BBG-1070-QS
BBG-1070-QS
3G/HD/SD-SDI/CVBS Standalone Expandable Multiviewer
with Advanced On-Screen Graphics
Product Manual
Cobalt Digital Inc.
2506 Galen Drive
Champaign, IL 61821
Voice 217.344.1243 • Fax 217.344.1245
www.cobaltdigital.com
BBG-1070QS-OM (V1.9)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BBG-1070-QS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cobalt Digital Inc BBG-1070-QS

Summary of Contents for Cobalt Digital Inc BBG-1070-QS

  • Page 1 BBG-1070-QS BBG-1070-QS 3G/HD/SD-SDI/CVBS Standalone Expandable Multiviewer with Advanced On-Screen Graphics Product Manual Cobalt Digital Inc. 2506 Galen Drive Champaign, IL 61821 Voice 217.344.1243 • Fax 217.344.1245 www.cobaltdigital.com BBG-1070QS-OM (V1.9)
  • Page 2 Furthermore, Cobalt Digital Inc. reserves the right to make changes to any products herein to improve readability, function, or design. Cobalt Digital Inc. does not assume any liability arising out of the application or use of any product or circuit described herein.

  • Page 3: Table Of Contents

    BBG-1070-QS Functional Description ..............1-4 BBG-1070-QS Input/Output Formats ............1-4 Video Processing Description ..............1-4 Audio Processor Description ..............1-8 Cascading (Multi-Device) BBG-1070-QS Operation and Setup Overview 1-8 User Control Interface ................1-11 Technical Specifications..................1-11 Warranty and Service Information ............... 1-13 Cobalt Digital Inc.
  • Page 4 BBG-1070-QS Function Menu List and Descriptions ..........3-9 Input Routing ................... 3-10 PIP Clone Global Controls ............... 3-13 PIP Layout Controls ................. 3-14 PIP ARC/Borders Controls ..............3-19 Tally Lamp Insertion Controls ..............3-21 UMD/Identification Text Insertion Controls ........... 3-23 Audio Meter Overlay Controls ..............

  • Page 5: Chapter 1 Introduction

    • BBG-1070-QS and setting up its network access. Chapter 3, “Setup/Operating Instructions” – Provides overviews • of operating controls and instructions for using the BBG-1070-QS. This chapter contains the following information: Cobalt Reference Guides (p. 1-1) • Manual Conventions (p. 1-2) •...

  • Page 6: Manual Conventions

    Manual Conventions Manual Conventions In this manual, display messages and connectors are shown using the exact name shown on the BBG-1070-QS itself. Examples are provided below. Device display messages are shown like this: • BBG-1070-QS Connector names are shown like this: SDI IN A •...

  • Page 7: Labeling Symbol Definitions

    CAUTION unauthorized sources may cause product damage, unreliable operation, and invalidate warranty. The BBG-1070-QS FPGA is designed for a normal-range operating temperature around CAUTION 85° C core temperature. Operation in severe conditions exceeding this limit for non-sustained usage are within device operating safe parameters, and can be allowed by setting this control to Disable.

  • Page 8: Bbg-1070-Qs Functional Description

    BBG-1070-QS Functional Description BBG-1070-QS Functional Description Figure 1-1 shows a functional block diagram of the BBG-1070-QS. The BBG-1070-QS includes input processing functions to accommodate SDI and CVBS analog inputs, a validity check function to provide indication of input defects, timecode and audio data handling and routing control, multi-split...
  • Page 9 Introduction BBG-1070-QS Functional Description Figure 1-1 BBG-1070-QS Functional Block Diagram BBG-1070QS-OM (V1.9) BBG-1070-QS PRODUCT MANUAL...
  • Page 10 FRAME LOOP video as a frame reference. As such, BBG-1070-QS can accommodate asynchronous program video inputs. This function also allows frame offset delay to be added between the output video and the frame sync reference.
  • Page 11 Introduction BBG-1070-QS Functional Description Output Preview via Network Connection A DashBoard Output Preview function provides the display of regularly-sampled screen captures in the device DashBoard remote control page. This provides remote-access program video content/presence and multiviewer layout confidence monitoring via the device’s DashBoard display without needing collocation with the BBG-1070 or its input or output video signals.

