audium Comp 3.2 Drive User Manual page 7

Controls and Connectors on the Speakers
1
3
1
4
1. Display: OLED graphic display shows the current speaker status.
2. Knob / push-button for navigation in the menu and setting of the parameters.
Power LED: lights red when speaker is active, dimmed red when in standby
3.
4. Line - Input: Connect this input with the Pre - Out of your audio source
5. Speaker Input:
Note: Note the polarity + (red) and - (white).
6. Power socket: Insert here the end of the power supply cable.
Power Supply:
The AUDIUM Active
The outsourcing of the power supply from the speaker prevents mutual unwanted
influencing the Amplifier electronics, the chassis and the power supply.
Furthermore, this allows a simple upgrade of the power supply to a higher- performance
type.
The power supplies of Comp7 Active, Comp8 and Comp9
additionally a power switch. Switch on the power supply with it when all connections have
been made.
Power-LED
Stromversorgungs-Stecker
Active
6
Connect these jacks to the speaker cable.
and drive Speakers have an external power supply.
Drive
5
Active
- 7 -
and drive have
Netzschalter
Netzbuchse
2
5
