TREX Outdoor Furniture TXNCT3772 Assembly Instructions

Assembly Instructions
Model: TXNCT3772
Step 1
Attach feet to legs using (8) 2½" Chair bolts.
Step 2
Lay the table frame on a flat surface.
Attach the leg assemblies to the frame using
(16) 14x2½" screws - Do not tighten yet.
Step 3
Attach braces to the leg assemblies using
(8) 14x3" screws
Step 4
Set table upright and tighten all bolts.
__(1) Table top
__(8) Leg
__(4) Foot
__(4) Brace
__(1) Hardware pack
TOOLS NEEDED
4mm HEX KEY: INCLUDED
Qty. Description
A - .27 X 2-1/2 SOCKET WAFER A
16
B - .27 X 3 SOCKET WAFER A
8
C - 1/4-20 X 2-1/2 WAFER SHCS
8
B
fine thread
C
B
A
ALL HARDWARE IS COATED STAINLESS STEEL
C
B
B
A
Removable table plug
included in table.
Foot
Leg
Brace
Table frame
10/16/2012
