GE Profile JK955SKSS Dimensions And Installation Information

JK955SK
GE Profile 27" Built-In Double Oven
™
Dimensions and Installation Information
KW Rating Cabinet
240V A - Cabinet Width Required
6.8
B - Minimum Cabinet Depth
208V 5.1
C - Opening Width
Breaker Size
D - Opening Height
240V 30 Amps
E - Recommended Minimum
208V 30 Amps
Cutout Location from Floor
Oven
F - Overall Depth
G - Overall Height
H - Overall Width
Note: Cabinets installed adjacent to wall ovens must have an adhesion spec of at
least a 194°F temperature rating. For 27" built-in single ovens, if marks, blemishes
or the cutout opening is visible above the installed oven, it may be necessary to
add wood shims under the runners and front trim until the marks or openings
are covered.
Electric wall ovens are not approved for installation with a plug and receptacle.
They must be hard wired in accordance with installation instructions.
Installation Information: Before installing, consult installation instructions packed
with product for current dimensional data.
For answers to your Monogram, GE Profile
®
GE appliance questions, visit our website at
®
ge.com or call GE Answer Center
®
800.626.2000.
25" min. - 25-1/4" max.
50-1/8" max.
w/o trim
with trim
or
™
service,
27"
27" min.
23-5/8"
13-1/4"
23-5/8"
50-1/4"
51"
20
26-5/8"
Allow 3/4"
for overlap A
over all edges
of cutout
C
B
G
2" X 4" or
Conduit
F
equiv. runners
49" long
(cutout floor)
20" MIN.
door opening
allowance
(Must Support 275 LBS.)
Suitable
bracing
to support
over centerline
runners
of cabinet
