauder.com/services Page 21...

  • Page 22: Lista De Partes

    CC TORNILLO NEGRO DE Si necesita ponerse CABEZA REDONDA de 38 mm ..12 en contacto con DD TORNILLO PLATEADO Sauder en cuanto a PARA METAL de 22 mm ....10 esta unidad, refi érase TORNILLO PLATEADO DE al número de lote y CABEZA REDONDA de 19 mm ..12...
  • Page 23 SUPERIOR (D). Utilice un TORNILLO NEGRO DE Fije un TIRADOR (V) a la PUERTA (G). Utilice dos CABEZA GRANDE de 14 mm (FF). TORNILLOS PLATEADOS PARA METAL de 22 mm (DD). Repita este paso para la otra PUERTA (G). 413123 www.sauder.com/services Page 23...
  • Page 24 MÉNSULAS DE CARA DE CAJÓN (W). instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 24 www.sauder.com/services 413123...
  • Page 25 équipé. • Blessure physique. Le mobilier peut • Ne pas pousser le mobilier, surtout sur la être très lourd. moquette. 413123 www.sauder.com/services Page 25...
  • Page 26 • No empuje la unidad, especialmente • Lesión física. El mobiliario puede ser sobre un piso alfombrado. muy pesado. Page 26 www.sauder.com/services 413123...

  • Page 27: Year Limited Warranty

    4. La présente garantie ne s’applique qu’aux défauts garantis qui se produisent des composantes de mobilier Sauder. Le mot « défaut », tel qu’il est utilisé sous pour la première fois et qui sont signalés à Sauder dans les limites de ouverture les termes de la présente garantie, comprend les imperfections des pièces qui...
  • Page 28 Archbold, Ohio, where it all began. Certifi cate of Conformity The Sauder name on the box ensures that 1. This certifi cate applies to the Sauder Woodworking Product indentifi ed by this Instruction Book. the item you have purchased is made with 2.
