Assembly Instructions
Model: TXA53
Step 1
Unfold chair assembly
Step 2
Insert (2) 2¼" bolts, washers and locknuts
into pre-drill holes
Then insert pins
Note: pins can be removed for folding
TOOLS NEEDED
7/16 wrench
4mm HEX KEY, ALLEN, T-HANDLE
(INCLUDED)
Qty.
Description
Pin
2
A - 1/4-20 X 2-1/4 WAFER SHCS
2
2
B - 1/4 FLAT WASHER
2
B - 1/4-20 NYLOCK NUT
Step 1
Step 2
A/B
ALL HARDWARE IS COATED STAINLESS STEEL
Correct
A/B
Incorrect
6/2/2011
