0GU3035
Volume Control Valves
Single Volume Control Valve
Dual Volume Control Valve
•
Thank you for your recent purchase
of the TOTO product . Please read
the enclosed information to ensure
the safe use of your product
.
®
TSKA
TSKD
Installation and Owner's Manual
RENESSE
English
Contents
Important Safeguards---------------1
Specifications -------------------------2
Before Installation -------------------2
Set-up Drawing------------------------3
Components ---------------------------3
Installation Procedure ----------4~5
Set-up Options -----------------------6
Replacement Parts-------------------6
Warranty---------------------------------7
™
Español
Français
2007.5
Advertisement
Table of Contents
Related Manuals for Toto RENESSE TSKA
Summary of Contents for Toto RENESSE TSKA
- Page 1 Components ---------------------------3 Installation Procedure ----------4~5 Set-up Options -----------------------6 Replacement Parts-------------------6 Warranty---------------------------------7 TSKD Dual Volume Control Valve • Thank you for your recent purchase of the TOTO product . Please read the enclosed information to ensure the safe use of your product...
- Page 2 Important Safeguards (For your safety please follow the instructions below) Read the “Important Safeguards” section thoroughly before installing the product. ●The following table demonstrates the use ●The following symbols indicate safe and proper use of the of safety symbols in this manual. product.
- Page 3 Specification Minimum pressure 20 psi (0.15MPa)(flowing pressure) Water Supply Pressure Check local building Maximum pressure 125 psi (0.75MPa)(static) code Supplied Water Temperature Less than 185˚F (85˚C) Water that meet National/Primary drinking water Water Quality regulation Ambient Temperature 34 - 104˚F (2～40˚C) 1/2”...
- Page 4 Set-Up Drawing *Some parts may differ from the illustration depending on the model. 1/2” NPT Volume Control Trim (SOLD SEPARTELY) Dual Volume FINISHED WALL Control Valve Single Volume Conrol Valve COLD 2-15/16” (75mm) MIN 2-9/16” Complete Shower Set 6-5/16” (160 mm) 65 mm 3-9/16”...
- Page 5 WATER IN (From Thermostatic Mixing Valve) Plug Plug Install WATER OUT the Trims (To Handshower Adapter) TOTO mark on bottom TSKD ( Dual Volume Control Valve) WATER OUT Connect Hot/Cold TOTO mark on top (To Showerhead) Water Supply Lines Plug Clean water supply Finish the wall.
- Page 6 Installation of Volume Control Valve (s) Confirm the rough-in mentioned in the Set-up ① 1/2” pipe Drawing and Install the volume control valve(s) Showerhead (Sold separately) Connect the valve (s), Single Volume Control ② Single Vol and/or Dual Volume Control, (please see the Control Shower Set up Options for Renesse Shower Valve...
- Page 7 Set-Up Options 2) w/o 3) w/o wall spout 1) Complete Set 4) Showerhead Handshower only Showerhead Showerhead Showerhead Showerhead Handshower Single Single Vol Vol Control Control Trim Dual Vol & valve Control Trim & valve Dual Vol Dual Vol Trim & Control Control valve...
- Page 8 ® ® defect together with proof of purchase (original sales receipt) shall constitute delivery. In such case, TOTO ® may choose to repair the Product at the purchaser’s location or pay to transport the Product to a service facility.
