- Page 1 KMP 7036 Insulation-Continuity Tester Users Manual...
- Page 3 KMP7036 Insulation-Continuity Tester Users Manual September 2011, Rev.1 ©2011 Amprobe Test Tools. All rights reserved. Printed in China...
- Page 4 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for 1 year from the date of purchase, unless local laws require otherwise. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
- Page 5 KMP7036 Insulation-Continuity Tester EARTH: Terminal for insulation resistance measurement COM: Return terminal for Voltage and Continuity measurement V: Input terminal for Voltage measurement LINE: Terminal for insulation resistance measurement LCD Display Test lead resistance zero function / Display backlight button Data Hold button TEST Button Rotary switch...
- Page 6 Test Lead Resistance Zero mode Continuity Buzzer Low Battery Indicator External Voltage Warning AC Voltage Data Hold Hazardous Voltage presents at terminals Measurement Unit for Resistance Measurement Unit for Voltage...
-
Page 7: Table Of Contents
KMP7036 Insulation-Continuity Tester CONTENTS SYMBOLS ......................2 SAFETY INFORMATION ..................2 UNPACKING AND INSPECTION ................3 FEATURES .......................4 MAKING MEASUREMENT ..................4 Rotary Switch Positions ..................5 Function Buttons ....................5 Measuring AC Voltage ..................6 Measuring Continuity ..................7 Measuring Insulation Resistance ..............8 SPECIFICATIONS .....................10 MAINTENANCE AND REPAIR ................12 REPLACING THE BATTERY ..................12... -
Page 8: Symbols
SYMBOLS Caution ! Risk of electric shock. � Caution ! Refer to the explanation in this Manual. The equipment is protected by double insulation or reinforced insulation. Do not use in distribution systems with voltages higher than 660 V. Earth (Ground). Battery �... -
Page 9: Unpacking And Inspection
X� Warning: Read Before Using • To avoid possible electrical shock or personal injury, follow these instructions and use the Tester only as specified in this manual. • Do not use the Tester or test leads if they appear damaged, or if the Tester is not operating properly. -
Page 10: Features
If any of the items are damaged or missing, return the complete package to the place of purchase for an exchange. FEATURES The quality of insulation is critical to assure proper, uninterrupted and safe functioning of the electrical circuits. Robin-Amprobe Insulation-Continuity Tester is designed to diagnose and prevent the breakdown of the insulation in various parts of the electrical system such as wires, transformers and motors. -
Page 11: Rotary Switch Positions
• Verify the Tester’s operation by measuring on a known source • Do not use in distribution systems with voltages higher than 660V AC. • Use the Tester with caution for voltages above 30 Vac rms, 42 Vac peak, or 60 Vdc. These voltages pose electrical shock hazards. Rotary Switch Positions Switch Position Measurement Function... -
Page 12: Measuring Ac Voltage
• Verify the Tester’s operation by measuring on a known source • Do not use in distribution systems with voltages higher than 660V AC. • Use the Tester with caution for voltages above 30 Vac rms or 42 Vac peak. These voltages pose electrical shock hazards. - Page 13 • Warning buzzer will sound when the Tester detects a voltage >10Vac or dc. Display shows “Uext” and To measure continuity: 1. Turn the rotary switch to Continuity position. 2. Use V and COM terminals for this test with test leads. 3.
-
Page 14: Measuring Insulation Resistance
4. Press TEST button (continuous measurement) The primary display shows the continuity resistance. The secondary (smaller digits on the right side) display shows the actual output DC voltage. buzzer threshold: 2Ω (when symbol on screen) Measuring Insulation Resistance X� • Disconnect circuit power and de-energize the circuit before test. •... - Page 15 • When the measurement is completed, do not touch the circuit as the circuit may store energy, which may cause electric shock. Allow time for circuit to discharge or discharge the circuit (capacitors) after the measurement. To measure insulation resistance: 1.
-
Page 16: Specifications
SPECIFICATIONS Ambient temperature: 23°C ±5°C (73.4°F ±9°F); Relative temperature: ≤75% Accuracy: ±(% of reading + LSD) Maximum display: Digital 1999 counts Over-range indication: Voltage “OL V”, Continuity “>200Ω”, Insulation “>2.2GΩ”. Range: Automatic Altitude: Operating ≤ 2000m Operating temperature: 0°C ~ +35°C (32°F ~ 95°F), Relative humidity ≤70% Storage temperature: -20°C ~ +60°C (14°F ~ 122°F), Relative humidity ≤80% Power Supply: Alkaline Battery 1.5V (AA Battery or equivalent) ×... - Page 17 Insulation Resistance Measurement DC Test Voltage Resolution Test Current Accuracy 250V ≥1mA@ 0.25MΩ 500V ≥1mA@ 0.5MΩ 0 to +10% 1000V ≥1mA@ 1MΩ Measuring Range Resolution Accuracy (auto ranging) 0.00MΩ – 9.99MΩ 0.01MΩ ± (3% Rdg + 5 LSD) 10.0MΩ – 99.9MΩ 0.1MΩ...
-
Page 18: Maintenance And Repair
MAINTENANCE AND REPAIR If the Tester fails to operate, check battery, test leads, etc., and replace as necessary. Double check the followings: 1. Check the battery. Replace the battery immediately when the symbol “ ” appears on the LCD. 2. Review the operating instructions for possible mistakes in operating procedure. - Page 20 • Catalog • Application notes • Product specifications • User manuals...
