Sauder 413118 Instruction Booklet

Sauder 413118 Instruction Booklet

Starter kit hanover closets collection
Hide thumbs

Advertisement

Quick Links

Download this manual
413118
Starter Kit
Hanover Closets Collection
PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English .................... Page 1-20
Français ...............Pages 21-23
Made in the USA
Archbold, OH
Espanol .............Páginas 24-27
Lot #: 354641
Date Purchased: ____________________
07 / 10 / 13

Advertisement

loading
Need help?

Need help?

Do you have a question about the 413118 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sauder 413118

Summary of Contents for Sauder 413118

  • Page 1 413118 Starter Kit Hanover Closets Collection NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE CONTACT US PLEASE READ AND KEEP FOR FUTURE REFERENCE. BEFORE RETURNING English ....Page 1-20 YOUR UNIT TO THE STORE Français ....Pages 21-23 Made in the USA...
  • Page 2 El herraje de fi jación debe ser clasifi cado para proveer una resistencia mínima a la tracción de 22.6 kg. Page 2 www.sauder.com/services 413118...
  • Page 3 FIXED SHELF D239 DRAWER SIDE SHELF DRAWER BOTTOM UPPER SECTION LOWER SECTION DRAWER D239 D239 HARDWARE IDENTIFICATION CLOSET ROD KIT - 1 ROD - 3 ROD HANGER - 6 BLACK 9/16" FLAT HEAD SCREW - 12 413118 www.sauder.com/services Page 3...
  • Page 4 SILVER 1/2" MACHINE SCREW - 2 BROWN 7/16" LARGE HEAD SCREW - 4 GOLD 5/16" FLAT HEAD SCREW - 8 NAIL - 64 Screws are shown actual size. You may receive extra hardware with your unit. Page 4 www.sauder.com/services 413118...
  • Page 5 Assemble your unit on a carpeted fl oor or on the empty carton to avoid scratching your unit or the fl oor. Push sixteen HIDDEN CAMS (P2) into the ENDS (A and B), and FIXED SHELVES (D). Then, insert the metal end of a CAM DOWEL (O2) into each HIDDEN CAM. 413118 www.sauder.com/services Page 5...
  • Page 6 Fasten the CABINET RIGHT (35DA) and CABINET LEFT (35DB) to one of each END (A and B). Use four GOLD 5/16" FLAT HEAD SCREWS (EE). See the DRAWER KIT 068-1672 instruction book for fastening CABINET RAILS to these optional holes. Page 6 www.sauder.com/services 413118...
  • Page 7 Tighten Arrow Risk of damage or injury. Hidden Cams must be completely Arrow Maximum tightened. Hidden 210 degrees Cams that are not completely tightened Minimum may loosen, and parts 190 degrees may separate. To completely tighten: 413118 www.sauder.com/services Page 7...
  • Page 8 Fasten the RIGHT END (A) to the FIXED SHELF (D) and BRACE (K). Tighten two HIDDEN CAMS. NOTE: Be sure the PINS in the BRACE insert into the holes in the END. Repeat this step for the LOWER SECTION. Page 8 www.sauder.com/services 413118...
  • Page 9 Fasten the TOP (C) to the ENDS (A and B) without the CABINET RAILS. Tighten four HIDDEN CAMS. Fasten the SHELF (E) to the ENDS (A and B) with the CABINET RAILS. Tighten four HIDDEN CAMS. 413118 www.sauder.com/services Page 9...
  • Page 10 Use a hammer to drive a PROPEL NUT (X) into the holes in the ENDS (A and B) in the LOWER SECTION with CABINET RAILS. Now, turn an ADJUSTABLE GLIDE (T) clockwise completely into each PROPEL NUT. Page 10 www.sauder.com/services 413118...
  • Page 11 NOTE: Be sure the edges of the ANGLE BRACKETS are even with the edges of the ENDS and TOP. Fasten the TOP MOLDING (M) to the ENDS (A and B) and TOP (C). Use three BLACK 9/16" LARGE HEAD SCREWS (DD). 413118 www.sauder.com/services...
  • Page 12 Fasten the DRAWER FRONT (G) to the DRAWER FRONT BRACKETS (BB). Use four BLACK 7/16" LARGE HEAD SCREWS (HH). Slide the DRAWER BOTTOM (J) into the grooves in the DRAWER SIDES (D239) and DRAWER FRONT (G). Page 12 www.sauder.com/services 413118...
  • Page 13 Flip the drawer over and insert four CLIPS (Y) into the groove in the DRAWER BACK (H) and wrap them over the DRAWER BOTTOM (J). Tap a NAIL (GG) through each CLIP. NOTE: The CLIPS should set in about 1” from the DRAWER SIDES. 413118 www.sauder.com/services Page 13...
  • Page 14 D239 Roller end D239 GOLD 5/16” FLAT HEAD SCREW (4 used in this step) Fasten the DRAWER RIGHT (35DC) and DRAWER LEFT (35DD) to the DRAWER SIDES (D239). Use four GOLD 5/16" FLAT HEAD SCREWS (EE). Page 14 www.sauder.com/services 413118...
  • Page 15 SILVER 1/2" MACHINE SCREW (2 used in this step) (2 used) Fasten the PULL (AA) to the DRAWER FRONT (G). Use two SILVER 1/2" MACHINE SCREWS (FF) through the WASHERS (II) and into the PULL (AA). 413118 www.sauder.com/services Page 15...