  • Page 12: Audio Processor Description

    BBG-1070-QS devices to operate in a cascading arrangement, where four of the device inputs serve as program video inputs, and the fifth input receives the cascading combined layout of a preceding BBG-1070-QS device in a daisy-chain arrangement. In this mode, the...
  • Page 13 “A” thru “C”, all 16 PiPs are now positioned in the four resulting columns. This provides the 16:1 multiviewer layout using four devices (“A” thru “D”) in a cascaded form. Figure 1-3 Cascaded BBG-1070-QS Example 16:1 Setup and Overview BBG-1070QS-OM (V1.9) BBG-1070-QS PRODUCT MANUAL...
  • Page 14 Cascade Config DashBoard tabs and multi-unit network connection allows cascade chain network-connected BBG-1070-QS units (BBG-1070-QS units “A” thru “D” in this example) to communicate with each other and centrally expose setup attributes of all of the units within the chain.

  • Page 15: User Control Interface

    10/100/1000 RJ-45 Ethernet connection. The device can also be controlled using DashBoard™ remote control, where it appears as a frame connection. Technical Specifications Table 1-1 lists the technical specifications for the BBG-1070-QS 3G/HD/ SD-SDI/CVBS Standalone Expandable Multiviewer with Advanced On-Screen unit.
  • Page 16 GPI HI @ Vin > 2.3 V Max Vin: 9 V Frame Reference Input Looping 2-BNC connection. SMPTE 170M/318M “Black Burst”, SMPTE 274M/296M “Tri-Level” Return Loss: >35 dB up to 5.75 MHz Redundant (or spare) AC power supply BBG-1000-PS (optional) 1-12 BBG-1070-QS PRODUCT MANUAL BBG-1070QS-OM (V1.9)

  • Page 17: Warranty And Service Information

    (1) year. Cobalt Digital Inc.'s (“Cobalt”) sole obligation under this warranty shall be limited to, at its option, (i) the repair or (ii) replacement of the product, and the determination of whether a defect is covered under this limited warranty shall be made at the sole discretion of Cobalt.

  • Page 18: Contact Cobalt Digital Inc

    Contact Cobalt Digital Inc. Contact Cobalt Digital Inc. Feel free to contact our thorough and professional support representatives for any of the following: Name and address of your local dealer • Product information and pricing • Technical support • Upcoming trade show information •...

  • Page 19: Chapter 2 Installation

    • Installing the BBG-1070-QS Note: • Where BBG-1070-QS is to be installed on a mounting plate (or regular table or desk surface) without optional frame Mounting Tray BBG-1000-TRAY, affix four adhesive-backed rubber feet (supplied) to the bottom of BBG-1070-QS in locations marked with stamped “x”. If feet are not affixed, chassis bottom cooling vents will be obscured.

  • Page 20: Bbg-1070-Qs Unit Dimensions

    Tighten only finger tight. Figure 2-1 Mounting BBG-1070-QS Using Frame Mounting Tray BBG-1070-QS Unit Dimensions Figure 2-2 shows the BBG-1070-QS physical dimensions and mounting details for cases where BBG-1070-QS will be installed in a location not using the optional BBG-1000-TRAY mounting tray.
  • Page 21 REAR Notes: 1. All dimensions in inches. 2. If BBG-1070-QS is mounted on flat surface, either rubber feet must be installed, or mounting surface must be open to mate with cooling vents on bottom of BBG-1070-QS chassis. Figure 2-2 BBG-1070-QS Dimensional Details BBG-1070QS-OM (V1.9)
  • Page 22 Pullup R >500Ω resistor is recommended when using 5V control. GPI to GPI Specifications: card control GPI LO @ Vin < 1.5 V GPI HI @ Vin > 2.3 V 10 kΩ Max Vin: 9 V Figure 2-3 BBG-1070-QS Rear Panel Connectors BBG-1070-QS PRODUCT MANUAL BBG-1070QS-OM (V1.9)

