selezionare il diametro della tubatura dove è installato il sensore di
fl usso.
- SENSORE DI FLUSSO ASSENTE Premere tante volte il tasto
fi nche non viene visualizzato il parametroTipo sensore di fl usso
selezionare assente.
11. Set point.
Premere il tasto
per uscire dal menù installatore.
Premere i tasti
per impostare la pressione desiderata.
SP
Apparirà
con i tasti
e
impostare la pressione.
7. How to program the PWM
Then the end user should close the front cover.
8. Switch on the power supply
Next step is to fi x the amperometric protection. Press for 5 seconds:
RC
On the screen appears the value
Adjust the amperage with
and
9. Direction of Rotation of the motor
Press
On the screen appears the parameter
select the direction of rotation.
To choose the correct direction of rotation , the end user could do in the
follwing way: after opening one tap, the end user could check on the
display the value of the frequency (FR). The right direction of rotation
is the one that givees to lower FR value.
10. Flow sensor
IF THE FLOW SENSOR IS INSTALLED - Press
until it is not achieved the parameter
Choose the value of the pie diameter where the sensor is assembled.
IF THE FLOW SENSOR IS NOT INSTALLED - Press
until it is not achieved the parameter
14
14
WACS si riserva il diritto di apportare modifi che senza obbligo di preavviso - WACS reserves the right to make any changes it deems fi t without notice - WACS se reserva el derecho de realizar modifi caciones sin la obligación de aviso previo
FL
.
RT
And with the
and
FD
. (Pipe dimension).
FL
. Fix this parameter, so that
the fl ow sensor is absent.
11. Set point
Press
to exit from Installer's menu.
Press
for 2 seconds and adjust the pressure with
and
.
7. Confi guración PWM
Cierre la tapa y conecte la tensión.
8. Confi guración de la protección amperimétrica
Para confi gurar la corriente hay que utilizar el menú instalador, pul-
sando simultáneamente, durante 5 segundos, los botones:
RC
se visualizará
.
El valor rC está indicado en la placa de cara-
cterísticas de la electrobomba como corriente nominal en Amperios (A)
y debe confi gurarse utilizando los botones
9. Confi guración de la dirección de rotación
Pulse 2 veces el botón mode
RT
Aparecerá
, con los botones
Para escoger el valor correcto de la dirección de rotación se puede
hacer lo siguiente: se abre un punto de salida y se controla en la pan-
talla la frecuencia (FR). La dirección correcta de rotación garantiza una
Fr más baja.
10. Sensor de fl ujo
- SSENSOR DE FLUJO INSTALADO – Pulse varias veces el botón
hasta que se visualiza el parámetro de dimensión del tubo en pulgadas
seleccione el diámetro de la tubería donde está instalado el sensor de fl ujo.
- SENSOR DE FLUJO AUSENTE Pulse muchas veces el botón
fhasta que aparezca el parámetro Tipo sensor de fl ujo
ausente.
11. Set point.
Pulse el botón
para salir del menú instalador.
Pulse los botones
SP
Aparecerá
con los botones
y
.
y
se selecciona aquel correcto.
FD
FL
y seleccione
para confi gurar la presión deseada.
y
confi gure la presión.