  • Page 16 Push ten HOLE PLUGS (W) into the front unused CABINET RAIL holes in each END (A and B). NOTE: Do not plug the holes for the CABINET RAILS in the lower section, if you purchased extra DRAWER KITS 068-1672. Page 16 www.sauder.com/services 413118...
  • Page 17 Fasten two TIE PLATES (Z) to the back edges of the ENDS (A and B). Use four BLACK 9/16" LARGE HEAD SCREWS (DD). With someone's help, move the unit against the closet back wall near its final position. 413118 www.sauder.com/services...
  • Page 18 BLACK 9/16" LARGE HEAD SCREW (DD) through the BRACKET and into the TOP. Repeat this step to fasten the remaining SAFETY BRACKETS along the top of the UPPER SECTION and ENDS of the LOWER SECTION. Page 18 www.sauder.com/services 413118...
  • Page 19 Place the RODS onto the ROD HANGERS by inserting the holes in the ends of the RODS over the posts on the ROD HANGERS. Pull down firmly. Repeat this step to fasten and hang the remaining RODS in the CLOSET KIT. 413118 www.sauder.com/services Page 19...
  • Page 20 See the DRAWER KIT #412914 and SHELF KIT #412913 instruction book for fastening them to the STARTER KIT. NOTE: Please read the back pages of the instruction booklet for important safety information. This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. Page 20 www.sauder.com/services 413118...
  • Page 21 DD VIS NOIRE TÊTE LARGE 14 mm ..14 PLATE 14 mm ......12 pour future référence. VIS DORÉE TÊTE PLATE 8 mm ..8 Pour contacter Sauder 35DA ÉLÉMENT DROITE .......1 en ce qui concerne cet VIS ARGENTÉE À 35DB ÉLÉMENT GAUCHE .....1 élément, faire référence...
  • Page 22 DE TIROIR (H) et les enrober sur le FOND DE TIROIR (J). Enfoncer un CLOU (GG) à travers chaque CLIP. REMARQUE : Les CLIPS devraient être situés environ 25 mm des CÔTÉS DE TIROIR. Page 22 www.sauder.com/services 413118...
  • Page 23 CONSOLE DE SÉCURITÉ (R). Forcer légèrement en Ceci complète l'assemblage. Nettoyer à l’aide d’une encaustique pour tournant le VIS NOIRE TÊTE LARGE 14 mm (DD) dans le meubles ou d’un chiffon humide. Essuyer. DESSUS (C). 413118 www.sauder.com/services Page 23...
  • Page 24 Si necesita ponerse TORNILLO DORADO DE CABEZA en contacto con 35DA GABINETE DERECHO ....1 PERDIDA de 8 mm ......8 Sauder en cuanto a 35DB GABINETE IZQUIERDO ....1 esta unidad, refi érase TORNILLO PLATEADO PARA 35DC CAJÓN DERECHO .......1 al número de lote y METAL de 13 mm ......2...
  • Page 25 INMÓVIL (K) y a la RIOSTRA (K). tres TORNILLOS NEGROS DE CABEZA GRANDE de NOTA: Asegúrese de insertar las ESPIGAS DE METAL 14 mm (DD). sujetadas a la RIOSTRA dentro de los agujeros del EXTREMO. Repita este paso en la SECCIÓN INFERIOR. 413118 www.sauder.com/services Page 25...
  • Page 26 PERDIDA de 8 mm (EE). PASO 11 Fije el TIRADOR (AA) a la CARA DE CAJÓN (G). Utilice dos TORNILLOS PLATEADOS PARA METAL de 13 mm (FF) a través las ARANDELAS (II) y dentro del TIRADOR (AA). Page 26 www.sauder.com/services 413118...
  • Page 27 NOTA: Por favor, lea las páginas de atrás del folleto de SECCIÓN INFERIOR. instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. 413118 www.sauder.com/services Page 27...
  • Page 28 • TVs can be very heavy. Plus the a television. • Setting TVs on furniture items not weight and location of the picture tube intended tends to make TVs unbalanced and to support them is hazardous. prone to tipping forward. Page 28 www.sauder.com/services 413118...
  • Page 29 • Les téléviseurs peuvent être très lourds. téléviseurs sur des meubles qui ne sont De plus, le poids et l’emplacement du tube pas prévus à cet effet. image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’avant. 413118 www.sauder.com/services Page 29...
  • Page 30 • Es peligroso colocar los televisores sobre Además, el peso y la ubicación del tubo de muebles que no están diseñados para imagen tienden a causar la inestabilidad de soportar un televisor. televisores y hacerlos propensos a volcarse hacia adelante. Page 30 www.sauder.com/services 413118...
  • Page 31 4. La présente garantie ne s’applique qu’aux défauts garantis qui se produisent des composantes de mobilier Sauder. Le mot « défaut », tel qu’il est utilisé sous pour la première fois et qui sont signalés à Sauder dans les limites de ouverture les termes de la présente garantie, comprend les imperfections des pièces qui...
  • Page 32 Archbold, Ohio, where it all began. Certifi cate of Conformity The Sauder name on the box ensures that 1. This certifi cate applies to the Sauder Woodworking Product indentifi ed by this Instruction Book. the item you have purchased is made with 2.