  • Page 23: Chapter 3 Setup/Operating Instructions

    • Control and Display Descriptions (p. 3-5) • Checking BBG-1070-QS Device Information (p. 3-8) • BBG-1070-QS Function Menu List and Descriptions (p. 3-9) • Uploading Firmware Using Web Interface and GUI (p. 3-63) • Front Panel User Menus (p. 3-64) •...
  • Page 24 Repeatedly press the button to step up through sub-menus and then to other menus. Access other menu items using buttons. The display backlight automatically brightens with any navigation arrow activity, and then goes dim after a few moments. Figure 3-1 BBG-1070 Front Panel Display and Menu Controls BBG-1070-QS PRODUCT MANUAL BBG-1070QS-OM (V1.9)

  • Page 25: Connecting Bbg-1070 To Your Network

    Note: Current IP address of BBG-1070 can now be checked from the front panel by accessing this at any point. 6. At this point, BBG-1070 can now be accessed with a web browser pointing to the configured address. Browse to the configured address and check connectivity. Web browser pointing to configured address displays BBG-1070 BBG-1070QS-OM (V1.9) BBG-1070-QS PRODUCT MANUAL...

  • Page 26: Finding A Bbg-1070 Device In Dashboard

    BBG-1070 DashBoard remote control is also available by opening the device ® in DashBoard similar to opening an openGear card. Hovering over the blue BBG icon in DashBoard displays the address of the BBG device Figure 3-2 Finding BBG-1070 Using DashBoard BBG-1070-QS PRODUCT MANUAL BBG-1070QS-OM (V1.9)

  • Page 27: Control And Display Descriptions

    Figure 3-3 shows how the BBG-1070-QS device and its menus are organized, and also provides an overview of how navigation is performed between devices, function menus, and parameters.

  • Page 28: Web User Interface

    In this example, the Layout/Routing main menu tab is selected, with the overall pane now showing all sub-menu items related to the framesync function. Clicking another main menu tab immediately displays the pane related to the selected main menu tab. Figure 3-4 Typical Web UI Display and Controls BBG-1070-QS PRODUCT MANUAL BBG-1070QS-OM (V1.9)

  • Page 29: Display Theme

    Light – this is the theme shown in this manual and is Dark – the dark theme is suited for low-light environments. useful for normal ambient light environments such as offices. Figure 3-5 Web UI Display Themes BBG-1070QS-OM (V1.9) BBG-1070-QS PRODUCT MANUAL...

  • Page 30: Checking Bbg-1070-Qs Device Information

    Checking BBG-1070-QS Device Information Checking BBG-1070-QS Device Information The operating status and software version the BBG-1070-QS device can be checked by clicking the Status main menu tab. Figure 3-6 shows and describes the BBG-1070-QS device information status display. Note: Proper operating status is denoted by green icons for the status indicators shown in Figure 3-6.

  • Page 31: Bbg-1070-Qs Function Menu List And Descriptions

    BBG-1070-QS Function Menu List and Descriptions BBG-1070-QS Function Menu List and Descriptions Table 3-1 individually lists and describes each BBG-1070-QS function menu and its related list selections, controls, and parameters. Where helpful, examples showing usage of a function are also provided.

