- Page 1 VPC3+ Evaluation Kit (Order No.: PA006300) Revision 2.00 Th e Cl ever Al t er n a t i ve...
- Page 2 We gratefully accept suggestions for improvements. Copyright Copyright © profichip GmbH 2005. All Rights Reserved. Unless permission has been expressly granted, passing on this document or copying it, or using and sharing its content are not allowed. Offenders will be held liable. All rights reserved, in the event a patent is granted or a utility model or design is registered.
-
Page 3: Table Of Contents
3.4.2 Main Connector X14 ............17 3.4.3 Extension Connector X14 ..........18 Display Elements................19 PROFIBUS Interfaces ..............19 3.6.1 RS485 Interface.............. 19 3.6.2 Fiber Optic Interface ............20 Technical Data ................22 4 Schematics ..............23 VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... -
Page 4: Vpc3+ Evaluation Kit
Table of Contents AT89C5132 ................23 VPC3+/C Extension Board............28 5 ISP (InSystemProgramming)........33 ATMEL FLIP 2.4.4..............33 How to use FLIP.................34 Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... -
Page 5: Introduction
Introduction Introduction Overview Profichip's VPC3+ Evaluation Kit contains all the necessary hardware and software to easily connect to PROFIBUS-DP. It consists of: Controller board with Atmel 89C5132 microcontroller 8-bit MCU C51 Core-based (FMAX = 20 MHz) 2304 Bytes of Internal RAM 64K Bytes of Code Memory (Flash) USB Rev 1.1 Device Controller... -
Page 6: Document Conventions
Handling the Boards Handle the VPC3+ evaluation boards with care in respect to ESD require- ments. Take precautions to use the boards only at an ESD-safe workplace. Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... -
Page 7: At89C5132 Board
TWI, MultiMediaCard, DataFlash, I2S, 10-bit ADC) 32kByte external RAM RS232 interface LCD-display Real Time Clock wide range of power supply (DC 7-24V) all relevant signals are applied to the plug connectors DIP-switches and LED's VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... -
Page 8: At89C5132 Board
2 AT89C5132 Board AT89C5132 board Figure 2-1: AT89C5132 Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... -
Page 9: At89C5132
FPGA on VPC3+/C Base Board B000 – BFFFH C000 – CFFFH D000 – DFFFH I/O Port 0 E000 – EFFFH I/O Port 1 F000 – FFFFH I/O Port 2 Figure 2-3: Address Map VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... -
Page 10: Internal/External Clock (Jumper X6)
'1' on this port. Reset Button S4 The entire application can be reseted by pressing the Reset Button S4.The microcontroller goes into a defined state and starts up the application program. Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... -
Page 11: Rs232 Interface
/D. The RTC is described more detailed in the document V3022_DS.pdf. 2.13 Multi Media Card is not supported. 2.14 I2C is not supported VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... -
Page 12: Connector
Address line 15 Read select Write select Address latch enable Reset EXT_CLK External clock CS_EXT0# Chip select Not connected Not connected Not connected Not connected Figure 2-6: Assignment of Connector X5 Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... -
Page 13: Mpi Board ( Main Connector, X5 )
Chip select for DIP-switches and LEDs CS_EXT0# Direction reverser for the fibre optic interface DIR_AB# Enable signal for fibre optic interface B EN_LWL_B Address line 11 Not connected Figure 2-7: Assignment of Connector X5 VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... -
Page 14: Mpi Board ( Extension Connector, X9 )
Address line 14 Address line 15 HLDTOK# Hold Token INT_FPGA Interrupt FPGA CS_FPGA’ Chip select FPGA FPGA_PROG# FPGA_CCLK FPGA_DIN FPGA FPGA_INIT# FPGA_DONE RES# Reset Not connected Figure 2-8: Assignment of Connector X9 Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... -
Page 15: Power Supply
AT89C5132 Board 2 2.16 Power Supply 7V-24V DC, from external power supply Figure 2-9: Power Supply VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... -
Page 16: Technical Data
7V – 24V DC, from ext. power supply Current consumption Operating temperature 0°C to +70°C Dimensions and Weight Dimensions (LxWxH) 89mm x 180mm x 16mm Weight Figure 2-10 : Technical data Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... -
Page 17: Vpc3+/C Extension Board
The extension board contains all necessary hardware to connect to PROFIBUS: VPC3+/C slave ASIC 48 MHz clock generator RS485 interface realized with opto coupler realized with ADuM electrical isolation fiber optic interface FPGA (for internal use) VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... -
