- Page 1 MODEL D AND C DEVICE CONTROL INTERFACE MANUAL VERSION 2.0 [Skriv tekst]...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS ..................2 INTRODUCTION ....................3 COMPLIANCE ....................3 SERIAL INTERFACE ..................4 TELEGRAMS ......................5 COMMANDS .......................6 SERVICE INFORMATION ................14... -
Page 3: Introduction
Steinway Lyngdorf products and accessories comply with parts 15 and 68 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference; and (2) this device must accept any interference received, including any interference that may cause undesired operation. -
Page 4: Serial Interface
SERIAL INTERFACE This document describes the interface to control a Steinway Lyngdorf system through an MCB-1 and RF interface box. The interface between PC and interface box is UART based. This section briefly describes a standard UART based communication protocol to be used in the interface. -
Page 5: Telegrams
Object Value Description RF_SETUP_OBJECT 0x00 Commands to the Interface box. RF_DEVICE_CONTROL_OBJECT 0xF1 Commands to control Steinway Lyngdorf system. See description in the next chapter. For RF_SETUP_OBJECT the commands and replies are constructed as shown below: Object Command Param_0 … Param_n... -
Page 6: Commands
RESET_AND_SCAN [0x00] Telegram: 0x02 0x00 0x00 Reply: None Description: This telegram resets the Interface box, and scans for a Steinway Lyngdorf unit. RF_INFO [0x01] Telegram: 0x02 0x00 0x01 Reply: 0x05 0x00 0x01 0xYY 0xZZ 0xZZ Description: This telegram can be used to request info on the current RF connection. - Page 7 RF_DEVICE_CONTROL_OBJECT commands Command Value Parameters Size Reply 0x00 None Status 0x01 None Status STANDBY 0x02 None Status SELECT_INPUT 0x10 Input select 1 BYTE Status SELECT_ROOMPERFECT 0x11 RP filter select 1 BYTE Status SELECT_VOICING 0x12 Voicing select 1 BYTE Status VOLUME_SET 0x20 Volume Status...
- Page 8 Standby [0x02] Telegram: 0x03 0xF1 0x00 0x02 Reply: 0x04 0xF1 0x00 0x02 0x00 Description: Toggles On/Off. SELECT_INPUT [0x10] Telegram: 0x04 0xF1 0x00 0x10 0xSS Reply: 0x04 0xF1 0x00 0x10 0x00 Description: Selects desired input. 0xSS can be one of the following: 0x00 = CD 0x01 = DIGITAL_1 0x02 = DIGITAL_2...
- Page 9 SELECT_VOICING [0x12] Telegram: 0x04 0xF1 0x00 0x12 0xVV Reply: 0x04 0xF1 0x00 0x12 0x00 Description: Selects desired Voicing. 0x00 = “Neutral” 0x01 = “Music 1” 0x02 = “Music 2” 0x03 = “Relaxed” 0x04 = “Open” 0x05 = “Open Air” 0x06 = “Soft” VOLUME_SET [0x20] Telegram: 0x05 0xF1 0x00 0x20 0xVH 0xVL...
- Page 10 CD_PLAY_PAUSE [0x31] Telegram: 0x03 0xF1 0x00 0x31 Reply: 0x04 0xF1 0x00 0x31 0x00 Description: Toggles play/pause mode. CD_PAUSE [0x32] Telegram: 0x03 0xF1 0x00 0x32 Reply: 0x04 0xF1 0x00 0x32 0x00 Description: Sets CD in pause mode. CD_STOP [0x33] Telegram: 0x03 0xF1 0x00 0x33 Reply: 0x04 0xF1 0x00 0x33 0x00 Description: Sets CD in stop mode.
- Page 11 CD_PLAY_MODE [0x38] Telegram: 0x04 0xF1 0x00 0x38 0xPM Reply: 0x04 0xF1 0x00 0x38 0x00 Description: Sets CD play mode. 0x00 = Normal 0x01 = Repeat one 0x02 = Repeat All 0x03 = Random CD_START_WIND [0x39] Telegram: 0x03 0xF1 0x00 0x39 Reply: 0x04 0xF1 0x00 0x39 0x00 Description: Starts winding CD.
- Page 12 GET_INPUT [0x81] Telegram: 0x03 0xF1 0x00 0x81 Reply: 0x05 0xF1 0x00 0x81 0x00 0xSS Description: Returns current selected input. (See select input command) GET_INPUT_NAME [0x82] Telegram: 0x03 0xF1 0x00 0x82 Reply: 0x12 0xF1 0x00 0x82 0x00 … Description: Returns name of current selected input. (14 Chars) GET_ROOMPERFECT [0x83] Telegram: 0x03 0xF1 0x00 0x83...
- Page 13 GET_CD_DATA [0x87] Telegram: 0x03 0xF1 0x00 0x87 Reply: 0x12 0xF1 0x00 0x87 0x00 … Description: Returns CD data. (14 BYTES) cd_state pause_state cd_direction repeat_state random_state title minimum title maximum disc minutes disc seconds disc frames track title track index track minutes track seconds...
-
Page 14: Service Information
SERVICE INFORMATION In order to obtain warranty service you must contact your original dealer or the Steinway Lyngdorf distributor of the region or country where you are located. If you have trouble locating an authorized representative, please contact the Steinway Lyngdorf Customer Service Department using the contact information at www.steinwaylyngdorf.com, or you may email service@steinwaylyngdorf.com.
