1RU Enclosure for openGear
Product Manual
BBG-1300-FR
BBG-1300-FR
Cobalt Digital Inc.
2506 Galen Drive
Champaign, IL 61821
Voice 217.344.1243 • Fax 217.344.1245
www.cobaltdigital.com
Cards
®
BBG-1300-OM (V1.0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BBG-1300-FR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cobalt Digital Inc BBG-1300-FR

Summary of Contents for Cobalt Digital Inc BBG-1300-FR

  • Page 1 BBG-1300-FR BBG-1300-FR 1RU Enclosure for openGear Cards ® Product Manual Cobalt Digital Inc. 2506 Galen Drive Champaign, IL 61821 Voice 217.344.1243 • Fax 217.344.1245 www.cobaltdigital.com BBG-1300-OM (V1.0)
  • Page 2 Furthermore, Cobalt Digital Inc. reserves the right to make changes to any products herein to improve readability, function, or design. Cobalt Digital Inc. does not assume any liability arising out of the application or use of any product or circuit described herein.
  • Page 3 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Warning Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 4 Changes or modifications to this equipment not expressly approved by Cobalt Digital Inc. could void the user's authority to operate this equipment.

  • Page 5: Table Of Contents

    Ventilation Considerations ................. 2-3 Cable Connections ..................2-4 Installing Rear I/O Modules and Cards ..............2-5 Rear I/O Module Installation..............2-5 User Card Installation................. 2-6 BBG-1300-FR Multi-Function Display..............2-9 BBG-1300-FR Device Status Displays ............ 2-10 BBG-1300-OM (V1.0) BBG-1300-FR PRODUCT MANUAL...
  • Page 6 Setting Up Network Remote Control ..............2-11 Setup Using DHCP ................... 2-11 Setup Using Static Address Connection ........... 2-14 BBG-1300-FR DashBoard Status and Expanded Network Settings Interfaces ............. 2-17 BBG-1300-FR Info Tabs................2-17 BBG-1300-FR Setup, Network, and Auxiliary Function Control Tabs .............. 2-19 Setting/Configuring Miscellaneous BBG-1300 Functions .......

  • Page 7: Chapter 1 Introduction

    Contact Cobalt Digital Inc. (p. 1-10) Manual Conventions In this manual, connectors are shown using the exact name shown on the BBG-1300-FR itself. In this manual, the terms below are applicable as follows: • BBG-1300-FR refers to the BBG-1300-FR enclosure that houses ®...

  • Page 8: Warnings, Cautions, And Notes

    Symbol (WEEE 2002/96/EC) For product disposal, ensure the following: • Do not dispose of this product as unsorted municipal waste. • Collect this product separately. • Use collection and return systems available to you. BBG-1300-FR PRODUCT MANUAL BBG-1300-OM (V1.0)

  • Page 9: Safety Summary

    Most cards within the Cobalt product lineup can be housed in the BBG-1300-FR, with a total available power of 60 W. Up to three BBG-1300-FR units can fit onto a single 1RU tray for maximum density where a 2RU frame is not feasible.
  • Page 10 BBG-1300-FR Functional Description Card User Slot Area (2 Slots max) Figure 1-1 BBG-1300-FR (Front View with Card Access Front Door Separated from Chassis) Network Looping Redundant Power Supply IEC AC Ethernet Reference Connector Connectors Line Connectors (2) Rear I/O Module Area...

  • Page 11: Rear I/O Modules

    Split rear modules are identified by "S" in the part number (for example, "RM20-9902-A/S"). Note: Utilization of BBG-1300-FR as a two-card device requires Split Rear I/O Module usage. Split rear modules are not available for all cards. Figure 1-3 Rear Module Types Compatible with BBG-1300-FR BBG-1300-OM (V1.0)

  • Page 12: Network Interface

    BBG-1300-FR Functional Description Network Interface Figure 1-4 shows the user remote control interface options for BBG-1300-FR. Note: All user control interfaces described here are cross-compatible and can oper- ate together as desired. Where applicable, any control setting change made using a particular user interface is reflected on any other connected interface.
  • Page 13 Introduction BBG-1300-FR Functional Description OGCP-9000 Control Panel, OGCP-9000/CC Control Panel, and/or WinOGCP Virtual Control Panel(s) Remote Control Panel Using the Control Panel, cards are remotely controlled over a LAN BBG-1300-FR DashBoard™ Remote Control Using a computer with DashBoard™ installed, card can...

  • Page 14: Technical Specifications

    Technical Specifications Technical Specifications Table 1-1 lists the technical specifications for the BBG-1300-FR. Table 1-1 Technical Specifications Item Characteristic ® Part number, nomenclature BBG-1300-FR 1RU Enclosure for openGear Cards Installation/usage environment Intended for installation and usage in environmentally controlled ®...

