Mic-D30 Microphone
User Manual
Guangzhou Zhiying Technology Co., Ltd
Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou,
China, 510000
Thank you for choosing
SYNCO Mic-D30
support@syncoaudio.com
Please read this manual carefully before use and follow all instructions
www.syncoaudio.com
mentioned herein.
https://www.facebook.com/syncomicrophones

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mic-D30 and is the answer not in the manual?

Questions and answers

Related Manuals for Synco Mic-D30

Summary of Contents for Synco Mic-D30

  • Page 1 Mic-D30 Microphone User Manual Guangzhou Zhiying Technology Co., Ltd Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou, China, 510000 Thank you for choosing SYNCO Mic-D30 support@syncoaudio.com Please read this manual carefully before use and follow all instructions www.syncoaudio.com mentioned herein.
  • Page 2 Feature Introduction.................01 Caring For Your SYNCO Mic-D30 Microphone......01 Package List..................02 Components Introduction..............03 Operations..................03 ① The Use of Furry Windscreen ② Charging the Mic-D30 Microphone ③ Using with Your Device ④ Real-time Audio Monitoring ⑤ Low Cut Button Specifications..................05...

  • Page 3: Feature Introduction

    Packing Box *1 Support real-time audio monitoring Type-C to 3.5mm TRS/ TRRS output Dual shock mount to firmly hold the mic Caring For Your SYNCO Mic-D30 Microphone Furry Windscreen *1 Shock Mount *1 User Manual *1 Please keep the product in a dry, clean, dust-free environment.

  • Page 4: Components Introduction

    2. Charging the Mic-D30 Microphone Components Introduction The Mic-D30 has a built-in battery. Please ON-OFF & Battery fully charge the microphone with the Indicator Type-C Charging Port and Type-C to USB Charging Cable before use. (Note: The ON-OFF & Battery Indicator...

  • Page 5: Specifications

    2. Performance Parameter 5. Low Cut Button First press for 75Hz low cut, second press for 150Hz low cut and the third press to turn off the low cut function. Transducer Back Electret Condenser Polar Pattern Super Cardioid Specifications Frequency Response 20 Hz to 20 KHz Dynamic Range (Typical) 119dB SPL (A-weight per IEC651)
