- Page 1 Assembly Instruction Packet For: TXC71 and TXC47 Sort Boxes Items are shipped in multible boxes Sections needed for Sections needed for SOFA LOVESEAT box - TXC23R box - TXC23R box - TXC23C box - TXC23L box - TXC23L TXC71 TXC47 page 1 10/29/2010...
-
Page 2: Sofa Assembly
Sofa Assembly Layout Parts Backs Back Cushion Qty 3 Seat supports Seats Seat Cushion Qty 3 Back rails Sideframes Center legs back legs front legs Layout Hardware Tools Needed note: you will need hardware pack from TXC23C box 4mm Hex Key - included 4mm Hex Bit for screw gun - included course thread Phillips head screwdriver... - Page 3 Sofa Assembly note: use course thread on 1,2,3,4,5 Repeat until all three seats and backs are assembled Attach Seat support Attach Back to Seat using (2) 3” chair screws using (2) 3” chair screws Attach Sideframe and Back rail using (4) 3" chair screws Left Sideframe and Back rail to Seat →...
- Page 4 Sofa Assembly note: use fine thread bolts for 7, 8, 9 Fit all sections together with Center legs → Attach small center legs with (2) 3 1/4" chair bolts and (2) capnuts Attach Rails to Back legs using (2) 1 1/2" chair bolts and capnuts Put cushions on sofa Your sofa is assembled! Attach Seats to Back legs using...
- Page 5 Loveseat Assembly Layout Parts Back Cushion Qty 2 Backs Seat supports Seat Cushion Qty 2 Seats Back rails Sideframes Center legs back leg front leg Layout Hardware Tools Needed 4mm Hex Key - included 4mm Hex Bit for screw gun - included course thread Phillips head screwdriver 3"...
- Page 6 Loveseat Assembly note: use course thread on 1,2,3,4,5 Repeat until both seats and backs are assembled Attach Seat support Attach Back to Seat using (2) 3” chair screws using (2) 3” chair screws Attach Sideframe and Back rail Left Sideframe and Back rail to Seat using (4) 3"...
- Page 7 Loveseat Assembly note: use fine thread bolts for 7, 8, 9 Fit all sections together with Center legs → Attach small Center leg with (1) 3 1/4" chair bolt and (1) capnut Attach Rails to Back leg using (1) 1 1/2" chair bolt and capnut Put cushions on loveseat Your loveseat is assembled! Attach Seats to Back leg using...
- Page 8 (“Purchaser”) that, for a period of five (5) years of residential use and one (1) year for commercial use from the date of original purchase, under normal use and service conditions, Trex Outdoor Furniture products (other than the cushion, which is covered by the warranty set forth below) shall be free from material defects in workmanship and materials, and shall not splinter, crack, chip, peel, rot, or suffer structural damage from insect infestation.