  • Page 15: Warranty And Service Information

    (1) year. Cobalt Digital Inc.'s (“Cobalt”) sole obligation under this warranty shall be limited to, at its option, (i) the repair or (ii) replacement of the product, and the determination of whether a defect is covered under this limited warranty shall be made at the sole discretion of Cobalt.

  • Page 16: Contact Cobalt Digital Inc

    Contact Cobalt Digital Inc. Contact Cobalt Digital Inc. Feel free to contact our thorough and professional support representatives for any of the following: • Name and address of your local dealer • Product information and pricing • Technical support •...

  • Page 17: Chapter 2 Installation And Setup

    Troubleshooting (p. 2-25) Installing the BBG-1300-FR Note: • Where BBG-1300-FR is to be installed on a mounting plate (or regular table or desk surface) without optional frame Mounting Tray BBG-1300-TRAY, affix four adhesive-backed rubber feet (supplied) to the bottom of BBG-1300-FR in locations marked with stamped “x”.

  • Page 18: Bbg-1300-Fr Dimensional Drawing

    Slide unit (rear) fully to rear of tray. Secure unit to tray using captive fastener. Tighten only finger tight. Figure 2-1 Mounting BBG-1300-FR Using Frame Mounting Tray BBG-1300-FR Dimensional Drawing Figure 2-2 shows the installation dimensional details for the BBG-1300-FR. BBG-1300-FR PRODUCT MANUAL BBG-1300-OM (V1.0)

  • Page 19: Ventilation Considerations

    Figure 2-2 BBG-1300-FR Dimensional Drawings Ventilation Considerations BBG-1300-FR has three fans built into the front bezel assembly. Overall, the unit takes in cooling air and provides exhaust through vents on all sides of the front bezel, and via vents near the rear of the chassis. Make certain these vents are not obstructed.

  • Page 20: Cable Connections

    Figure 2-3 BBG-1300-FR Rear Panel Connections Power Connections (See Figure 2-3.) BBG-1300-FR is equipped with two corded IEC power input receptacle which mate to IEC cord sets. Note: For non-redundant AC power input, either receptacle can be used for power connection.

  • Page 21: Installing Rear I/O Modules And Cards

    Standard-Width rear module. Ideally, these cards should be mated with a rear module specified (on web page or manual) as: Note: Mates to card in odd slot. Odd-slot rear module places card mating in lower BBG-1300-FR slot and circumvents top-clearance issue. BBG-1300-OM (V1.0)

  • Page 22: User Card Installation

    On underside of front bezel assembly, remove retaining screw and place aside in safe place. (See Figure 2-5.) While firmly holding BBG-1300-FR chassis with one hand, grasp front bezel assembly and pull front bezel assembly straight away from chassis.
  • Page 23 Installing Rear I/O Modules and Cards Note: Use care to pull front bezel assembly away from BBG-1300-FR chassis as straight as possible. If bezel is pulled out unevenly, mounting tab(s) could bend. This may result in needing to straighten the tab(s) before the bezel can again mate with slots in the BBG-1300-FR chassis.
  • Page 24 Assess proper installation Push card lightly and fully into slot until card-edge connector on card orientation before installing card. fully mates with Rear I/O Module mating connector. Figure 2-6 Card Installation BBG-1300-FR PRODUCT MANUAL BBG-1300-OM (V1.0)

  • Page 25: Bbg-1300-Fr Multi-Function Display

    Installation and Setup BBG-1300-FR Multi-Function Display BBG-1300-FR Multi-Function Display Figure 2-7 shows and describes the BBG-1300-FR front panel display, soft keys, and menu access rotary knob. Display shows available main menu items, as well as sub-menus when a main item is selected.

  • Page 26: Bbg-1300-Fr Device Status Displays

    Icons in upper display corner show status and presence of BBG-1300-FR device and any installed user cards (F for BBG-1300-FR; 1 for user card slot 1; 2 for user card slot 2). • Green background indicates OK status.

  • Page 27: Setting Up Network Remote Control

    DashBoard™ remote control, or remote control via Cobalt OGCP-9000 Remote Control Panel or WinOGCP. Before the card(s) hosted by BBG-1300-FR can be used with remote control, BBG-1300-FR and the remote control devices (e.g., computer running DashBoard™ or remote control panels) must be set up to communicate (“connect”) with each other as described in this section.
  • Page 28 DashBoard™ and the DHCP-assigned addresses with the physical identity of the devices. On the computer where DashBoard™ is installed, make certain TCP/IP Properties DHCP settings are as follows: • Obtain an IP address automatically • Obtain DNS Server address automatically 2-12 BBG-1300-FR PRODUCT MANUAL BBG-1300-OM (V1.0)
  • Page 29 Setting Up Network Remote Control Set BBG-1300-FR for DHCP Connection After main menu appears Frame press soft key to go to the Frame (BBG-1300-FR) setup menu. Press Navigate/Select knob to select Network Address Mode sub-menu is now displayed. DHCP/Static select field...

