Description of the connectors
J1:
48-pin connector for connecting the MVE or POCZ card.
J2:
Not fitted.
J3:
48-pin connector for connecting an expansion daughter card (EQPT 6).
J4:
18-pin connector for connecting the power supply ribbon cable.
J5:
40-pin connector for connecting the integrated parallel port to the distribution
frame (ribbon cable).
J6:
50-pin connector for various connections to the distribution frame (including serial
port connection), using a ribbon cable.
J7:
40-pin stocko connector for connecting a serial terminal.
Note:
This connector is parallel wired to connector J3 on the ROCZ card.
J8:
Not fitted.
J9:
80-pin connector for connecting a memory expansion daughter card (MOCZ).
J10:
2-pin vertical stocko connector to the ringing current for analog sets.
Description of switches:
CA1:
Bus adaptation on the Tx/Rx pair of the T0 interface (set to the ON position at
the factory).
CA2:
Bus adaptation on the Tx/Rx pair of the S0 interface (set to the ON position at
the factory).
CA5:
BA:
S:
CA9:
NMI: Reserved for factory tests.
RES: System RESET (do not leave this switch in the ON position).
CA10: To start up the remote power supply to S0 (dual jumper).
1-2 and 5-6:
2-3 and 6-7:
3-4 and 7-8:
PAGE
24/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
put the battery in service (ON position)
(set to the OFF position at the factory)
S0 operating mode (ON position).
Idle state.
40 V remote power supply for ISDN sets (positions are set at
the factory).
48 V remote power supply for the DECT base station.
LCAH-30521-001-05=01/EN