Page 18: Board Vpc3+/C
3 VPC3+/C Extension Board Board VPC3+/C Figure 3-1: Extension Board VPC3+/C Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... -
Page 19: Jumpers
3.3.2 VPC3+/C clock divider Jumper X17 selects the VPC3+/C CLK to CLKOUT2/4 divider: Default Default setting Divider 0: CLK divided by 4 Divider 1: CLK divided by 2 Figure 3-3: VPC3+/C clock divider VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... -
Page 20: Select Profibus Interface
RS485 PROFIBUS interface (DEFAULT) Figure 3-4: PROFIBUS interface 3.3.4 Select Opto/ADuM Interface Jumper X6..X11 selects the Opto/ADuM interface: Default (RS485) Interface ADuM interface OPTO interface (DEFAULT) Figure 3-5: PROFIBUS interface Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... -
Page 21: Connectors
Address line 3 Address line 4 Address line 5 Address line 6 Address line 7 Address line 8 Address line 9 AB10 Address line 10 AB11 Address line 10 Read select VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... -
Page 22: Extension Connector X14
Address line 14 Address line 15 HLDTOK# Hold Token INT_FPGA Interrupt FPGA CS_FPGA’ Chip select FPGA FPGA_PROG# FPGA_CCLK FPGA_DIN FPGA FPGA_INIT# FPGA_DONE RES# Reset Not connected Figure 3-8: Assignment of Connector X9 Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... -
Page 23: Display Elements
Extensions to the system do not affect stations that have already been commissioned. Any failures of stations or new devices are detected automatically. VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... -
Page 24: Fiber Optic Interface
Advantages of FO over copper cables: wide bandwidth low attenuation no crosstalk between cores immunity to external electrical interference no potential difference lightning protection may be installed in explosive environments Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... - Page 25 Received data from A will be transmitted by B, and vice versa (default) Received data from B will be transmitted by A, and vice versa Figure 3-11: Coding of EN_LWL_B and DIR_AB VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005...
-
Page 26: Technical Data
50 m between stations Max. no. of stations 126 stations incl. Master. Dimensions and Weight Dimensions (LxWxH) 89mm x 180mm x 16mm Weight Figure 3-12: Base Board, Technical Data Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... -
Page 27: Schematics
Schematics Schematics AT89C5132 VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... - Page 28 4 Schematics Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005...
- Page 29 Schematics 4 VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005...
- Page 30 4 Schematics Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005...
- Page 31 Schematics 4 VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005...
-
Page 32: Vpc3+/C Extension Board
4 Schematics VPC3+/C Extension Board Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... - Page 33 Schematics 4 VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005...
- Page 34 4 Schematics Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005...
- Page 35 Schematics 4 VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005...
- Page 36 4 Schematics Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005...
-
Page 37: Isp (Insystemprogramming)
Atmel’s ISP function libraries (DLL) within their applications without having to know the details of Atmel's ISP protocols. FLIP adds flexibility, power and user-friendliness to Atmel Flash C51 devices In-System Programming. Figure 5-1: FLIP 2.4.4 VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005... -
Page 38: How To Use Flip
Set on Evaluation board switch S2 to ISP and connect USB cable: Position Execute Client Application Bootloader Figure 5-3: Switch S2, ISP Open USP Port Figure 5-4: Open USB Port Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005... - Page 39 ISP (InSystemProgramming) 5 Load Firmware, start programming over the button RUN and press the button Start Application. Figure 5-5: FLIP 2.4.4 VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2004...
- Page 40 5 ISP (InSystemProgramming) Notes: Revision 2.00 VPC3+ Evaluation Kit Copyright © profichip GmbH, 2005...
- Page 41 Revision History Version Date Page Remarks V1.00 15.09.2005 VPC3+ Evaluation Kit Revision 2.00 Copyright © profichip GmbH, 2005...
- Page 42 GmbH Einsteinstrasse 6 91074 Herzogenaurach Germany Phone : +49.9132.744-200 Fax: +49.9132.744-204 Th e Cl e ver Al t er n a t i ve www.profichip.com...