  • Page 32: Input Routing

    BBG-1070-QS Function Menu List and Descriptions Note: Some control descriptions in this section are also contained in “BBG-1070-QS Operator’s Guide” and are repeated here for convenience. It is however recommended that operators use BBG-1070-QS Operator’s Guide (included with this product) for using the BBG-1070-QS rather than this manual.
  • Page 33 Cascade Mode Select sets PiP 5 as a input to be used to receive a cascade output from another BBG-1070-QS unit or to be set as a regular fifth PiP input as follows: • Enabled: Sets PiP 5 input to receive a cascade output from another BBG-1070-QS unit.
  • Page 34 Unit Local inputs are inputs received by the unit to serve as an individual PiP image. A Cascade input is an image imported into the unit from an upstream BBG-1070-QS used in a multi-unit cascading multiviewer arrangement. An input used as a cascade input has controls related to local setup locked out (for example, burn-ins and sizing) since a cascading input serves as an underlay with all its burn-ins and other attributes already provided by the upstream unit.

  • Page 35: Pip Clone Global Controls

    Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides controls to set global “cloning” of graphics attributes settings from one PiP to another. This helps in providing a consistent and easily set layout across PIP Clone Global Controls selected PiPs.

  • Page 36: Pip Layout Controls

    BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides PiP layout presets templates and other controls related to the number of splits and layout for the overall merged-image output. PIP Layout Controls • Layout Preset Template Select For local (non-cascading) inputs, selects from several preset global (base) layout templates from the choices shown and depicted below.
  • Page 37 (In this example, PiP 1 is selected for editing.) Note: • These controls are intended only for local inputs and not a cascade underlay imported from an upstream BBG-1070-QS unit. • For multi-unit setup using Cascade Config mode/setup, Clone Settings from any of the units in the chain can be cloned to any unit in the chain (i.e., all units in the chain appear in the Clone...
  • Page 38 Cascade Mode Using PiP Layout QuickSet Template Presets upstream BBG-1070-QS provides a first column of PiP images, and then a second BBG-1070-QS provides the second column of PiP images.
  • Page 39 Example 16:1 Multiviewer Setup Using Multi-Unit Cascading Mode and Quicksets This example shows a layout setup that provides a 16:1 multiviewer output. It uses four BBG-1070-QS units, each handling four PiP inputs, and with each unit set to work with a 16-PiP (4x4) grid.
  • Page 40 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • PiP Custom Positioning Controls Controls allow the positioning and sizing of the PiP within the overall merged output image. • Position Vertical and Position Horizontal sets the PiP origin location (Vertical in lines;...

  • Page 41: Pip Arc/Borders Controls

    Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides controls to individually set border, ARC, and custom sizing for each local PiP input. PIP ARC/Borders Controls • PiP Configure Select/Clone Individually selects any of the five PiP inputs to be selected for sizing/ positioning edits (as described below).
  • Page 42 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • PiP ARC Mode Select ARC Mode select allows the ARC controls to either use the aspect ratio defined by the incoming PiP video to serve as the referenced aspect ratio for other ARC controls, or to use a custom-sized aspect ratio PiP raster as the referenced aspect ratio.

  • Page 43: Tally Lamp Insertion Controls

    Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • Input PiP Video Size/Position Controls The controls shown here allow manipulating the input scaling and positioning of the selected PiP image before it is processed by the image area ARC.
  • Page 44 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • Tally Insertion Select Enables or disables lamp insertion overlay for selected PiP(s). • Lamp Color Control Provides control for setting selected tally lamp “illuminated” color as directed by the control inputs shown.

