PARTS INCLUDED
A
HARDWARE INCLUDED
22X
22X
TOOLS REQUIRED
#2 Phillips screwdriver
DISCLAIMER
•
Two people are recommended for the assembly of this product.
•
Use hardware provided and tools recommended to avoid any product faults.
•
Always assemble product on a clean soft surface to avoid scratching.
B
C
20X
4X
#2 Robertson
ASSEMBLY INSTRUCTIONS
D
1X
W-01S
F
E
G
1
Advertisement
Table of Contents
Related Manuals for Belair W-01S
Summary of Contents for Belair W-01S
- Page 1 W-01S ASSEMBLY INSTRUCTIONS PARTS INCLUDED HARDWARE INCLUDED TOOLS REQUIRED #2 Phillips screwdriver #2 Robertson DISCLAIMER • Two people are recommended for the assembly of this product. • Use hardware provided and tools recommended to avoid any product faults. • Always assemble product on a clean soft surface to avoid scratching.
- Page 2 W-01S STEP 1 Connect desk top A and right gable B as shown. Fasten pins and cams. STEP 2 Lay back D flat and lower top and gable onto back. Do not fasten pins and cams until next step. STEP 3 Attach left gable C .
- Page 3 W-01S STEP 4 Assemble transaction top E . Fasten pins and cams. STEP 5 Assemble waterfall top F and back G as shown. Fasten pins and cams. STEP 6 Position waterfall on center of transaction top. Secure waterfall with screws through back of unit as shown.
