ASSEMBLY INSTRUCTIONS
SKU: KDF
Description
Product Dimension
(FULL BED)
Cube Size
Product Dimension
(QUEEN BED)
Cube Size
Kendall Fabric Bed (Full-Queen)
: Kendall Fabric Bed (Full-Queen)
: 59"Wx83.6"Lx47"H
: 61"x41,7"x6.6"
: 65"Wx88.7"Lx47"H
: 66.8"x41.7"x6.6"
- 1 -
175 Southbelt Industrial Dr,
Houston, TX 77047
Email:sales@eastwestfurniture.net
NW: 95.7
LBS
GW: 103.4
LBS
NW:105.6 LBS
GW: 114.4 LBS
Advertisement
Table of Contents
Related Manuals for East West Furniture KDF
Summary of Contents for East West Furniture KDF
- Page 1 ASSEMBLY INSTRUCTIONS SKU: KDF 175 Southbelt Industrial Dr, Houston, TX 77047 Email:sales@eastwestfurniture.net Description : Kendall Fabric Bed (Full-Queen) Product Dimension : 59”Wx83.6”Lx47”H (FULL BED) Cube Size : 61”x41,7”x6.6” NW: 95.7 GW: 103.4 Product Dimension : 65”Wx88.7”Lx47”H (QUEEN BED) Cube Size : 66.8”x41.7”x6.6”...
- Page 2 BEFORE ASSEMBLY Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. Please take the time to read and follow the assembly instructions carefully. Be sure to check all packing material carefully for small parts which may have come loose inside the carton during shipment. Please separate, identify, and count all parts and metal hardware.
- Page 3 STEP 1 Attach the legs (E) to the bottom of the headboard (C). as shown below. STEP 2 Attach the legs (E) to the bottom of the footboard (D).as shown below. STEP 3 Assemble the left side rails by joining the (A) & (B) side rail pieces in the center to the horizontal support rail using the bolts (2) provided.
- Page 4 STEP 4 Attach the Headboard to the assemble side rails using the bolts (1) and washers (4) and (5) on the both sides. Repeat for the Footboard. Tighten with Allen key (6). STEP 5 Attach U-bracket (K) to the Horizontal support frame (H) Tighten with Allen key (6) using the bolts (6) STEP 6...
- Page 5 STEP 7 Attach Center Support Rail (L) to Headboard & footboard (on step 6) using the bolts (2) & bolts (3) Tighten with Allen key (6) STEP 8 Place the straight slats on top, and enjoy your new bed frame! Kendall Fabric Bed (Full-Queen) - 5 -...
