Read these instructions completely and carefully.
DIMENSIONS AND CLEARANCES
Provide adequate clearances between the range and adjacent combustible surfaces. These
dimensions must be met for safe use of your range. The location of the electrical outlet and
pipe opening (see Gas Pipe and Electric Outlet Locations) may be adjusted to meet specific
requirements.
Height
"
47 3 ⁄
4
Depth with door open:
"
46 3 ⁄
8
Minimum to
cabinets on
30"
either side of
the range
30"
3"
Minimum
Minimum
18"
clearance
to left wall
0"
To cabinets
below cooktop
and at the
range back
Depth with door closed (includes door handle)
" to 29"
28 1 ⁄
4
30"
Maximum depth
6" Minimum clearance
to right wall
36"
1/4"
Depth varies depending on model.
See specifications sheet for your
model.
" ± 1⁄4"
36 1 ⁄
4
for cabinets
13"
above
countertops
Front edge of
the range side
panel forward
from cabinet
0"
To cabinets below
cooktop and at
the range back
