GE Profile JT980SKSS Dimensions And Installation Information

JT980SK
GE Profile 30" Built-In Double Oven with Trivection
™
Dimensions and Installation Information
KW Rating
240V
8.9
208V 6.7
Breaker Size
240V 40 Amps
208V 40 Amps
Cabinet
A - Overlap of Oven Over Side Edges of Cutout
B - Overlap of Oven at Bottom of Cutout
Oven
C - Overall Depth
D - Overall Height
E - Overall Width
Note: Cabinets installed adjacent to wall ovens must have an adhesion
spec of at least a 194°F temperature rating. Electric wall ovens are not
approved for installation with a plug and receptacle. They must be
hard wired in accordance with installation instructions. Suitable oven
cabinet bracing must support 275 lbs.
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
For answers to your Monogram, GE Profile
®
GE appliance questions, visit our website at
®
ge.com or call GE Answer Center
®
800.626.2000.
30"
11/16"-3/4"
1"
23-1/2"
52-7/8"
29-3/4"
or
™
service,
Technology
™
Cabinet
width 30"
E
21" minimum
Door Opening
Allowance
MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.
THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.
2 x 4 or
C L
equivalent
runners
Suitable
bracing
18
to support
Over centerline
runners
of cabinet
Dimension and installation information are shown in inches.
Cutout width
28-1/2'' MIN.
5
28-5/8'' MAX.
A
B
Conduit
(48-1/2"
long)
Cutout height
51-13/16" MIN.
D
51-15/16" MAX.
A
21
B
Minimum cutout
location 2" from
C
the floor.
Acceptable
junction box
location area
DWO
Bottom of
7
Cutout
DWO
Listed by
Underwriters
Laboratories
R
jt980_install_ii.eps
Specification Created 1/05
Cutout
depth
23-1/2"
MIN
Junction
box
location
47" to
bottom of
junction
box
32
25