  • Page 45: Umd/Identification Text Insertion Controls

    Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides controls for each PiP to insert UMD text, user identification text, and timecode burn-in. Also allows setting insertion rules and text attributes such as size and color.
  • Page 46 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • UMD Text Entry Field Dialog entry box that allows entry of desired ident text string. Enter desired text as click Update when done to input the text string.
  • Page 47 Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • Text/Background Positioning Controls • Using the Position Mode drop-down, UMD text and its background can be positioned using template choices (as shown) or can use the Custom choices which provide basic positioning which can then be further manipulated as described below.
  • Page 48 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides controls for each PiP to insert identifying active-video area burn-in text, and set insertion rules and text attributes such as size and color. Note: Identical independent controls are provided for additional ident text insertion Ident 2. Therefore, only the Ident 1 controls are shown here.
  • Page 49 Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) Note: The sizing/positioning controls below for text and background have an interrelation where a background shading box can automatically track with text size/position and vice-versa as described below.
  • Page 50 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • Text/Background Positioning Controls • Using the Position Mode drop-down, ident text and its background can be positioned using template choices (as shown) or can use the Custom choices which provide basic positioning which can then be further manipulated as described below.
  • Page 51 Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides controls for each PiP to insert active-video area timecode burn-in, and set insertion rules and attributes such as size and color. Note: Timecode character burn-in is always the embedded timecode associated with the PiP (i.e., PiP 1 Timecode Burn uses only the timecode value embedded on PiP 1 input video).
  • Page 52 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • Text Character/Background Attributes Provides independent controls for setting the color and opacity of the Controls ident text and its background. • Character Size drop-downs set text size (in pixels).

  • Page 53: Audio Meter Overlay Controls

    Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides controls for each PiP to insert active-video area audio meters (bars), and set insertion rules and attributes such as layout, size and position.
  • Page 54 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) Example Meter Layouts Stereo split Stereo snap left Stereo snap right Groups 1-2 All Groups Custom In this example, ch 1-4 on left, and ch 5-6 on right; 6 meters total...
  • Page 55 Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • Meter Width Control Sets the relative height of the audio bars. Width set at middle Width set at less • Meter Height Control Sets the relative height of the audio bars.
  • Page 56 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • Meter Borders Select Enables or disables limit borders surrounding each audio bar. Borders Borders enabled disabled • Meter Brightness Control Adjusts relative brightness of audio meter bars display.

  • Page 57: Reticules Controls

    Reticules Controls Typical Reticule/Overlay Marker Insertions The BBG-1070-QS allows any combination of the reticule/overlay markers to be applied to the output video. Sizing and other characteristics for each type of marker can be set as described below. Safe Action Area (SAA) Reticule...
  • Page 58 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • Safe Action Area (SAA) Controls • SAA provides enable/disable of safe action area graticule insertion. • SAA Height and SAA Width control height and width of insertion (from 0% to 100% of 4:3 outputted image area).
  • Page 59 Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides controls for each PiP for insertion and sizing controls for custom graticules and other markers. Also provides NTSC legacy 4:3 master reticule sizing.

  • Page 60: Output Format Controls

    BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides controls to set merged split output format/ conditioning and global ref lock mode. Also provides settings to force an HDMI or DVI output Output Format Controls...
  • Page 61 • HDMI Mode Control Sets HDMI/DVI output to use the connected monitor to inform BBG-1070-QS to automatically detect the monitor format, or to use manual (forced) control. Where the monitor may not be able to provide this handshake signal, it is recommended to use Manual mode and force the desired mode as described below.

  • Page 62: Output Audio Routing/Controls

    BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides an audio crosspoint allowing the audio source selection for each embedded audio output channel. Also provides Gain, Phase Invert, and Muting controls Output Audio Routing/Controls and peak level meters for each output channel.

  • Page 63: Cascade Config Setup Controls

    Cascade Config DashBoard tabs and multi-unit network connection allows cascade chain network-connected BBG-1070-QS units (BBG-1070-QS units “A” thru “D” in this example) to communicate with each other and centrally expose setup attributes of all of the units within the chain.
  • Page 64 The configurator definer tool defines the BBG-1070-QS units within a particular cascade chain by unit IP address, and each unit’s position within the multiviewer setup. The setup is based on BBG-1070-QS units being used with the first unit receiving 5 program...
  • Page 65 (continued) Cascade Configurator Example and Setup Tips The following shows an example where a 17:1 multiviewer is furnished using Cascade Config with four BBG-1070-QS units forming a 4-unit chain (5+4+4+4 PiP inputs which provides a 17-PiP multiviewer). A very important and clarifying aspect of using Cascade Config is when the units are cascade network defined (as described on the previous page) the DashBoard UI simply combines all the discrete units as a single device.
  • Page 66 BBG-1070-QS Function Menu List — continued (continued) Cascade Configurator Example and Setup Tips (cont.) First, all BBG-1070-QS units in the cascade chain need to be assigned dedicated IP addresses to be used in conjunction with the per-unit dedicated Ethernet RJ-45 port.
  • Page 67 Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) All of the PiP Layout, ARC/Borders, Tally, UMD/Idents, and other graphical attributes are under the cloning “umbrella” (i.e., attributes can be set up for a given PiP and then cloned across others as desired). Knowing the desired general layout, set up any PiP meeting your layout desires, and then clone and modify the settings to achieve the overall desired layout.