  • Page 30: Setup Using Static Address Connection

    Setting Up Network Remote Control Setup Using Static Address Connection After Frame main menu appears press soft key to go to the Frame (BBG-1300-FR) setup menu. Press Navigate/Select knob to select Network sub-menu is now displayed. Address Mode DHCP/Static select field...
  • Page 31 Mask sub-menu. Note: Typically, default mask setting of 255.255.255.0 is suitable. If default mask is to be used, simply use Navigate/Select knob to skip past Mask and go to Gateway sub-menu select (step 11). 2-15 BBG-1300-OM (V1.0) BBG-1300-FR PRODUCT MANUAL...
  • Page 32 Using Navigate/Select knob, select and press knob to OK the selected values. Mask is now set as desired. IP address and related settings are now engaged into BBG-1300-FR device and device is accessible using configured address. Press soft key to exit the setup menu and go to frame main menu.

  • Page 33: Bbg-1300-Fr Dashboard Status And Expanded Network Settings Interfaces

    Similar to expanded access to network and other setup offered via DashBoard for frame network controller cards, BBG-1300-FR can be accessed via DashBoard on its connected network. When BBG-1300-FR is on the same network as a DashBoard instance, BBG-1300-FR appears in the DashBoard Basic Tree View identically to that of a standard rack-mounted frame.
  • Page 34 This displays shows the hardware identifcation of the network card, as well as software revision. Network Display This displays shows the user name for the BBG-1300-FR, current network settings (either user configured static or DHCP assigned status) NTP details, and other access-related info.

  • Page 35: Bbg-1300-Fr Setup, Network, And Auxiliary Function Control Tabs

    Identify is pressed (see Beeper Mute (p. 2-24) for more info). • BBG-1300-FR Date/Time Entry Controls Allows a running date and time to be entered for the BBG-1300-FR and connections displayed in DashBoard. When date/time are entered as desired, press Apply to invoke the settings.
  • Page 36 • Click Apply or Cancel to commit or reject and related entry fields allow user static address entry. • Cobalt VPN Support Enable Enables or disables a VPN connection from the BBG-1300-FR and Cobalt Support where the BBG-1300-FR network installation and operation can be viewed, queried, and assessed by Cobalt Support.
  • Page 37 • Enabled with enumeration; cards immediately visible– caching is performed and enumerated list is written. BBG-1300-FR and card presence is visible even for cards not fully enumerated. (This setting provides fastest rendering of BBG-1300-FR and cards in DashBoard and is the recommended default setting.) Enumeration list shows write-to-list status.
  • Page 38 Ignore setting allows item to be removed from alarm triggering. Note: • Alarm items shown here are related exclusively to the BBG-1300-FR device; hosted card DashBoard alarms are set on the respective card alarm pages (where present).
  • Page 39 Installation and Setup Setting Up Network Remote Control Table 2-1 BBG-1300-FR Setup and Auxiliary Control Descriptions — continued Provides setup controls for BBG-1300-FR SNMP agent. SNMP page offers standard SNMP setup fields. Up to 10 Targets can be independently set.

  • Page 40: Setting/Configuring Miscellaneous Bbg-1300 Functions

    Setting Up Network Remote Control Setting/Configuring Miscellaneous BBG-1300 Functions Numerous other BBG-1300-FR operating and monitoring functions are available via front panel control and via DashBoard. This section describes these attributes and their setup. Beeper Mute • To temporarily mute the device alert beeper, select the BBG-1300-FR main menu (by pressing soft key ).

  • Page 41: Troubleshooting

    Note: All remote control items described here use industry standard 100/1000 Mbps Ethernet for communication between the BBG-1300-FR and remote control systems such as DashBoard™. Standard LAN troubleshooting techniques and practices are applicable to this usage.
  • Page 42 LAN mis-connected switch indicators and the ETHERNET connector indicator on the BBG-1300-FR. Use ping to check the connection. BBG-1300-FR connection to network is shown on front panel as shown below. Connection OK...

  • Page 43: In Case Of Problems

    Remove the front bezel as shown in Figure 2-5 on page 2-7. Power-up the BBG-1300-FR. Note: To access PCB buttons on next steps, if possible place the BBG-1300-FR on its left side. This will make access and readability of the switch buttons and their screened legends easier.
  • Page 44 The Cobalt Digital Inc. Technical Support Department will continue to provide advice on any product manufactured by Cobalt Digital Inc., beyond the warranty period without charge, for the life of the product. See Contact Cobalt Digital Inc. (p. 1-10) in Chapter 1, “Introduction“ for contact information. 2-28 BBG-1300-FR PRODUCT MANUAL BBG-1300-OM (V1.0)
