Chino DB630E Instruction Manual

6-way lowboy console

6-Way Lowboy Console

Standard Features Are:

73FC Transformer

125 Amp 3 Phase Circuit Breaker

Primary 3-Phase Input Tapping options of 480/575v, 3ph,

60hz. Secondary Output Voltage 80 Volt

6 Channel Contactor Switching

Individual Neon Indicators per Channel

Chino Temperature Controllers

Size: 36" high x 34" deep x 24" wide

6" Heavy Duty Casters

4 Eye Hooks

Table of Contents

Do you have a question about the DB630E and is the answer not in the manual?

Page 1 Primary 3-Phase Input Tapping options of 480/575v, 3ph, 60hz. Secondary Output Voltage 80 Volt 6 Channel Contactor Switching Individual Neon Indicators per Channel Chino Temperature Controllers Size: 36” high x 34” deep x 24” wide 6” Heavy Duty Casters 4 Eye Hooks...
Page 2 Read Carefully before operating 1) Upon receipt of your new power console, visually inspect it for any damage that might have occurred during shipment. If there are any signs of damage please call EHS immediately so a damage claim can be processed. 2) The power console weighs approximately 960 pounds.
Page 5 DB630E-Ramp Instruction Manual * This controller is designed for heat treatment market Ver. 2014/7 PV : Process Value Display Status (Current Temperature) Solid RUN the controller SV : Set Point PAUSE Blink PAUSE the controller (Current Target Set Point) Solid...