  • Page 68: Protocols (Router Integration) Controls

    PiP IN A thru IN E input channels. Protocols (Router Integration) Controls Note: • Router address must be accessible to network used for BBG-1070-QS Ethernet port (as set using the unit Admin > Networking function (see pg. 3-61). •...
  • Page 69 • Update from Line asserts UMD text. Note: • The Image Video integration works on a PiP-by-PiP basic (rather than commands being tied to input channels). • Image Video router/server holds BBG-1070-QS IP address to establish connection. Therefore, the Image Video address is not required here.

  • Page 70: Gpi Setup Controls

    BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides controls for setting up to 16 “virtual GPIs” using the up to five discrete GPI inputs. The virtual GPIs can in turn be used for attribute control such as tally...

  • Page 71: Event Actions Setup Controls

    Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides controls for setting up attribute control such as tally lamp activation, borders, and ident text using GPI, video format, or other action triggers. Internal intelligent event triggers provide attribute control based off of detected signal conditions.
  • Page 72 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) Event Action Examples • • • • • • • • • • • • In this example, GPI Condition 1 and GPI Condition 2 are used to control the color and activation of the PiP 1 tally lamps.
  • Page 73 Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides event-based loading allowing a defined action to be automatically engaged upon various received signal status. Event Setup Controlsvent Setup Controls Event based actions are not passive and can result in very significant and unexpected control and signal processing changes if not properly used.
  • Page 74 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) In the example here for Event 1, the Video Quality Events tab is set to screen for frozen video on Input A. When detected, this status can be used here (Video Quality set to “Input A Event Engaged”...
  • Page 75 Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides three general-purpose timers that can be triggered to start, pause, reset, or stop upon event actions. The state of each timer, in turn, can also be used to invoke other actions.

  • Page 76: Output Preview

    BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Output Preview displays regularly-sampled screen captures in the device DashBoard page. The transfer of screen image frame captures (via the device through Output Preview the DashBoard network connection) allows...

  • Page 77: User Graphic Overlay (Logo) Insertion Controls

    Uploading Your Logo or Trouble Slate Graphic Images Uploading Your Logo Graphic Image to BBG-1070-QS Device A user memory area for images is reserved in the device. A standard .png file is converted to a .bin file which is uploaded to the device, where the .bin then provides the logo graphic used by the device.

  • Page 78: Clock (Wall-Clock Time/Ltc) Controls

    BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides controls for setting and inserting wall-clock time into merged output or as a per-PiP insertion selection. Clock (Wall-Clock Time/LTC) Controls • Clock Mode / Set Controls Allows clock time and display mode to be set as follows: •...

  • Page 79: Presets

    Setup/Operating Instructions BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • Clock Character Size and Custom Position Horizontal and Vertical Position controls set the origin point for the clock Controls overlay. x= 100%...
  • Page 80 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • Preset Enter/Save/Delete Locks and unlocks editing of presets to prevent accidental overwrite as follows: • Protect (ready): This state awaits Protected and allows preset Save/ Delete button to save or delete current settings to the selected preset.
  • Page 81 Uploading Saved Presets to New or Different BBG-1070 Units (Cascade Config Usage) When uploading presets .bin files to BBG-1070-QS units in a Cascade Config chain, the steps below must be used to make certain each unit receives cascade setup info which is stored individually on each unit.
  • Page 82 BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued Provides a global operating status and allows a log download for factory engineering support. Also provides controls for selecting and loading firmware upgrade files. Firmware upgrade controls allow a selected firmware version (where multiple versions can be uploaded to the unit’s internal memory) to invoke...

