5.3

LDS CARD

5.3.1

PRESENTATION

The LDS card provides BRI connections to the ISDN network and allows you to manage 2-
or 4-channel DECT radio base stations.
The 16 interfaces on this CLX type card can be individually configured as S0, T0, or DECT.
Four-channel DECT radio base stations are connected by adding ADPCM daughter cards
(eight card maximum per LDS card).
LDS cards which are not fitted with ADPCM daughter cards operate on 2 channels.
References and Equipment:
LDS cards
LDSA:
LDSB:
ADPCM daughter card for LDS card
ADPCM:
Plug
BADX
Remote power supply card
PLDS
Cables
PAGE 66/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
Designation
16 T0/S0 interfaces, 2/4-channel DECT radio base stations
8 T0/S0 interfaces, 2/4-channel DECT radio base stations
Designation
ADCPM daughter card for the LDS card for management of
4-channel base stations (1 card for 2 interfaces)
Designation
Synchronous bus link plug
Designation
ISDN 40 V or Subscriber 48 V remote power supply card
Designation
Cable for LDSA card
(16 T0/S0 interfaces, 2/4-channel DECT radio base stations)
Cable for LDSB card
(8 T0/S0 interfaces, 2/4-channel DECT radio base stations)
HJ4094A
HJ4094B
HJ4055A
HR 3664D
HJ 4206A
HG4301A
HG4301B
LCAH-30521-001-05=01/EN
Reference
Reference
Reference
Reference
Reference