  • Page 83: Admin (Log Status/Firmware Update)

    (Thermal shutdown is enabled by default). CAUTION Admin (Log Status/Firmware Update) The BBG-1070-QS FPGA is designed for a normal-range operating temperature around 85° C core temperature. Operation in severe conditions exceeding this limit for non-sustained usage are within device operating safe parameters, and can be allowed by setting this control to Disable.

  • Page 84: User Log

    BBG-1070-QS Function Menu List and Descriptions Table 3-1 BBG-1070-QS Function Menu List — continued (continued) • NTP Clock Setup Allows device NTP clock IP source and localization. This is the clock/time device will use for logs and other recorded actions.

  • Page 85: Uploading Firmware Using Web Interface And Gui

    Uploading Firmware Using Web Interface and GUI Firmware (such as upgrades, option keys, and presets .bin files) can be uploaded to BBG-1070-QS directly via the web html5 interface without going through DashBoard (see Figure 3-7). In addition to allowing uploads without needing a DashBoard connection, this method transfers files typically much faster than using DashBoard.

  • Page 86: Front Panel User Menus

    The front panel menus offers a true standalone means to configure the BBG-1070-QS with no connection to a network required, and is useful where changes need to be done immediately (or in emergency situations) without the benefit of network access.
  • Page 87 Illuminates GREEN indicating signal presence for currently-selected input video path. Illuminates ORANGE if input video is lost. REF STATUS Illuminates GREEN indicating BBG-1070-QS is receiving valid reference when set up for framesync operation. Illuminates ORANGE if reference is lost or incompatible with input video. COMM LED Illuminates GREEN when device is communicating with network connection.

  • Page 88: Basic Troubleshooting Checks

    Basic Troubleshooting Checks Item Checks Verify power presence and • On the BBG-1070-QS, in all cases when power is being properly supplied characteristics all indicators should be illuminated. Any device showing no illuminated indicators should be cause for concern. • Check the Power Consumed indication for the BBG-1070-QS. This can be observed using the Status front-panel or web UI pane.
  • Page 89 See Input Routing (p. 3-10) for more information. Cascade mode upstream image • -QS devices in cascade • All BBG-1070-QS devices used in a not as expected chain not set for same grid cascading chain must be set for the same layout number of columns and rows.

  • Page 90: In Case Of Problems

    (See Figure 3-9.) Make certain the card has the proper SD card installed in the under-card slot. If SD card is not installed, contact Product Support to obtain an SD card. Note: If unit is a BBG-1000 Series device, remove the top cover before proceeding. 3-68 BBG-1070-QS PRODUCT MANUAL BBG-1070QS-OM (V1.9)
  • Page 91 With button now released, the card will begin reprogramming: LED illuminates and remains illuminated. • When reprogram is complete, LED turns off, on, and then off • again (entire process takes about 1-1/2 minute). 3-69 BBG-1070QS-OM (V1.9) BBG-1070-QS PRODUCT MANUAL...
  • Page 92 The Cobalt Digital Inc. Technical Support Department will continue to provide advice on any product manufactured by Cobalt Digital Inc., beyond the warranty period without charge, for the life of the product. See Contact Cobalt Digital Inc. (p. 1-14) in Chapter 1, “Introduction“ for contact information. 3-70 BBG-1070-QS PRODUCT MANUAL BBG-1070QS-OM (V1.9)
  • Page 94 Cobalt Digital Inc. 2506 Galen Drive Champaign, IL 61821 Voice 217.344.1243 • Fax 217.344.1245 www.cobaltdigital.com BBG-1070QS-OM (V1.9) Printed in USA...
